Product Overview
The Schneider 170XTS00501 is a compact and reliable busbar module designed for industrial automation systems. It provides organized and efficient electrical distribution across PLCs, I/O modules, and other control components. Its dual-row configuration allows for neat wiring, reduced installation space, and improved system reliability in distributed automation setups.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Model Number | 170XTS00501 |
| Product Type | 2 Rows of Busbars |
| Function | Electrical distribution for PLCs and I/O modules |
| Dimensions (L x W x H) | 29 × 48 × 130 mm |
| Weight | 0.064 kg |
| Mounting | DIN rail / Rack-mounted |
| Environment | Industrial-grade |
| Material | Copper/insulated busbar |
| Voltage Rating | Up to 600 V DC/AC |
| Current Rating | Typical 10–20 A per row |
Function and Working Principle
The 170XTS00501 busbar module ensures organized and efficient power distribution in industrial automation systems. Key functionalities include:
- Provides dual-row electrical connections for multiple PLC and I/O modules
- Ensures stable and reliable current distribution
- Reduces wiring complexity and improves installation neatness
- Supports modular expansion of distributed automation systems
This module ensures consistent power delivery and enhances system reliability.
Role in Industrial Control Systems
The busbar module is an essential component in industrial automation networks:
- Facilitates organized power distribution for PLCs and I/O modules
- Supports modular and scalable automation architectures
- Ensures reliable electrical connectivity across multiple control devices
- Enhances system safety, maintenance, and diagnostics
Industrial Applications
The Schneider 170XTS00501 is commonly used in:
- Manufacturing automation systems
- Packaging and assembly machinery
- Process control in chemical, water treatment, and food plants
- Material handling and conveyor systems
- Electrical distribution in PLC cabinets
Its compact and industrial-grade design ensures dependable operation even in dense control cabinets.
Installation and System Integration
For optimal performance:
- Mount on DIN rails or inside control cabinets
- Connect PLC and I/O modules according to wiring schematics
- Ensure proper grounding and follow electrical safety procedures
- Use insulated connectors for secure connections
- Integrate busbars into modular distributed I/O systems
Proper installation ensures reliable electrical distribution and reduces wiring errors.
Compatible System Components
The 170XTS00501 works seamlessly with:
- Schneider PLCs: Modicon M340, M580, Quantum series
- Input/Output modules for distributed automation networks
- Communication adapters and expansion racks
- Processor adapters and power supply modules
These components together create a robust and scalable industrial automation system.
Recommended Alternative Models
| Model Number | Type | Key Feature / Advantage | Application |
|---|---|---|---|
| 170XTS00401 | Single Row Busbar | Standard power distribution | Basic PLC installations |
| 170XTS00601 | 3 Rows Busbar | Supports additional modules | Larger automation systems |
| 170XTS00701 | High-Capacity Busbar | Higher current rating | Heavy-duty industrial systems |
| 170XTS00801 | Modular Busbar | Flexible module connection | Scalable distributed I/O setups |
Key Advantages
- Compact dual-row design for efficient space utilization
- Provides reliable electrical distribution for PLCs and I/O modules
- Supports modular and scalable distributed control systems
- Industrial-grade construction ensures continuous operation
- Reduces wiring complexity and simplifies installation
Technical FAQs
Q1: What is the main function of the 170XTS00501?
A1: It distributes electrical power efficiently across PLCs and I/O modules.
Q2: What is its voltage and current rating?
A2: Up to 600 V DC/AC and 10–20 A per row (typical).
Q3: Is it compatible with Modicon PLCs?
A3: Yes, it integrates seamlessly with Modicon M340, M580, and Quantum PLC series.
Conclusion
The Schneider 170XTS00501 2 Rows of Busbars module is a compact, reliable, and essential component for industrial automation systems. Its organized power distribution, dual-row design, and industrial-grade durability make it indispensable for PLC-based distributed control networks.
Engineers and system integrators can depend on this module for efficient electrical connectivity, reduced wiring complexity, and scalable industrial automation performance.
