Product Overview
The Schneider TCSESM163F23F0 ConneXium Ethernet TCP/IP Managed Switch is an industrial Ethernet communication device used to connect multiple Ethernet-based automation components within a control network. It provides managed switching functions for industrial installations where controllers, distributed I/O, operator interfaces, drives, industrial computers, and supervisory systems need to exchange data over a structured Ethernet network.
The switch can be installed in a control cabinet as a central communication point between different automation devices. Its managed architecture allows network parameters and diagnostic functions to be handled at the switch level, which is useful when troubleshooting communication faults or maintaining a larger industrial Ethernet installation.
In a Modicon-based control environment, the TCSESM163F23F0 can connect control equipment with field-level and supervisory devices while maintaining the Ethernet communication structure defined by the system integrator. It can also be used in machine-level networks where multiple Ethernet nodes need to share a common industrial communication infrastructure.
The switch itself does not execute PLC logic or process field signals. Its role is to maintain the Ethernet communication path between connected devices and support the network management requirements of the automation system.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Schneider Electric |
| Model / Part Number | TCSESM163F23F0 |
| Product Family | ConneXium |
| Product Type | Ethernet TCP/IP Managed Switch |
| Application | Industrial Ethernet network management and connectivity |
| Dimensions | 111 × 131 × 111 mm |
| Weight | 0.6 kg |
Product Features
- Managed Ethernet switching for industrial automation networks.
- Supports Ethernet TCP/IP communication between connected control devices.
- Provides a centralized network connection point for multiple Ethernet nodes.
- Suitable for PLC, PAC, remote I/O, HMI, drive, and industrial computer networks.
- Supports network configuration and diagnostic activities.
- Suitable for cabinet-based and machine-level Ethernet installations.
- Can form part of larger industrial control and supervisory networks.
- Supports structured network maintenance and troubleshooting.
Working Principle
The TCSESM163F23F0 operates by receiving Ethernet frames from connected devices and forwarding them toward the appropriate network destination. The switch uses Ethernet addressing information to determine where communication traffic should be sent, allowing several connected devices to exchange information through the same network infrastructure.
A typical communication path is:
PLC / PAC → TCSESM163F23F0 → Ethernet Network Device → HMI / I/O / Drive / SCADA
For example, a PLC can exchange control data with remote I/O while an HMI retrieves process information from the controller through the same Ethernet infrastructure. The switch handles the corresponding frame forwarding between the connected network ports.
As a managed switch, it also supports network configuration and diagnostic functions. During commissioning, technicians can verify network connectivity and configuration. During maintenance, diagnostic information can help identify problems associated with individual ports, connected devices, or the network topology.
Role in an Industrial Ethernet Control Architecture
PLC / PAC → TCSESM163F23F0 → Remote I/O / HMI / Drives / Industrial PC → Supervisory Network
| System Element | Function |
|---|---|
| PLC / PAC | Executes control logic and exchanges automation data |
| TCSESM163F23F0 | Provides managed Ethernet switching and device connectivity |
| Remote I/O | Exchanges field input and output data with the controller |
| HMI | Provides operator monitoring and control functions |
| Ethernet Drives | Exchanges drive commands, status, and diagnostic information |
| Industrial PC / SCADA | Provides supervisory monitoring and data acquisition |
| Plant Network | Connects the control network with higher-level automation systems |
The TCSESM163F23F0 functions as part of the communication infrastructure between these devices. Its configuration and physical placement should match the intended network topology so that control, diagnostic, and supervisory traffic can reach the required destinations.
Industrial Applications
| Application | Typical Use |
|---|---|
| PLC Control Networks | Connects controllers with Ethernet-enabled automation equipment |
| Distributed I/O | Provides network connectivity between controllers and remote I/O stations |
| HMI Communication | Connects operator interfaces with PLC and other control devices |
| Drive Networks | Provides Ethernet communication between controllers and compatible drives |
| Machine Automation | Serves as a central Ethernet connection point inside machine control systems |
| SCADA Integration | Connects supervisory computers with industrial control networks |
| Plant Automation | Supports Ethernet communication between control-level and higher-level systems |
Installation and Maintenance
- Define the network topology
Identify all devices that will communicate through the switch and determine the intended network structure before installation. - Select a suitable installation location
Install the switch in a control cabinet or equipment area that allows convenient cable routing and maintenance access. - Verify the power supply
Confirm that the available control-cabinet power source matches the requirements of the switch. - Inspect Ethernet cables
Check cable condition, connectors, routing, and shielding arrangements before commissioning. - Review IP addressing
Confirm that connected Ethernet devices use the intended addresses and that duplicate addresses are avoided. - Configure managed functions
Apply the required network configuration according to the control system architecture. - Label important connections
Clearly identify connections to PLCs, HMIs, I/O stations, drives, uplinks, and other critical devices. - Verify communication after startup
Confirm that each required network device can communicate with its intended destination. - Check switch diagnostics
Use available diagnostic information to identify abnormal port conditions or communication problems. - Inspect physical connections during maintenance
Check Ethernet connectors and cables for looseness, damage, contamination, or excessive mechanical stress. - Maintain configuration backups
Keep current network configuration records so that a replacement switch can be restored efficiently if required. - Update network documentation
Record changes to device addresses, port assignments, network topology, and connected equipment after system modifications.
Compatible System Components
| Component | Role in the System |
|---|---|
| Schneider Modicon PLCs and PACs | Provides the main Ethernet control nodes |
| Schneider Modicon X80 I/O | Provides distributed control and I/O communication |
| Schneider Harmony HMIs | Provides operator interface connectivity |
| Schneider Altivar Drives | Exchanges drive control and diagnostic data |
| Industrial Ethernet Cables | Provides physical network communication |
| Industrial PCs / SCADA Systems | Provides supervisory monitoring and data acquisition |
Recommended Related Models
| Model / Family | Product Type / Application |
|---|---|
| Schneider ConneXium Ethernet Switches | Industrial Ethernet switching and network infrastructure |
| Schneider ConneXium Managed Switches | Managed Ethernet communication for automation networks |
| Schneider Modicon X80 | PLC and distributed I/O platform |
| Schneider Modicon M340 | PLC platform for industrial automation |
| Schneider Modicon M580 | Ethernet-based PAC platform for modern control architectures |
Key Advantages
- Provides managed Ethernet connectivity for industrial automation equipment.
- Supports communication between multiple Ethernet-based control devices.
- Provides network configuration and diagnostic capabilities.
- Suitable for PLC, I/O, HMI, drive, and SCADA architectures.
- Helps organize Ethernet communication within control cabinets and machine networks.
- Supports maintenance activities through structured network diagnostics.
Technical FAQs
What is the Schneider TCSESM163F23F0 used for?
The TCSESM163F23F0 is a ConneXium Ethernet TCP/IP managed switch used to connect and manage communication between Ethernet-enabled industrial automation devices.
What role does the switch have in a PLC network?
The switch provides the Ethernet communication infrastructure between the PLC and other network devices such as remote I/O, HMIs, drives, industrial computers, and supervisory systems.
What should be checked when a device connected to the switch cannot communicate?
Check the device power, Ethernet cable, connector, switch port, IP address, network configuration, and relevant switch diagnostics. Comparing the affected port with a known-working connection can also help isolate the problem.
Can the TCSESM163F23F0 be used for both machine-level and plant-level Ethernet networks?
It can form part of different industrial Ethernet architectures, but the appropriate application depends on the required network topology, communication functions, environmental conditions, and system design. The switch configuration should be matched to the intended network role.
