Ovation 1C31222G01 Relay Output Panel
Product Introduction
The Ovation 1C31222G01 is a high-performance relay output panel designed for use in industrial automation and control systems. As part of the renowned Ovation distributed control system (DCS), this module provides reliable and efficient switching of field devices by offering multiple relay outputs. Its design is focused on delivering dependable signal transmission in mission-critical environments, such as power generation plants, chemical facilities, and heavy manufacturing.
With robust build quality and exceptional electrical specifications, the 1C31222G01 enables seamless integration into large-scale control infrastructures. It is particularly valued for its high output channel density, compact footprint, and easy panel installation. The panel ensures consistent operation under demanding field conditions, supporting the secure and accurate execution of control commands issued by the central controller.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model Number | 1C31222G01 |
| Product Type | Relay Output Panel |
| Number of Output Channels | 16 Relay Outputs |
| Output Type | Form C Relays (SPDT) |
| Output Voltage Rating | 24 VDC / 120 VAC |
| Output Current Rating | 2 A max per channel |
| Isolation Voltage | 1500 V |
| Response Time | ≤ 10 ms |
| Dimensions | 220 × 140 × 35 mm |
| Weight | 0.32 kg |
| Mounting Style | Panel Mount |
| Operating Temperature | -20°C to +70°C |
| Compatibility | Ovation DCS |
| Certification | CE, RoHS |
Product Applications
The Ovation 1C31222G01 relay output panel is widely implemented in a broad range of industries and applications due to its flexibility and durability:
-
Power Plants: Enables control of turbines, circuit breakers, and auxiliary systems for smooth operation and safety assurance.
-
Oil & Gas Facilities: Controls valves, pumps, and emergency shutdown systems to meet operational and regulatory demands.
-
Industrial Manufacturing: Switches conveyor systems, actuators, and process equipment in real-time for efficient production cycles.
-
Water and Wastewater Plants: Manages pumping systems, filtration processes, and automated chemical treatment steps.
-
Infrastructure Automation: Useful in HVAC systems, lighting control, and other intelligent building management tasks.
Product Advantages
-
High-Density Output Configuration: With 16 output channels in one panel, this module reduces space and cost for installations with many control points.
-
Robust Electrical Isolation: 1500 V isolation protects the control system from voltage spikes and field interferences.
-
Versatile Output Support: Capable of handling both AC and DC loads, suitable for a wide range of end devices.
-
Wide Temperature Tolerance: Engineered for harsh environments, including outdoor panels and high-temperature areas.
-
Seamless DCS Integration: Full compatibility with Ovation control processors and software enables rapid deployment and minimal configuration time.
-
Reliable Form C Relays: Changeover relay design supports both normally open and normally closed operations, enhancing application flexibility.
Brand Overview: Ovation
Ovation, a brand under Emerson Process Management, is recognized for delivering sophisticated control and automation solutions primarily to the power and process industries. With a strong reputation for reliability and innovation, Ovation products such as the 1C31222G01 are engineered to perform in mission-critical applications, offering users an edge in terms of safety, operational efficiency, and long-term maintainability.
Recommended Related Models (Same Series or Related)
| Model Number | Outputs | Dimensions (mm) | Weight (kg) | Key Feature |
|---|---|---|---|---|
| 1C31219G01 | 8 | 150 × 100 × 30 | 0.18 | Compact relay module |
| 1C31218G01 | 4 | 150 × 100 × 30 | 0.14 | Low channel density |
| 1C31220G01 | 12 | 180 × 100 × 30 | 0.22 | Medium-density relay module |
| 1C31221G01 | 8 | 150 × 100 × 30 | 0.18 | Solid-state outputs |
| 1C31223G01 | 24 | 250 × 140 × 35 | 0.36 | High-density output panel |
Popular Ovation Models
| Model Number | Type | Dimensions (mm) | Weight (kg) | Description |
|---|---|---|---|---|
| 1C31210G01 | Analog Input Module | 150 × 100 × 30 | 0.20 | Precision analog input |
| 1C31214G01 | Analog Output Module | 150 × 100 × 30 | 0.21 | High-resolution output signals |
| 1C31215G01 | Digital Input Module | 150 × 100 × 30 | 0.17 | Fast digital signal acquisition |
| 1C31216G01 | Control Processor Unit | 180 × 120 × 40 | 0.40 | Central processing and control |
| 1C31125G02 | Power Supply Module | 160 × 110 × 40 | 0.28 | Redundant power backup |
Frequently Asked Questions (FAQ)
Q1: What is the function of the 1C31222G01 relay output panel?
A1: It provides 16 relay outputs to control field devices such as motors, solenoids, and alarm systems in industrial environments.
Q2: How is this module connected to the Ovation system?
A2: It connects via standardized Ovation I/O channels and integrates directly into Ovation DCS racks or panels.
Q3: What type of relays are used in this panel?
A3: The module uses Form C (SPDT) relays, which allow both normally open and normally closed configurations.
Q4: Can it be used for both AC and DC loads?
A4: Yes, it supports 24 VDC and 120 VAC, making it versatile for a variety of applications.
Q5: What is the response time for relay switching?
A5: It features a fast response time of ≤10 milliseconds.
Q6: Is the panel suitable for outdoor or extreme environments?
A6: Yes, the unit is rated for temperatures from -20°C to +70°C and is built to operate reliably in tough conditions.
Q7: How many devices can be controlled with one panel?
A7: Up to 16 separate field devices can be controlled with the relay outputs.
Q8: Does it require any special software to configure?
A8: No special software is required; it is fully integrated into the Ovation DCS programming environment.
Q9: How does this panel ensure safety?
A9: It includes 1500 V isolation and industry-standard certifications to prevent field-device interference with the control system.
Q10: Is maintenance complex?
A10: No, it is designed for easy maintenance with panel-mounted connectors and replaceable relay components.
