Product Overview
The Schneider ATS22D62S6 Soft Starter is a reliable motor control device from the Schneider Electric Altistart 22 (ATS22) series, developed to provide smooth starting and stopping for three-phase induction motors used in industrial automation systems. By controlling the motor voltage during acceleration and deceleration, the soft starter reduces electrical inrush current while protecting both the motor and connected mechanical equipment from excessive stress.
Instead of applying full voltage immediately like a conventional direct-on-line starter, the ATS22D62S6 gradually increases motor voltage during startup. This significantly reduces torque shock, minimizes wear on transmission components, and improves the overall reliability of pumps, conveyors, compressors, fans, and other rotating machinery.
As part of the Altistart 22 family, this soft starter is widely used in manufacturing facilities, water treatment plants, HVAC installations, mining operations, and process industries where dependable motor starting is essential.
With compact dimensions of 295 × 145 × 207 mm and a weight of approximately 12 kg, the ATS22D62S6 is designed for installation inside industrial control cabinets and motor control centers while maintaining excellent accessibility for maintenance and servicing.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Product Series | Altistart 22 (ATS22) |
| Model | ATS22D62S6 |
| Product Type | Soft Starter |
| Motor Type | Three-Phase AC Induction Motor |
| Primary Function | Controlled Motor Starting and Stopping |
| Starting Method | Soft Start |
| Stopping Method | Soft Stop |
| Control Technology | Solid-State Thyristor Control |
| Installation | Panel Mounted |
| Cooling Method | Air Cooling |
| Mounting Position | Vertical Installation |
| Application | Industrial Motor Control |
| Dimensions | 295 × 145 × 207 mm |
| Weight | 12 kg |
Function and Working Principle
The ATS22D62S6 controls motor acceleration by gradually increasing the voltage delivered to the motor windings. Rather than exposing the motor to a sudden surge of current, the soft starter allows the motor to reach operating speed progressively.
The operating sequence can be simplified as:
Power Supply
↓
ATS22D62S6 Soft Starter
↓
Three-Phase Motor
↓
Industrial Equipment
During startup, semiconductor devices regulate the output voltage according to preset acceleration parameters. This allows the motor torque to build smoothly while limiting starting current.
When the motor reaches normal operating speed, the motor continues running under full supply conditions according to the system configuration.
During stopping, the soft starter gradually reduces voltage, allowing controlled deceleration and reducing mechanical impact on the driven equipment.
Role in Industrial Automation Systems
Within an industrial control system, the ATS22D62S6 functions as the motor starting interface between the electrical distribution system and the motor.
A typical control architecture includes:
Power Distribution
↓
Circuit Breaker
↓
ATS22D62S6 Soft Starter
↓
Three-Phase Motor
↓
Industrial Machine
The PLC determines when the motor should start or stop, while the soft starter manages acceleration and deceleration to protect both electrical and mechanical systems.
This arrangement improves equipment reliability while reducing maintenance requirements.
Industrial Applications
The Schneider ATS22D62S6 is suitable for numerous industrial applications, including:
- Water treatment plants
- Wastewater processing
- Pumping stations
- HVAC systems
- Cooling towers
- Industrial fans
- Air compressors
- Screw compressors
- Conveyor systems
- Material handling equipment
- Packaging machinery
- Food processing equipment
- Chemical production
- Mining equipment
- Cement plants
- Steel processing
- Textile machinery
- Paper manufacturing
- General factory automation
Its smooth starting capability makes it especially valuable for equipment with large rotating masses or frequent startup cycles.
Motor Starting Advantages
Compared with conventional direct-on-line motor starting, the ATS22D62S6 provides several important operational benefits.
These include:
- Reduced starting current
- Smooth motor acceleration
- Lower mechanical stress
- Reduced gearbox wear
- Longer bearing life
- Improved belt protection
- Reduced hydraulic shock in pump systems
- Lower maintenance costs
- Improved production stability
- Extended equipment service life
These advantages contribute to greater system reliability and lower operating costs.
Installation and System Integration
Proper installation is essential for safe and reliable operation.
Mechanical Installation
Before installation, verify:
- Correct model number
- Sufficient cabinet space
- Proper ventilation
- Secure panel mounting
- Vertical installation
- Adequate wiring clearance
The unit dimensions of 295 × 145 × 207 mm should be considered during cabinet design to ensure proper airflow and maintenance access.
Electrical Connections
Typical connections include:
- Three-phase power supply
- Motor output terminals
- Protective grounding
- Control wiring
- PLC control signals
- Motor protection devices
Power cables and control cables should be routed separately whenever practical to reduce electrical interference.
Commissioning Procedure
A recommended commissioning sequence includes:
- Install the ATS22D62S6.
- Verify mechanical installation.
- Check all power connections.
- Inspect motor wiring.
- Verify grounding.
- Configure startup parameters.
- Configure stopping parameters.
- Energize the control system.
- Perform a no-load startup.
- Verify motor acceleration.
- Perform a full-load operational test.
- Confirm stable system performance.
Compatible System Components
The ATS22D62S6 is commonly integrated with the following industrial automation products.
| Component | Function |
|---|---|
| Schneider PLC Controller | Executes motor control logic |
| Human Machine Interface (HMI) | Operator monitoring and control |
| Motor Circuit Breaker | Short-circuit protection |
| Contactor | Motor isolation |
| Thermal Overload Relay | Overload protection |
| Three-Phase Induction Motor | Driven equipment |
| Industrial Power Supply | Control power |
| Ethernet Communication Module | Industrial networking |
| Modbus Communication Module | PLC communication |
| Industrial Sensors | Process feedback |
| Encoder | Speed monitoring |
| Motor Control Center (MCC) | Central motor management |
These components create a complete motor control solution for industrial automation systems.
Typical Application Example
Pumping System
A pump system often experiences hydraulic shock when started directly.
Using the ATS22D62S6:
PLC
↓
Soft Starter
↓
Motor
↓
Pump
↓
Stable Water Flow
The controlled acceleration reduces pressure surges and protects valves, pipelines and pump assemblies.
Conveyor System
For conveyor equipment, smooth acceleration minimizes:
- Belt slippage
- Product movement
- Mechanical shock
- Gearbox loading
- Bearing wear
This improves production efficiency and extends equipment lifespan.
Maintenance and Troubleshooting
Routine maintenance should include:
- Inspect terminal connections.
- Verify cooling airflow.
- Remove accumulated dust.
- Check cable insulation.
- Inspect grounding.
- Verify motor current.
- Test control wiring.
- Review operating parameters.
Regular preventive maintenance helps maximize equipment reliability.
Common Fault Conditions
| Symptom | Possible Cause |
|---|---|
| Motor fails to start | Power supply or control wiring |
| Excessive starting current | Incorrect startup settings |
| Frequent trips | Motor overload or improper configuration |
| Motor overheats | Poor ventilation or excessive load |
| Unexpected shutdown | External protection circuit |
| Abnormal acceleration | Parameter configuration |
| Communication fault | Control wiring issue |
| Equipment vibration | Mechanical load problem |
Recommended Alternative Models
| Model | Product Type | Main Feature | Typical Application |
|---|---|---|---|
| ATS22D47S6 | Soft Starter | Compact motor control | Pumps and fans |
| ATS22D75S6 | Soft Starter | Higher motor capacity | Heavy conveyors |
| ATS22C11Q | Soft Starter | Heavy-duty motor starting | Process industries |
| ATS22C17Q | Soft Starter | Large motor control | Mining equipment |
| ATS48C14Q | Soft Starter | Advanced motor protection | Heavy industrial applications |
| ATS48C17Q | Soft Starter | High-performance starting | Large motors |
| ATV630 | Variable Frequency Drive | Variable speed control | Pump systems |
| ATV650 | Variable Frequency Drive | Process automation | Industrial plants |
| ATV340 | Variable Frequency Drive | Machine automation | OEM equipment |
Key Advantages
- Designed for Schneider Altistart 22 motor control systems
- Smooth motor acceleration and deceleration
- Reduces electrical inrush current
- Minimizes mechanical stress
- Improves motor reliability
- Protects pumps and conveyors
- Reduces equipment maintenance
- Suitable for continuous industrial operation
- Compact industrial construction
- Easy PLC integration
- Suitable for OEM and process automation
- Dimensions: 295 × 145 × 207 mm
- Weight: 12 kg
Technical FAQs
What is the Schneider ATS22D62S6?
The ATS22D62S6 is an industrial soft starter designed to provide controlled starting and stopping for three-phase AC induction motors.
What is its primary function?
Its primary function is to reduce motor starting current while minimizing mechanical shock during startup and stopping.
What are the dimensions?
The unit measures 295 × 145 × 207 mm.
What is the weight?
The specified weight is approximately 12 kg.
Is it a Variable Frequency Drive?
No. It is a soft starter designed for motor acceleration and deceleration rather than continuous speed regulation.
What types of motors are supported?
It is intended for three-phase AC induction motors used in industrial automation.
Where is it typically installed?
It is commonly installed inside industrial control cabinets or motor control centers.
Can it be used for pump applications?
Yes. It is well suited for pumping systems where controlled acceleration helps reduce hydraulic shock.
Can it be used for conveyor systems?
Yes. Smooth acceleration reduces belt slippage and mechanical stress on conveyor equipment.
What should be checked before replacement?
Verify motor specifications, wiring configuration, cabinet space, protection devices, PLC control logic and application requirements before replacing the unit.
Conclusion
The Schneider ATS22D62S6 Soft Starter is a dependable motor control solution designed to improve the startup and stopping performance of three-phase induction motors in industrial automation systems. By providing controlled acceleration and deceleration, it reduces electrical stress, minimizes mechanical wear and enhances the long-term reliability of motors and driven equipment.
With dimensions of 295 × 145 × 207 mm and a weight of approximately 12 kg, the ATS22D62S6 is suitable for installation in industrial control cabinets, motor control centers and OEM machinery. It is widely applied in pumps, compressors, conveyors, HVAC systems and other constant-speed motor applications.
Integrated with PLC controllers, protection devices and industrial communication systems, the Schneider ATS22D62S6 provides an efficient and reliable motor starting solution that supports stable operation, lower maintenance costs and improved equipment longevity.
