Product Overview
Efficient and precise motor control is critical in industrial automation systems. The Schneider ATV212HD22N4 Frequency Converter provides advanced speed and torque management for high-power three-phase motors, ensuring energy efficiency, optimized process control, and reliable operation.
Designed for very high-power applications, this frequency converter delivers smooth acceleration, accurate speed regulation, and integrated protection for motors, making it ideal for demanding industrial environments. Its robust construction and advanced control features allow seamless integration into automation systems.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model | ATV212HD22N4 |
| Product Type | Frequency Converter |
| Function | Motor speed and torque control |
| Motor Power | 22 kW |
| Output Voltage | 3-phase 380–480 V AC |
| Dimensions | 420 × 214 × 240 mm |
| Weight | 26.4 kg |
| Mounting Type | Panel / Wall Mountable |
| Input Voltage Range | 380–480 V AC |
| Output Frequency | 0–500 Hz |
| Control Type | V/f control |
| Operating Temperature | -10°C to 50°C |
| Environment | Industrial-grade |
| Application | Motor control, industrial automation |
Function and Working Principle
The ATV212HD22N4 operates by converting AC input voltage into a variable frequency output to regulate motor speed and torque. Key functions include:
- Smooth speed control for energy-efficient motor operation
- Precise torque management to protect motors and connected machinery
- Soft-start and dynamic braking functions to reduce mechanical stress
- Robust design suitable for panel or wall installation
By controlling both voltage and frequency, the converter ensures stable motor operation, reduces energy consumption, and provides reliable performance in demanding industrial environments.
Role in Industrial Control Systems
This frequency converter is essential in industrial automation by:
- Controlling speed and torque of pumps, fans, conveyors, compressors, and other heavy-duty motors
- Protecting motors from overcurrent, overheating, and voltage fluctuations
- Integrating with PLCs and automation networks for coordinated process control
- Improving energy efficiency and reducing operational costs
It ensures industrial processes operate safely, efficiently, and reliably.
Industrial Applications
The Schneider ATV212HD22N4 is commonly used in:
- Large pumping and HVAC systems
- Conveyor and material handling systems
- Fans, compressors, and industrial machinery
- Packaging, assembly, and production lines
- High-power motor-driven applications
- Energy-intensive manufacturing and processing industries
Its high power rating and industrial-grade durability make it suitable for demanding environments.
Installation and System Integration
Proper installation ensures optimal performance:
- Mounted on panels or walls following manufacturer instructions
- Connected to three-phase AC input and motor output terminals
- Integrated with PLCs or automation networks for process monitoring and control
- Maintain adequate ventilation and thermal management
- Follow industrial wiring, grounding, and safety standards
Correct installation guarantees reliable motor operation, safety, and long-term performance.
Compatible System Components
The ATV212HD22N4 typically integrates with:
- Schneider PLCs and I/O modules
- Three-phase motors and motor protection devices
- Industrial sensors for speed, torque, or process monitoring
- Control panels, wiring accessories, and terminal blocks
These components create a reliable and efficient industrial motor control system.
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| ATV212HD15N4 | Frequency Converter | 15 kW output, heavy-duty | High-power industrial motors |
| ATV212HD18N4 | Frequency Converter | 18 kW output, advanced performance | Very large industrial motors |
| ATV212HD22N4 | Frequency Converter | 22 kW output, high-performance | Extra-high-power industrial motors |
| ATV212HD30N4 | Frequency Converter | 30 kW output, maximum power | Extremely high-demand applications |
Key Advantages
- Precise speed and torque control for very high-power three-phase motors
- Energy-efficient operation reduces operational costs
- Protects motors against overcurrent, overheating, and voltage fluctuations
- Industrial-grade robust construction for demanding environments
- Compact and modular design for flexible installation
- Supports continuous operation and high-demand industrial applications
Technical FAQs
What is the main function of the ATV212HD22N4?
It provides variable frequency output to control speed and torque of high-power industrial motors.
Where is it typically used?
It is used in pumps, fans, conveyors, compressors, and other very high-power motor-driven systems.
Does it provide motor protection?
Yes, it includes protections against overcurrent, overheating, and voltage fluctuations.
Is it suitable for very high-power applications?
Yes, it is designed for motors up to 22 kW in demanding industrial environments.
Conclusion
The Schneider ATV212HD22N4 Frequency Converter is a vital component for industrial automation, providing precise motor control, energy efficiency, and protection for very high-power motors. Its advanced features, robust construction, and reliable performance make it ideal for heavy-duty industrial applications.
For engineers and system integrators, this converter ensures safe, efficient, and continuous operation in high-demand industrial processes.
