Product Overview
Efficient motor control is fundamental to modern industrial automation, enabling manufacturers to optimize production efficiency, reduce energy consumption, and extend equipment service life. The Schneider ATV12HU15M2 is a compact Altivar 12 Frequency Inverter (Variable Frequency Drive, VFD) engineered to deliver reliable variable-speed control for three-phase asynchronous motors in industrial and commercial applications.
By converting a fixed single-phase AC input into an adjustable three-phase AC output, the inverter allows motors to operate at precisely controlled speeds according to application requirements. This results in smoother motor starting, lower mechanical stress, improved process accuracy, and significant energy savings compared with traditional direct-on-line motor operation.
With overall dimensions of 105 × 142 × 156.2 mm and a weight of approximately 1.4 kg, the ATV12HU15M2 is suitable for compact electrical cabinets while offering powerful motor control capabilities. As part of Schneider Electric’s Altivar 12 product family, it combines simple commissioning, dependable operation, and comprehensive protection functions for a wide variety of industrial automation systems.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model | ATV12HU15M2 |
| Product Family | Altivar 12 |
| Product Type | Frequency Inverter / Variable Frequency Drive |
| Rated Motor Power | 1.5 kW |
| Rated Horsepower | 2 HP |
| Input Voltage | 200–240 VAC |
| Input Phase | Single-phase |
| Output Voltage | Three-phase AC |
| Output Frequency Range | 0–400 Hz |
| Motor Type | Three-phase Asynchronous Motor |
| Motor Control Method | Voltage/Frequency (V/F) Control |
| Communication Protocol | Modbus RTU |
| Communication Interface | Integrated RS-485 |
| Integrated Keypad | Yes |
| Cooling Method | Forced Air Cooling |
| Protection Rating | IP20 |
| Protection Functions | Overload, Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit, Motor Thermal Protection |
| Mounting Method | Panel Mount |
| Installation | Industrial Control Cabinet |
| Dimensions | 105 × 142 × 156.2 mm |
| Weight | 1.4 kg |
| Operating Environment | Industrial Applications |
| Typical Applications | Pumps, Fans, Compressors, Conveyors, Packaging Machines, HVAC Systems |
Function and Working Principle
The Schneider ATV12HU15M2 controls motor speed by varying the output voltage and frequency supplied to the connected AC motor. Since motor speed is directly proportional to electrical frequency, the inverter enables accurate speed adjustment without requiring mechanical speed-changing devices.
Major functions include:
- Variable speed motor control
- Smooth motor starting
- Controlled motor stopping
- Adjustable acceleration and deceleration ramps
- Energy-efficient operation
- Torque optimization
- Motor thermal protection
- Electronic overload protection
- Overcurrent protection
- Short-circuit protection
- DC injection braking
- Automatic fault diagnostics
- Local keypad operation
- Remote PLC control
- Modbus RTU communication
Operating principle:
AC Power Supply → Rectifier → DC Link → Inverter Module → Variable Frequency AC Output → Motor
The inverter continuously monitors electrical and operating parameters, including voltage, current, frequency, temperature, and motor load. When abnormal operating conditions occur, integrated protection mechanisms automatically respond to safeguard both the inverter and the connected motor.
Role in Industrial Control Systems
The ATV12HU15M2 serves as the intelligent motor controller between industrial automation systems and electric motors.
Typical automation architecture includes:
- Schneider Modicon PLC
- Schneider Harmony HMI
- Altivar Frequency Inverter
- Circuit Breakers
- Magnetic Contactors
- Three-phase Induction Motors
- Industrial Sensors
- Pressure Transmitters
- Proximity Switches
- Emergency Stop Systems
- Modbus Communication Network
- SCADA Monitoring Software
The PLC calculates the required operating speed according to production conditions and transmits commands to the inverter through digital I/O or Modbus communication. The ATV12HU15M2 then adjusts the motor output frequency, enabling precise speed regulation and optimized production efficiency.
Industrial Applications
The Schneider ATV12HU15M2 is suitable for a broad range of industrial automation and machine control applications.
Common applications include:
- Conveyor systems
- Packaging machinery
- Pumps
- Fans
- HVAC equipment
- Water treatment systems
- Food processing machinery
- Textile machinery
- Printing equipment
- Material handling systems
- Compressors
- Mixers
- Filling machines
- Agricultural equipment
- OEM automation machinery
In pumping systems, the inverter adjusts motor speed according to flow demand, reducing energy consumption and extending pump life.
For conveyor systems, electronic speed control provides greater production flexibility while reducing mechanical wear.
Packaging equipment benefits from smooth acceleration and deceleration, improving production quality and minimizing mechanical shock.
Installation and System Integration
Proper installation is essential for achieving reliable performance and maximum equipment lifespan.
Recommended installation practices include:
- Install vertically inside a well-ventilated electrical enclosure.
- Maintain adequate clearance for airflow.
- Ensure correct protective grounding.
- Verify input power supply specifications before energizing.
- Separate power wiring from signal wiring.
- Use appropriately sized motor cables.
- Configure motor parameters according to the motor nameplate.
- Set suitable acceleration and deceleration times.
- Verify motor rotation during commissioning.
- Configure Modbus communication parameters when required.
- Test all protection functions before production startup.
- Monitor operating current and motor temperature during commissioning.
Correct parameter configuration improves motor efficiency and ensures stable long-term operation.
Compatible System Components
The ATV12HU15M2 integrates seamlessly with Schneider Electric automation products and compatible industrial equipment.
Typical compatible components include:
- Schneider Modicon PLC
- Schneider Harmony HMI
- Altivar Communication Modules
- Modbus RS-485 Devices
- Industrial Ethernet Gateways
- Motor Protection Circuit Breakers
- Contactors
- Three-phase AC Motors
- Emergency Stop Switches
- Proximity Sensors
- Pressure Sensors
- Industrial Control Panels
- Remote I/O Modules
- SCADA Systems
- Industrial Communication Modules
These components together provide a complete automation solution capable of intelligent motor control, process monitoring, and centralized equipment management.
Recommended Alternative Models
| Model | Type | Key Feature | Typical Application |
|---|---|---|---|
| ATV12H055M2 | Frequency Inverter | 0.55 kW Compact Drive | Small Industrial Equipment |
| ATV12H075M2 | Frequency Inverter | 0.75 kW Motor Control | Conveyors & Pumps |
| ATV12H075M3 | Frequency Inverter | Three-phase Input Version | Industrial Machinery |
| ATV12HU15M2 | Frequency Inverter | 1.5 kW General-purpose Drive | Manufacturing Automation |
| ATV12HU22M2 | Frequency Inverter | 2.2 kW Higher Power Output | Heavy-duty Machinery |
| ATV320U15M2C | Variable Speed Drive | Advanced Vector Control | Intelligent Automation Systems |
| ATV320U22M2C | Variable Speed Drive | Enhanced Communication | Modern Industrial Equipment |
The appropriate drive should always be selected according to motor power, supply voltage, overload requirements, environmental conditions, communication requirements, and overall automation architecture.
Key Advantages
- Compact Altivar 12 design
- 1.5 kW motor control capability
- Single-phase 200–240 VAC input
- Three-phase AC output
- Output frequency up to 400 Hz
- Smooth motor acceleration and deceleration
- Excellent energy-saving performance
- Built-in Modbus RTU communication
- Integrated RS-485 interface
- Comprehensive motor protection
- Automatic fault diagnostics
- Compact dimensions of 105 × 142 × 156.2 mm
- Lightweight 1.4 kg construction
- Easy installation and maintenance
- Suitable for pumps, fans, conveyors, compressors, packaging equipment, and industrial machinery
Technical FAQs
What is the Schneider ATV12HU15M2?
The Schneider ATV12HU15M2 is an Altivar 12 Variable Frequency Drive (VFD) designed to provide precise speed control for three-phase asynchronous motors used in industrial automation.
What is the rated motor power?
The inverter supports motors rated up to 1.5 kW (2 HP).
What are the dimensions?
The overall dimensions are 105 × 142 × 156.2 mm.
How much does the inverter weigh?
The ATV12HU15M2 weighs approximately 1.4 kg.
Which communication protocol does it support?
The inverter supports Modbus RTU communication through its integrated RS-485 interface.
What types of motors can it control?
It is designed to control standard three-phase asynchronous AC induction motors.
What protection functions are included?
The inverter provides overload, overcurrent, overvoltage, undervoltage, overheating, short-circuit, and motor thermal protection functions.
Where is the ATV12HU15M2 commonly used?
Typical applications include pumps, fans, conveyors, compressors, packaging equipment, HVAC systems, food processing, textile machinery, water treatment facilities, and general industrial automation.
Can it communicate with PLC systems?
Yes. The ATV12HU15M2 supports PLC integration through Modbus RTU communication or conventional digital control terminals, enabling centralized motor control within industrial automation systems.
Conclusion
The Schneider ATV12HU15M2 Frequency Inverter is a powerful 1.5 kW Altivar 12 Variable Frequency Drive designed for efficient and reliable motor control across a wide range of industrial automation applications. Combining precise speed regulation, comprehensive protection features, energy-efficient operation, and integrated Modbus communication, it provides an ideal solution for OEM equipment manufacturers, system integrators, and industrial maintenance professionals.
With compact dimensions of 105 × 142 × 156.2 mm and a weight of approximately 1.4 kg, the ATV12HU15M2 is well suited for space-limited control cabinets while delivering dependable long-term performance. Integrated with Schneider PLCs, HMIs, communication networks, and field devices, it forms a scalable and reliable motor control platform capable of supporting modern manufacturing and process automation systems.
