Product Overview The Schneider ATS48C17Q Soft Starter is an industrial motor-control device in the Altistart 48 family. It is designed for controlled starting and stopping of three-phase asynchronous mo……
Schneider ATS48C17Q Soft Starter
  • Schneider
  • ATS48C17Q
  • Soft Starter
  • France
  • 340 x 200 x 265 mm
  • 12.4 kg
  • Xiamen, China
  • New & In Stock
  • T/T, PayPal, Western Union
  • 1 Year
  • 1-3 Working Days
  • DHL, UPS, TNT, FedEx and EMS.
  • 24-Hour Service
  • COO
  • 8

Our advantage

Schneider ATS48C17Q Soft Starter

Global Logistics

We have a 10-year logistics and express cooperation agreement, so our products can be shipped to any place in the world.

Schneider ATS48C17Q Soft Starter

Brand new and original

Our products are imported in bulk from the place of origin. Because of the cooperative relationship, our products are all original and 100% new.

Schneider ATS48C17Q Soft Starter

24-hour service

We provide 7*24 hours service to our customers. We will be there whenever you need us.

Schneider ATS48C17Q Soft Starter

Price advantage

All our products are priced very favorably because we have our own warehouse and supply.


Company Information
E-mail [email protected]
Mobile +8615980777398
Whatsapp +8615980777398
WeChat 15980777398

Product Overview

The Schneider ATS48C17Q Soft Starter is an industrial motor-control device in the Altistart 48 family. It is designed for controlled starting and stopping of three-phase asynchronous motors used in industrial machinery, production equipment, and process systems.

A conventional direct-on-line starter applies the available supply directly to the motor, which can result in a high starting current and an abrupt increase in motor torque. The ATS48C17Q provides controlled motor acceleration to make the transition from standstill to operating speed more gradual.

This approach can reduce mechanical shock on connected equipment such as couplings, gearboxes, belts, pumps, fans, compressors, and conveyors. Depending on the application and configuration, controlled stopping can also be used where a gradual reduction in motor operation is desirable.

The ATS48C17Q can be integrated into industrial automation systems through its communication capability, allowing it to work alongside PLCs, HMIs, DCS systems, and other control equipment.

The specified physical dimensions are 340 × 200 × 265 mm, with a weight of 12.4 kg.


Product Identification

Parameter Specification
Manufacturer Schneider Electric
Product Family Altistart 48
Model ATS48C17Q
Product Type Soft Starter
Motor Type Three-Phase Asynchronous Motor
Main Function Controlled Motor Starting and Stopping
Communication Modbus
Communication Interface RS-485
Installation Orientation Vertical
Dimensions 340 × 200 × 265 mm
Weight 12.4 kg
Cooling Forced Air
Typical Applications Pumps, Fans, Compressors, Conveyors, Mixers
Automation Integration PLC / HMI / DCS

Technical Specifications

Technical Item ATS48C17Q
Manufacturer Schneider Electric
Series Altistart 48
Model ATS48C17Q
Product Category Motor Soft Starter
Application Three-Phase Asynchronous Motor Control
Primary Function Controlled Starting and Stopping
Communication Modbus
Physical Communication RS-485
Mounting Vertical
Height 340 mm
Width 200 mm
Depth 265 mm
Weight 12.4 kg
Cooling Method Forced Air
Typical Load Types Pumps, Fans, Compressors, Conveyors, Mixers
Control Architecture PLC / HMI / DCS / Industrial Automation

The ATS48C17Q is intended to be installed as part of a properly engineered motor-control system. The final application should always consider the actual motor rating, operating duty, starting frequency, load characteristics, and environmental conditions.


Understanding the ATS48C17Q

The ATS48C17Q is positioned between the electrical supply and the motor within a motor-control installation.

A simplified architecture is:

Three-Phase Power Supply

Protection and Isolation

ATS48C17Q Soft Starter

Three-Phase Motor

Mechanical Load

During startup, the soft starter controls the motor’s acceleration rather than allowing an uncontrolled direct connection to full operating conditions.

This can provide several practical benefits:

  • Reduced mechanical shock
  • Smoother motor acceleration
  • Reduced stress on transmission components
  • Improved starting behavior
  • Reduced process disturbance
  • Controlled stopping when required
  • Integration with industrial control systems

Working Principle

When a motor is started directly, the initial electrical demand can be considerably higher than its normal running condition. At the same time, the motor can generate a rapid torque increase.

The ATS48C17Q manages the startup sequence through controlled power switching.

The general process is:

Start Command

Soft-Start Sequence

Controlled Motor Acceleration

Normal Running

Stop Command

Controlled Stop Sequence

The exact configuration should be established according to the motor and mechanical load.


Core Functions

Controlled Starting

Controlled acceleration is the primary function of the ATS48C17Q.

A gradual starting process can be useful when direct-on-line starting causes:

  • Mechanical shock
  • Belt movement
  • Coupling stress
  • Gearbox impact
  • Pipeline disturbances
  • Excessive process vibration

Controlled Stopping

Some applications require more than simply removing motor power.

Controlled stopping can be useful for selected:

  • Pump systems
  • Conveyor systems
  • Fans
  • High-inertia machinery
  • Process equipment

The appropriate stop mode should be selected according to the machine’s mechanical and process requirements.


Motor Monitoring and Protection

The Altistart 48 platform provides functions intended to monitor motor and starter operating conditions.

Potential abnormal conditions can include:

  • Excessive current
  • Motor thermal stress
  • Starter temperature problems
  • Phase-related problems
  • Abnormal starting behavior

Protection settings should be configured based on the actual motor nameplate and application requirements.


Industrial Applications

Pump Applications

Pumps are among the common applications where controlled motor starting can be valuable.

Potential applications include:

  • Water circulation
  • Cooling systems
  • Industrial process pumps
  • Transfer pumps
  • Water treatment
  • Wastewater systems

A controlled start can help reduce sudden mechanical and fluid-system changes.


Fan and Blower Systems

Large fans and blowers may have considerable rotating inertia.

Typical applications include:

  • Industrial ventilation
  • Exhaust equipment
  • Cooling systems
  • Dust collection
  • Air-handling equipment
  • Process ventilation

The ATS48C17Q can provide controlled acceleration for suitable motor and fan combinations.


Compressor Applications

Compressors can impose significant starting requirements on their motors.

Before selecting or configuring the ATS48C17Q for a compressor, engineers should evaluate:

  • Motor current
  • Compressor load
  • Starting time
  • Starting frequency
  • Ambient temperature
  • Mechanical resistance
  • Operating cycle

Conveyor Systems

Conveyors can experience mechanical shock when large motors start abruptly.

Controlled acceleration can help reduce stress on:

  • Belts
  • Couplings
  • Gearboxes
  • Shafts
  • Drive components

It can also help reduce sudden movement of the conveyed material.


Mixer Systems

Mixers can present high starting resistance, especially when handling dense or viscous materials.

Controlled motor acceleration can provide a more gradual transition from stationary operation to the normal process speed.


Industrial Processing Machinery

Other possible applications include:

  • Blowers
  • Material-handling machines
  • Rotating process equipment
  • Industrial ventilation
  • Production machinery
  • Mechanical drive systems

Application suitability must be evaluated using the actual motor and load characteristics.


Installation Guide

1. Confirm the Product

Before installation, verify the identification:

Schneider ATS48C17Q

Inspect the unit for visible damage.

Check for:

  • Cracks
  • Damaged terminals
  • Bent mounting points
  • Loose components
  • Moisture
  • Dust contamination
  • Discoloration
  • Signs of overheating

Any damaged equipment should be evaluated before installation.


2. Collect Motor Nameplate Data

Before configuration, record the motor’s actual:

  • Rated voltage
  • Rated current
  • Rated frequency
  • Rated power
  • Connection type
  • Speed
  • Duty
  • Starting characteristics

The ATS48C17Q should be matched to the motor and application rather than selected only by physical size.


3. Design the Control Cabinet

The specified ATS48C17Q dimensions are:

340 × 200 × 265 mm

The cabinet must provide more than the exact physical footprint.

Allow space for:

  • Power cables
  • Control wiring
  • Communication wiring
  • Cable bending
  • Ventilation
  • Protective components
  • Maintenance
  • Inspection

The surrounding components should not obstruct the soft starter’s cooling path.


4. Mounting Position

The ATS48C17Q should be mounted in the recommended vertical orientation.

Confirm:

  • Panel strength
  • Correct orientation
  • Stable mounting
  • Ventilation clearance
  • Cable accessibility
  • Maintenance access

The unit weighs 12.4 kg, so the mounting structure must safely support the equipment.


5. Environmental Preparation

The enclosure should provide appropriate protection against industrial environmental conditions.

Avoid installation where the equipment is directly exposed to:

  • Water
  • Condensation
  • Excessive dust
  • Conductive particles
  • Oil mist
  • Corrosive substances
  • Excessive vibration
  • Excessive heat

Adequate cabinet cooling is essential for reliable operation.


6. Isolate Electrical Power

Before wiring:

  1. Disconnect all relevant power sources.
  2. Apply lockout/tagout procedures.
  3. Verify absence of hazardous voltage.
  4. Isolate the motor.
  5. Check for stored energy.
  6. Confirm the work area is safe.
  7. Wear appropriate electrical PPE.

Never perform power-terminal work on an energized system.


7. Power Circuit Installation

Connect the incoming three-phase supply and motor circuit according to the engineered electrical design.

Inspect:

  • Phase connections
  • Cable sizing
  • Protective devices
  • Grounding
  • Terminal connections
  • Cable insulation
  • Cable routing

Perform a complete visual inspection before energization.


8. Control Circuit Installation

The control circuit may include:

  • Start command
  • Stop command
  • Reset
  • Run status
  • Fault indication
  • External interlocks
  • PLC control
  • Emergency-stop logic

Control wiring should be organized to reduce interference from high-current power conductors.


9. Communication Installation

The ATS48C17Q can be integrated into an automation network using its communication capability.

A typical arrangement is:

PLC

RS-485 / Modbus

ATS48C17Q

Motor

Before commissioning, check:

  • Network wiring
  • Device address
  • Communication parameters
  • PLC configuration
  • Network topology
  • Control permissions

10. Parameter Configuration

Enter the actual motor information into the soft starter.

Important parameters can include:

  • Motor rated current
  • Starting parameters
  • Acceleration time
  • Deceleration time
  • Current limitation
  • Protection settings
  • Stop mode
  • Command source

Avoid copying parameters from an unrelated machine.


11. Mechanical Inspection

Before the first motor start, inspect the complete mechanical system.

Check:

  • Motor shaft
  • Coupling
  • Bearings
  • Gearbox
  • Belts
  • Pump
  • Fan
  • Conveyor
  • Mechanical guards

Verify that the motor can rotate without unexpected resistance.


Commissioning Procedure

Pre-Energization Checklist

Before applying power:

  1. Confirm the ATS48C17Q model.
  2. Verify motor nameplate information.
  3. Inspect power wiring.
  4. Inspect control wiring.
  5. Verify grounding.
  6. Check protective equipment.
  7. Check cabinet ventilation.
  8. Verify starter parameters.
  9. Test interlocks.
  10. Check emergency-stop functions.

Initial Energization

After completing the inspection:

  1. Energize the control system.
  2. Observe the soft-starter status.
  3. Check for faults.
  4. Verify control inputs.
  5. Confirm communication if used.
  6. Confirm the correct operating mode.

Do not immediately place the motor under full process load if commissioning conditions allow a controlled initial test.


First Motor Start

Perform the first start under controlled conditions.

Monitor:

  • Starting current
  • Acceleration time
  • Motor sound
  • Vibration
  • Starter status
  • Motor rotation
  • Mechanical movement
  • Process response

If abnormal conditions appear, stop the motor and investigate.


Troubleshooting Guide

Problem 1 – No Power or No Status

Possible Causes

  • Incoming power unavailable
  • Open circuit protection
  • Incorrect power wiring
  • Control circuit problem
  • Internal equipment fault

Checks

Verify:

  1. Incoming supply
  2. Protective devices
  3. Power wiring
  4. Control circuit
  5. Starter status

Problem 2 – Start Command Is Present but Motor Does Not Run

Possible Causes

  • Incorrect control wiring
  • Active interlock
  • Incorrect command source
  • Incorrect configuration
  • Motor circuit problem
  • Mechanical obstruction

Diagnostic Approach

Trace the command from the PLC or control device to the ATS48C17Q.

Then verify the motor power circuit and mechanical load.


Problem 3 – Motor Accelerates Too Slowly

Possible Causes

  • Acceleration time configured too long
  • Current limitation too restrictive
  • Incorrect motor data
  • Excessive load
  • Mechanical resistance

Corrective Action

Verify motor parameters and starting settings.

Then inspect the mechanical load.


Problem 4 – Excessive Starting Current

Possible Causes

  • Acceleration time too short
  • Current limitation incorrectly configured
  • Heavy mechanical load
  • Incorrect motor configuration
  • Motor condition

Compare the configured motor information with the actual motor nameplate.


Problem 5 – Starter Trips During Startup

Possible Causes

  • Motor overload
  • Phase problem
  • Incorrect wiring
  • Incorrect parameters
  • Mechanical obstruction
  • Excessive load

Do not repeatedly reset the fault without finding the underlying cause.


Problem 6 – ATS48C17Q Overheats

Possible Causes

  • Insufficient cabinet ventilation
  • Blocked airflow
  • High ambient temperature
  • Excessive starting frequency
  • Motor overload
  • Dust accumulation
  • Cooling problem

Corrective Action

Inspect the complete cabinet cooling system.

Check whether airflow is restricted and whether another device is introducing excessive heat.


Problem 7 – Motor Vibrates During Startup

Possible Causes

  • Shaft misalignment
  • Coupling problem
  • Bearing wear
  • Mechanical imbalance
  • Incorrect acceleration profile
  • Resonance

Investigate both the motor-control system and the connected machinery.


Problem 8 – Motor Stops Abruptly

Possible Causes

  • Incorrect stop mode
  • External stop command
  • Incorrect deceleration setting
  • PLC logic issue
  • High-inertia load

Review the complete stopping sequence.


Problem 9 – Motor Does Not Stop

Possible Causes

  • Stop command missing
  • Control wiring problem
  • PLC logic error
  • External interlock
  • Incorrect configuration

Trace the stop command from the controller to the starter.


Problem 10 – Communication Failure

Possible Causes

  • Incorrect Modbus address
  • Incorrect serial parameters
  • RS-485 wiring problem
  • PLC configuration problem
  • Network topology issue
  • Communication interface fault

Diagnostic Sequence

First inspect the physical communication wiring.

Then verify:

  • Device address
  • Communication speed
  • Serial configuration
  • PLC settings
  • Network connections

Problem 11 – Repeated Overload Faults

Possible Causes

  • Excessive mechanical load
  • Bearing deterioration
  • Mechanical obstruction
  • Incorrect motor parameters
  • Excessive starting frequency
  • Incorrect protection settings
  • Process overload

Repeated overload faults should be investigated as a complete motor-and-load system.


Diagnostic Decision Process

A structured troubleshooting sequence can be used:

Power Supply

Protection

ATS48C17Q Status

Control Commands

Communication

Power Wiring

Motor

Mechanical Load

Parameters

Restart Test

This sequence helps technicians distinguish between power, control, communication, motor, configuration, and mechanical faults.


Preventive Maintenance

Electrical Inspection

Inspect periodically:

  • Power terminals
  • Control terminals
  • Grounding
  • Cable insulation
  • Signs of heating
  • Loose connections

Cooling Inspection

Check:

  • Ventilation
  • Airflow
  • Cooling passages
  • Cabinet filters
  • Dust accumulation
  • Ambient temperature

Mechanical Inspection

Check:

  • Mounting hardware
  • Cable supports
  • Motor alignment
  • Couplings
  • Bearings
  • Gearboxes
  • Vibration

Operating Condition Monitoring

Monitor:

  • Motor current
  • Starting duration
  • Starter temperature
  • Fault history
  • Starting frequency
  • Motor vibration
  • Abnormal noise

Changes in these values can provide early warning of developing problems.


Preventive Maintenance Table

Inspection Area Recommended Action
Power Terminals Inspect tightness and heating
Control Terminals Check connection integrity
Grounding Verify continuity
Communication Inspect RS-485 wiring
Cooling Clean and inspect airflow paths
Cabinet Ventilation Keep airflow unobstructed
Filters Clean or replace when required
Motor Current Monitor operating values
Fault History Review periodically
Mounting Check mechanical stability
Cables Inspect insulation and routing
Cabinet Remove dust and contamination
Motor / Load Check vibration and alignment

Common Installation Errors

Wrong Motor Information

Incorrect motor parameters can lead to abnormal acceleration, unnecessary trips, or poor motor performance.

Poor Cabinet Ventilation

Insufficient airflow can cause unnecessary thermal stress.

Insufficient Mounting Support

The ATS48C17Q weighs 12.4 kg, so the cabinet mounting structure must be mechanically adequate.

Loose Connections

Loose electrical connections can produce heat, intermittent faults, and voltage problems.

Incorrect Control Logic

A missing start signal or active interlock can prevent motor operation even when the soft starter is functioning correctly.

Incorrect Communication Parameters

Incorrect addressing or serial settings can prevent communication with a PLC.

Mechanical Load Problems

A blocked pump, overloaded conveyor, damaged bearing, or tight gearbox can cause symptoms that appear to be electrical faults.

Repeated Resetting

Resetting the starter repeatedly without correcting the cause can increase downtime and equipment stress.


Automation System Integration

The ATS48C17Q can form part of an industrial motor-control architecture.

A representative configuration is:

PLC / DCS

Control Commands

ATS48C17Q

Motor

Industrial Machine

Process

The communication interface can support integration into supervisory and control architectures where motor status and available diagnostic information need to be exchanged with the automation system.

Possible functions include:

  • Remote motor starting
  • Remote stopping
  • Fault monitoring
  • Status monitoring
  • Alarm management
  • Interlocking
  • Diagnostic monitoring

Supporting Equipment

An ATS48C17Q installation may be accompanied by:

  • Circuit breakers
  • Disconnect devices
  • Fuses
  • Contactors
  • Motor protection equipment
  • PLC controllers
  • HMIs
  • Control relays
  • RS-485 network components
  • Emergency-stop circuits
  • Motor sensors
  • Process sensors

The complete system must be engineered around the actual motor, supply, load, protection requirements, and application duty.


Related Altistart 48 Models

Model Typical Position in Product Range
ATS48C11Q Higher-current industrial motor control
ATS48C14Q Larger industrial motor applications
ATS48C17Q Higher-power industrial motor applications
ATS48C21Q Larger motor-control applications
ATS48C25Q Higher-current industrial applications
ATS48C32Q High-power motor applications

Model selection should be based on the motor’s actual current, voltage, starting duty, load characteristics, environmental conditions, and control requirements.


Key Advantages

  • Altistart 48 industrial soft-starter platform
  • Controlled motor acceleration
  • Controlled motor stopping
  • Three-phase asynchronous motor applications
  • Motor protection functions
  • Starter monitoring and protection
  • Modbus communication capability
  • RS-485 industrial communication
  • PLC and DCS integration
  • Suitable for pumps
  • Suitable for fans and blowers
  • Suitable for compressors
  • Suitable for conveyors
  • Suitable for mixers
  • Forced-air cooling
  • Vertical installation
  • Dimensions: 340 × 200 × 265 mm
  • Weight: 12.4 kg

Technical FAQs

What is the Schneider ATS48C17Q?

The Schneider ATS48C17Q is an Altistart 48 industrial soft starter designed for controlled starting and stopping of three-phase asynchronous motors.

What are the dimensions of the ATS48C17Q?

The specified dimensions are 340 × 200 × 265 mm.

What is the weight of the ATS48C17Q?

The specified weight is 12.4 kg.

What is the purpose of the ATS48C17Q?

Its primary purpose is to provide controlled motor starting and stopping while providing monitoring and protection functions for industrial motor applications.

Where can the ATS48C17Q be used?

Typical applications include pumps, fans, compressors, conveyors, blowers, mixers, and other industrial motor-driven machinery.

Can the ATS48C17Q communicate with a PLC?

Yes. The ATS48 platform supports Modbus communication through an RS-485-based industrial network, allowing suitable PLC systems to integrate the soft starter into a control architecture.

Why does the motor fail to start?

Possible causes include missing start commands, active interlocks, incorrect configuration, wiring problems, motor faults, or excessive mechanical resistance.

Why does the soft starter overheat?

Common causes include inadequate ventilation, blocked airflow, high ambient temperature, excessive starting frequency, motor overload, and contamination.

Why does the starter trip during acceleration?

Possible causes include excessive load, incorrect motor parameters, phase-related problems, unsuitable starting settings, wiring faults, or mechanical obstruction.

What should be inspected before commissioning?

Verify the motor nameplate, power circuit, control wiring, grounding, protective devices, cabinet ventilation, communication configuration, soft-starter parameters, and mechanical load.

How can repeated faults be diagnosed?

Start with the incoming power and protective circuit, then inspect the ATS48C17Q status, control commands, communication, motor circuit, motor condition, configuration, and mechanical load. This prevents unnecessary replacement of a functioning soft starter.


Conclusion

The Schneider ATS48C17Q Soft Starter provides controlled starting and stopping for industrial three-phase asynchronous motor applications. It is particularly useful where direct motor starting could produce excessive mechanical shock, high starting demand, or undesirable process disturbances.

The specified ATS48C17Q measures 340 × 200 × 265 mm and weighs 12.4 kg. These dimensions and weight should be considered when designing the electrical cabinet, mounting structure, cable routing, ventilation system, and maintenance access.

Reliable operation depends on correct motor selection, accurate configuration, appropriate electrical protection, sound wiring practices, adequate cooling, and careful commissioning.

When troubleshooting, technicians should diagnose the complete system rather than assuming that a fault indication automatically means the soft starter itself has failed. Checking the supply, protection, control signals, communication, motor, parameters, and mechanical load in sequence provides a more reliable approach to fault identification.

With proper installation, commissioning, preventive maintenance, and systematic troubleshooting, the ATS48C17Q can be integrated effectively into industrial motor-control and automation systems.



Related Products

Get the latest price? We will reply as soon as possible (within 12 hours)

No:77501
