Product Overview
The Schneider 172JNN21032 Serial Link Option Adapter is a compact communication interface component designed to support serial communication within industrial automation and control systems. With its compact dimensions and low weight, this adapter can be integrated into compatible Schneider automation architectures where reliable serial data exchange is required.
Serial communication remains important in many industrial installations, particularly in systems containing controllers, remote I/O devices, intelligent instruments, operator interfaces, drives, and other field-level equipment. The 172JNN21032 provides an interface between compatible automation equipment and serial communication networks, allowing operating data, status information, configuration parameters, and diagnostic information to be exchanged.
The adapter is particularly useful in automation installations where additional serial communication functionality is required without replacing the complete control system. Its compact design also makes it suitable for applications where cabinet space is limited.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model | 172JNN21032 |
| Product Type | Serial Link Option Adapter |
| Communication Function | Serial communication interface |
| Application | Industrial automation and control communication |
| Dimensions | 25 × 143.1 × 60.06 mm |
| Weight | 0.085 kg |
| Installation | Control system / cabinet integration |
| Interface Type | Serial communication |
| Product Category | Communication accessory / option adapter |
| Typical Application | Industrial control and serial device communication |
Function and Working Principle
The main purpose of the Schneider 172JNN21032 Serial Link Option Adapter is to provide serial communication functionality within a compatible industrial automation system.
In an industrial control architecture, controllers need to exchange information with different types of equipment. Depending on the application, these devices may include remote I/O modules, intelligent field instruments, operator interfaces, motor drives, monitoring equipment, or other controllers.
The general communication path can be represented as:
Controller or Automation Device → 172JNN21032 Serial Link Adapter → Serial Communication Network → Connected Device
The adapter provides the communication interface required for data exchange between the automation system and compatible serial devices.
Typical information exchanged through an industrial serial communication system may include:
- Device status
- Process values
- Operating parameters
- Alarm information
- Diagnostic information
- Control commands
- Configuration data
- Maintenance information
The exact communication protocol and electrical interface depend on the Schneider automation platform and the equipment connected to the adapter. Therefore, the complete system configuration should be verified before installation or replacement.
Role in Industrial Control Systems
The 172JNN21032 can serve as an important communication accessory within an industrial automation architecture. Modern control systems often contain multiple levels, including controllers, field devices, monitoring equipment, and operator interfaces.
A serial communication adapter helps provide the connection between the control system and compatible serial devices, allowing information to move between different parts of the automation system.
The adapter may support communication involving:
- PLC and industrial controllers
- Remote automation devices
- Serial field devices
- Operator interfaces
- Intelligent instruments
- Industrial drives
- Monitoring systems
- Legacy automation equipment
This type of communication interface can be particularly valuable in existing automation systems where serial communication equipment remains in operation. Instead of replacing an entire control architecture, a suitable communication interface can help maintain communication with existing equipment.
Industrial Applications
The Schneider 172JNN21032 can be used in compatible industrial automation applications where serial communication is required between controllers and field-level equipment.
Factory Automation
Manufacturing systems often contain PLCs, drives, operator terminals, monitoring devices, and intelligent equipment that need to exchange operating information. Serial communication can provide a practical connection method for compatible devices.
Machine Control
Industrial machines may contain multiple control and monitoring components. The 172JNN21032 can help integrate compatible serial devices into the machine control architecture.
Process Automation
Process control systems can contain distributed instruments and automation equipment. Serial communication allows compatible devices to exchange measurements, status information, parameters, and diagnostic information.
Legacy Automation Systems
Serial interfaces remain common in older industrial equipment. The use of a suitable serial communication adapter can help extend the useful life of an existing automation system while reducing the need for a complete control-system replacement.
Industrial Monitoring
Serial communication can also be used to collect operating information from compatible devices for monitoring, maintenance, and diagnostic purposes.
Installation and System Integration
Correct installation is important for stable serial communication. Before installing the 172JNN21032, technicians should confirm that the adapter is designed for the target Schneider automation platform and that the required communication interface is supported.
1. Verify the System Configuration
Confirm the controller, rack, communication architecture, and designated option interface before installation.
2. Check the Product Identification
Verify the complete product number:
Schneider 172JNN21032
The model number should be compared with the original adapter and system documentation before replacement.
3. Install the Adapter
Install the adapter in its designated position and secure it correctly. Although the unit weighs only approximately 0.085 kg, correct mechanical installation is still important for reliable long-term operation.
4. Connect the Communication Cable
Connect the serial communication cable according to the applicable Schneider system configuration. Communication cables should be routed carefully and kept away from unnecessary sources of electromagnetic interference.
5. Configure Communication Parameters
Depending on the connected equipment, communication parameters such as addressing, transmission speed, data format, and other network settings may need to be configured.
6. Test Communication
After installation, communication should be tested before the system returns to normal production. Verify device recognition, stable data transmission, diagnostic information, and communication status.
Compatible System Components
The 172JNN21032 should be considered as part of a complete automation architecture rather than an independent controller.
| Component Type | Typical Function |
|---|---|
| Schneider PLC / Controller | Executes control logic and manages automation processes |
| Serial Communication Devices | Exchange process and diagnostic information |
| Remote I/O | Provides distributed field inputs and outputs |
| Operator Interface | Displays process information and accepts operator commands |
| Industrial Drives | Provides motor control and operating-status information |
| Communication Cables | Provides the physical serial communication connection |
| Power Supply | Supplies power to the automation equipment |
| Control Cabinet | Provides mechanical and environmental protection |
Recommended Alternative Models
When replacing or expanding a serial communication architecture, related Schneider communication products may be considered depending on the system requirements. These products should not be regarded as automatic drop-in replacements for the 172JNN21032. Compatibility must be confirmed according to the controller, communication protocol, electrical interface, mounting arrangement, and software configuration.
| Model / Series | Type | Key Feature | Application |
|---|---|---|---|
| 172JNN21032 | Serial Link Option Adapter | Compact serial communication interface | Compatible Schneider automation systems |
| Schneider 170 Series Communication Modules | Communication Module | Distributed communication capability | Industrial automation systems |
| Schneider Modicon Serial Communication Modules | Serial Interface | Serial device integration | PLC and field-device communication |
| Schneider Modicon Ethernet Communication Modules | Ethernet Communication Module | Higher-speed industrial networking | Modern industrial control networks |
| Schneider Modbus Communication Interfaces | Communication Interface | Industrial device connectivity | PLC, drives, meters, and field devices |
Key Advantages
- Compact dimensions of 25 × 143.1 × 60.06 mm
- Low weight of approximately 0.085 kg
- Provides serial communication functionality
- Suitable for compatible Schneider automation systems
- Supports communication between control equipment and serial devices
- Useful for established and legacy serial communication architectures
- Can extend communication capabilities without replacing an entire control system
- Suitable for industrial control and monitoring applications
- Practical for space-constrained control cabinets
Technical FAQs
What is the Schneider 172JNN21032?
The Schneider 172JNN21032 is a Serial Link Option Adapter designed to provide serial communication functionality within compatible Schneider industrial automation systems.
What is the main function of 172JNN21032?
Its main function is to provide an interface for serial communication, allowing compatible automation equipment to exchange data with connected serial devices.
What are the dimensions of Schneider 172JNN21032?
The listed dimensions are 25 × 143.1 × 60.06 mm.
How much does the 172JNN21032 weigh?
The listed weight is approximately 0.085 kg, equivalent to approximately 85 grams.
Is 172JNN21032 a PLC?
No. The 172JNN21032 is a Serial Link Option Adapter, not a standalone PLC controller. Its primary purpose is to provide communication functionality within a compatible automation architecture.
What equipment can be connected through the 172JNN21032?
Depending on the system configuration, it may be used with compatible controllers, serial field devices, intelligent instruments, operator interfaces, industrial drives, and other automation equipment.
Can another Schneider communication module directly replace 172JNN21032?
Not necessarily. A replacement must match the required mechanical, electrical, communication, controller, and software requirements. The original 172JNN21032 should therefore be matched whenever possible.
Why is serial communication still used in industrial automation?
Serial communication remains useful because many industrial devices and legacy control systems use established serial interfaces. It provides a practical method for connecting existing equipment while supporting long-term automation system maintenance.
Conclusion
The Schneider 172JNN21032 Serial Link Option Adapter is a compact industrial communication component designed to provide serial communication functionality within compatible Schneider automation systems. With dimensions of 25 × 143.1 × 60.06 mm and a weight of approximately 0.085 kg, the adapter is suitable for compact control-system installations where reliable serial communication is required.
By providing an interface between compatible automation equipment and serial devices, the 172JNN21032 can support data exchange for control, monitoring, diagnostics, and system integration. It can be particularly useful in existing automation installations where serial communication remains an important part of the control architecture.
For maintenance engineers, system integrators, and industrial automation spare-parts buyers, the most important consideration is to verify the complete 172JNN21032 product identification and the target Schneider automation system before installation. Correct component matching helps reduce compatibility problems and supports reliable long-term operation.
