Product Overview
The Schneider HMIET6700 is a Harmony ET6 wide screen touch panel for industrial machine and equipment operator interfaces. Its 15-inch display gives operators more room to view machine status, process values, alarms, and control functions within the same HMI application.
The larger display area is useful for equipment with multiple operating screens or a greater amount of information to present at the operator station. The HMI can be used alongside PLCs, remote I/O, drives, sensors, and other automation equipment to provide a centralized interface for machine operation.
Typical operator tasks include monitoring equipment conditions, changing operating parameters, acknowledging alarms, and accessing different machine functions through configured touchscreen pages.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Wide screen touch panel |
| Product Family | Harmony ET6 |
| Model | HMIET6700 |
| Screen Size | 15″ |
| Display Type | Wide screen |
| User Interface | Touchscreen |
| Application | Machine and equipment operator interface |
| Mounting | Panel mounting |
| HMI Function | Operator control and monitoring |
| Display Application | Process values, alarms, status information, and control screens |
| System Integration | PLC and industrial automation control systems |
| Dimensions | 412 × 50 × 268 mm |
| Weight | 2.52 kg |
Product Features
- 15-inch wide screen format for industrial operator interfaces
- Touchscreen operation for direct interaction with machine functions
- Harmony ET6 platform for machine and equipment applications
- Larger display area for detailed operating screens
- Suitable for displaying process values, alarms, and equipment status
- Supports centralized access to machine control functions
- Panel-mounted format for control cabinets and machine enclosures
- Suitable for PLC-based automation architectures
Working Principle
The HMIET6700 serves as the operator-facing interface of the automation system. The configured application displays information exchanged with the connected controller, allowing operators to view machine states, process values, alarms, and other operating information.
When an operator touches a control object or enters a parameter, the HMI processes the interaction and exchanges the corresponding data with the control system. This allows common tasks such as changing setpoints, issuing machine commands, acknowledging alarms, and navigating between operating screens.
During normal operation, the HMI continuously presents the information required by the operator while keeping frequently used controls accessible from the touchscreen.
Role in a Harmony ET6 HMI Control Architecture
| System Element | Role |
|---|---|
| HMIET6700 | Provides the touchscreen operator interface |
| PLC | Executes machine logic and control sequences |
| Remote I/O | Collects field signals and controls connected devices |
| Variable Speed Drive | Controls motor operation and provides operating feedback |
| Sensors | Supplies process and equipment information |
| Actuators | Performs physical machine operations commanded by the control system |
| Industrial Network | Exchanges application data between the HMI and automation devices |
Industrial Applications
| Application | HMIET6700 Usage |
|---|---|
| Machine Automation | Operator control, machine status monitoring, and alarm handling |
| Packaging Equipment | Production monitoring and operating parameter adjustment |
| Material Handling | Displaying conveyor and handling equipment conditions |
| Process Equipment | Monitoring process information and operating states |
| Pump Systems | Viewing pump conditions and adjusting control parameters |
| Motor Control Panels | Centralized display of motor and drive information |
| Production Lines | Monitoring multiple machine functions from one operator interface |
Installation and Maintenance
- Install the HMI in a suitable control cabinet, machine enclosure, or dedicated operator station.
- Confirm the required panel opening before beginning mechanical installation.
- Secure the panel firmly to prevent movement caused by machine vibration.
- Maintain sufficient access around the installed panel for wiring and service work.
- Route communication wiring away from high-power motor and switching cables where practical.
- Check power and communication connections before commissioning.
- Verify communication between the HMI and connected PLC during startup.
- Confirm that displayed process values correspond to the intended controller variables.
- Test touchscreen commands to verify that each operator control performs the intended function.
- Check alarm display and acknowledgement functions during commissioning.
- Keep the touchscreen surface clean and avoid using sharp objects on the display.
- Place the machine and control system in a safe state before performing maintenance or electrical work.
Compatible System Components
| Component | Function in the System |
|---|---|
| Schneider PLC | Executes control logic and exchanges application data with the HMI |
| Schneider Remote I/O | Handles distributed field input and output signals |
| Schneider Variable Speed Drive | Provides motor control and operating feedback |
| Schneider Contactors and Protection Devices | Controls and protects electrical loads |
| Industrial Ethernet Devices | Supports communication within the automation architecture |
| Machine Sensors | Supplies process and equipment status information |
| Motor Starters | Provides motor switching and control functions |
Recommended Related Models
| Model | Product Category | Typical Use |
|---|---|---|
| HMIET6401 | Harmony ET6 Wide Screen Touch Panel | Compact operator interface applications |
| HMIET6500 | Harmony ET6 Wide Screen Touch Panel | 10-inch class operator interface applications |
| HMIET6501 | Harmony ET6 Wide Screen Touch Panel | 10-inch class operator interface applications |
| HMIET6600 | Harmony ET6 Wide Screen Touch Panel | 12-inch class operator interface applications |
| HMIET6700 | Harmony ET6 Wide Screen Touch Panel | 15-inch class operator interface applications |
Key Advantages
- 15-inch wide screen operator interface
- Direct touchscreen operation
- Larger display area for detailed operator screens
- Suitable for PLC-based machine control
- Centralized access to machine information and control functions
- Suitable for panel-mounted industrial applications
Technical FAQs
What type of HMI is the Schneider HMIET6700?
The HMIET6700 is a Harmony ET6 wide screen touch panel intended for industrial machine and equipment operator interface applications.
What is the advantage of the 15-inch screen?
The larger screen area allows more operating information, status indicators, alarms, and control objects to be arranged on the HMI application, which is useful for machines with multiple functions.
Can the HMIET6700 be used with PLC-based automation systems?
Yes. The HMIET6700 can serve as the operator interface within a PLC-based automation architecture, allowing operators to monitor application information and interact with configured control functions.
What applications are suitable for the HMIET6700?
Typical applications include machine automation, packaging equipment, material handling systems, process equipment, pump systems, motor control panels, and production lines.
