Product Overview

The Ingersoll Rand 47623601001 24266215 Hose is an industrial replacement hose designed for installation in compatible Ingersoll Rand equipment and machinery. With a specified hose length of 28 inches and a shipping weight of 3 kg, this hose provides a flexible connection between components within an industrial air, fluid, pneumatic, or auxiliary equipment circuit, depending on the host-machine configuration.

Flexible hoses are important components in industrial machinery because they can accommodate vibration, minor movement, installation tolerances, and service requirements that would be difficult to manage with rigid piping alone. A properly selected hose helps maintain a dependable connection between equipment components while allowing the system to operate under its intended mechanical conditions.

The 47623601001 reference is associated with the 24266215 hose identification. When purchasing or installing this component, the complete part-number combination should be verified together with the host equipment model, connection arrangement, routing requirements, and original installation. The specified 28-inch length is an important identification characteristic, but length alone does not establish complete compatibility.

With a nominal length of 28 inches, equivalent to approximately 711 mm, the hose can accommodate a moderate connection distance between compatible equipment components. Correct routing is particularly important because unnecessary bending, twisting, tension, or abrasion can reduce hose service life and affect equipment reliability.

---

Technical Specifications

Parameter	Specification
Manufacturer	Ingersoll Rand
Main Part Number	47623601001
Associated Part Number	24266215
Product Type	Industrial Hose
Hose Length	28 in
Approximate Length	711 mm
Shipping Weight	3 kg
Application	Industrial Equipment and Flexible Connection Systems
Installation	Compatible Ingersoll Rand Equipment
Component Function	Flexible system connection
Replacement Type	Industrial replacement component

Specification Note: Exact hose material, internal diameter, fitting configuration, pressure rating, temperature rating, and media compatibility should be confirmed against the applicable equipment documentation and the original hose before installation.

---

What Is the Ingersoll Rand 47623601001 24266215 Hose?

The Ingersoll Rand 47623601001 24266215 Hose is a flexible industrial component intended for use within compatible Ingersoll Rand equipment.

Industrial equipment often contains multiple components that must remain connected while experiencing vibration or small amounts of mechanical movement. A flexible hose can provide this connection while maintaining a continuous passage for the applicable system medium.

Depending on the specific host equipment, a hose may be associated with:

• Compressor assemblies
• Pneumatic circuits
• Fluid-handling systems
• Valves
• Regulators
• Filters
• Manifolds
• Cooling systems
• Lubrication circuits
• Auxiliary equipment

The precise application of the 24266215 should be determined from the host equipment and original component identification.

---

Function of the Hose in Industrial Equipment

The main purpose of an industrial hose is to provide a flexible connection between two system components.

A simplified connection can be represented as:

Source Component → 47623601001 / 24266215 Hose → Receiving Component

The hose creates a continuous path between the two components while allowing an appropriate degree of flexibility.

This can help accommodate:

• Mechanical vibration
• Minor component movement
• Thermal movement
• Equipment tolerances
• Installation requirements
• Maintenance access

The hose should nevertheless be installed according to the mechanical and operating requirements of the specific application.

---

Working Principle

The hose operates as a flexible passage between compatible connection points.

Depending on the host system, the connected medium may be compressed air, process fluid, lubricant, coolant, or another medium for which the hose is specifically designed.

The general operating sequence is:

System Source → Flexible Hose → System Component

During operation, internal pressure and flow are contained by the hose construction and its connections. At the same time, the flexible structure allows the hose to tolerate appropriate equipment movement and vibration.

The actual pressure, temperature, and media limitations depend on the specific hose construction and application and should be verified before installation.

---

Importance of Flexible Hose Connections

Rigid piping can be effective for permanent connections, but industrial machines frequently require flexible connections.

A hose can provide several practical benefits.

Vibration Accommodation

Compressors, pumps, motors, and other rotating machinery can generate vibration. A flexible hose can help accommodate suitable movement between connected components.

Installation Flexibility

A flexible connection can simplify equipment assembly when components are not positioned on exactly the same plane.

Reduced Mechanical Stress

When correctly selected and routed, a hose can reduce the transmission of certain mechanical movements between connected components.

Maintenance Accessibility

Flexible connections can make component removal and servicing more practical in equipment where rigid piping would restrict access.

Flexible Routing

The 28-inch length provides a flexible routing path for installations requiring more distance between connection points.

---

Role in Ingersoll Rand Equipment

Industrial compressor systems can contain numerous interconnected assemblies. Flexible hoses may be used between pressure-related components, valves, filters, manifolds, and other equipment elements.

The 47623601001 24266215 can therefore serve as part of a larger equipment connection architecture where a flexible path is required.

A simplified system layout can be represented as:

Primary Equipment → Fitting → Flexible Hose → Valve / Auxiliary Assembly

The hose should always be evaluated as part of this complete system.

A failure in a hose or its connections can potentially result in leakage, pressure loss, reduced equipment performance, or an unexpected shutdown depending on the function of the particular circuit.

---

28-Inch Hose Length

The specified hose length of the 24266215 is 28 inches.

Using the standard conversion:

28 inches × 25.4 mm = 711.2 mm

Therefore, the nominal hose length is approximately 711 mm.

The 28-inch configuration provides a useful intermediate connection length for equipment layouts where a short hose is insufficient but a significantly longer hose would create unnecessary routing.

Correct installation should maintain an appropriate amount of clearance without creating excessive slack.

An improperly routed hose may:

• Contact moving components
• Rub against brackets
• Become sharply bent
• Become twisted
• Experience excessive vibration
• Interfere with maintenance access

The hose should therefore follow the intended equipment routing.

---

Industrial Applications

Compressor Equipment

Flexible hoses are commonly incorporated into compressor assemblies to provide connections between equipment components.

The 47623601001 24266215 should only be used where its complete specifications match the relevant Ingersoll Rand equipment configuration.

Pneumatic Systems

Pneumatic equipment depends on reliable air connections. Flexible hoses may be used between valves, regulators, manifolds, and other pneumatic assemblies.

Fluid-Handling Systems

Where the hose material and specifications are suitable for the intended medium, flexible connections can form part of an industrial fluid circuit.

Media compatibility must be verified before installation.

Cooling and Auxiliary Circuits

Industrial machinery may contain auxiliary cooling or service circuits requiring flexible connections between components.

The 28-inch hose length can provide additional routing flexibility for suitable equipment configurations.

Industrial Maintenance

Hoses are often replaced during preventive maintenance because their condition can deteriorate through aging, vibration, abrasion, thermal exposure, or repeated mechanical movement.

---

Installation Guidelines

Verify the Part Number

Before installation, verify:

• 47623601001
• 24266215
• Hose length
• Equipment model
• Connection configuration
• Original routing

The replacement should match the original application.

Inspect the Hose

Before installation, inspect the hose for:

• Cuts
• Cracks
• Abrasion
• Deformation
• Contamination
• Damaged ends
• Packaging damage

Do not install a visibly damaged component.

Compare the Original Installation

Compare the replacement hose with the removed component where practical.

Check:

• Overall length
• Connection orientation
• Routing path
• Clearance
• Connection locations

Prevent Twisting

The hose should be installed without torsional stress.

Twisting during installation can place unnecessary stress on the hose body and connection points.

Avoid Sharp Bends

The hose should follow a smooth routing path and should not be forced around corners tighter than permitted by its construction.

Avoid Abrasion

Keep the hose away from sharp edges and surfaces that could repeatedly contact the hose during operation.

---

General Replacement Procedure

Step 1: Shut Down the Equipment

Stop the Ingersoll Rand equipment according to the applicable maintenance procedure.

Step 2: Isolate the Relevant Circuit

Isolate the associated air, fluid, or auxiliary circuit as required.

Step 3: Release Stored Pressure

Ensure that the relevant system is safely depressurized before disconnecting the hose.

Step 4: Record Hose Routing

Document the original hose routing and connection orientation before removal.

Step 5: Remove the Existing Hose

Disconnect the old hose using appropriate maintenance tools and procedures.

Step 6: Inspect Adjacent Components

Check fittings, valves, connectors, clamps, and nearby components for damage or contamination.

Step 7: Install the 24266215 Hose

Install the 47623601001 24266215 in the correct orientation.

Step 8: Check the 28-Inch Routing

Ensure that the hose has sufficient clearance and is not stretched, twisted, sharply bent, or exposed to excessive abrasion.

Step 9: Restore the System

Return the equipment to operating condition according to the applicable procedure.

Step 10: Inspect During Startup

Check the hose and connections for leakage, abnormal movement, or other installation problems during controlled startup.

---

Troubleshooting the 47623601001 24266215 Hose

Hose Leakage

Leakage may result from:

• Damaged hose
• Loose connection
• Damaged fitting
• Incorrect installation
• Seal deterioration
• Mechanical stress
• Hose aging

Both the hose body and connection points should be inspected.

Cracking

Visible cracks can indicate material deterioration or environmental exposure.

A significantly cracked hose should be replaced according to the equipment maintenance procedure.

Abrasion

Repeated contact with brackets, piping, sheet metal, or other equipment can wear through the outer surface.

Routing should be corrected if abrasion is discovered.

Excessive Movement

Unexpected movement may be associated with:

• Equipment vibration
• Incorrect routing
• Insufficient support
• Pressure pulsation
• Incorrect hose length
• Mechanical interference

The underlying cause should be investigated.

Kinking or Flattening

Kinking can restrict internal flow and increase mechanical stress.

A hose showing significant deformation should be inspected and replaced where necessary.

Connection Failure

If a connection repeatedly loosens, inspect the fitting, installation orientation, vibration level, and surrounding mechanical conditions rather than repeatedly tightening the connection without investigating the cause.

---

Preventive Maintenance

Regular hose inspection can help reduce unexpected equipment downtime.

Visual Inspection

Inspect the hose for:

• Cracks
• Cuts
• Abrasion
• Bulging
• Flattening
• Discoloration
• Leakage
• Connection damage

Check Hose Routing

Confirm that the 28-inch hose remains in its intended position after maintenance activities.

Nearby component work can unintentionally change hose routing.

Inspect Connection Points

Check both ends for leakage, looseness, corrosion, or physical damage.

Monitor Equipment Vibration

Changes in equipment vibration can increase mechanical stress on flexible connections.

Unusual hose movement should therefore be investigated.

Check Environmental Conditions

Inspect whether the hose is exposed to excessive heat, chemicals, moisture, or other environmental conditions that may affect its service life.

---

Replacement Considerations

When sourcing the Ingersoll Rand 47623601001 24266215 Hose, the following information should be verified.

Identification Item	Specification
Manufacturer	Ingersoll Rand
Main Part Number	47623601001
Associated Part Number	24266215
Hose Length	28 in
Approximate Length	711 mm
Shipping Weight	3 kg
Product Type	Industrial Hose
Equipment Model	Verify before installation
Connection Arrangement	Verify before installation
Application	Verify before installation
Operating Requirements	Verify before installation

A replacement should reproduce the required mechanical and application characteristics of the original hose.

---

Physical Dimensions and Shipping Information

The supplied hose length is 28 inches, corresponding to approximately 711.2 mm.

For engineering and inventory documentation, the length can be recorded as approximately 711 mm.

The specified shipping weight is 3 kg.

This shipping specification can be useful for:

• Warehouse planning
• Spare-parts management
• Packaging
• Transportation
• Purchasing
• International shipping calculations

Shipping weight should not automatically be interpreted as the net weight of the hose because packaging materials may contribute to the stated value.

---

Storage Recommendations

Proper storage is important when keeping the 47623601001 24266215 as a spare component.

Recommended practices include:

• Store in a clean and dry location.
• Protect the hose from direct sunlight.
• Avoid excessive heat.
• Keep away from aggressive chemicals.
• Prevent sharp bends during storage.
• Avoid placing heavy objects on the hose.
• Protect connection ends from contamination.
• Keep the part-number identification visible.

Proper storage helps maintain the condition of replacement components until they are required.

---

Related Industrial Components

The hose may be installed as part of a larger equipment assembly containing components such as:

Related Component	General Function
Compressor Assembly	Generates compressed air
Air Filter	Filters incoming air
Oil Filter	Removes contaminants from lubricating oil
Air-Oil Separator	Separates oil from compressed air
Valve	Controls system flow
Regulator	Controls or regulates pressure
Manifold	Distributes air or fluid
Fitting	Provides mechanical connection
Cooling Assembly	Supports thermal management
Instrumentation	Monitors equipment conditions

The exact relationship between these components and the 24266215 hose depends on the host equipment design.

---

Engineering Best Practices

Use Complete Part Identification

Maintenance and purchasing records should identify the component as 47623601001 / 24266215.

Match the Original Application

A visually similar hose may have different material, pressure, temperature, fitting, or media characteristics.

Preserve the Intended Routing

The 28-inch length should be used to create the required connection without excessive slack or mechanical tension.

Avoid Using Hose as an Alignment Tool

A flexible hose should not be forced into position to compensate for major misalignment between equipment components.

Inspect Before Startup

After installation, inspect the hose and connections before returning the machine to normal operation.

Maintain Spare-Part Records

Record replacement dates, part numbers, equipment locations, and inspection results to support preventive maintenance.

---

Key Advantages

28-Inch Flexible Connection

The 28 in hose length provides a useful flexible connection distance for compatible industrial equipment layouts.

Flexible Mechanical Interface

The hose can accommodate appropriate vibration and minor movement between connected equipment components.

Practical Replacement Component

The dedicated 24266215 identification helps maintenance personnel source the required replacement component.

Compact Industrial Routing

The 711 mm approximate length provides flexibility without the excess routing associated with substantially longer hose assemblies.

Useful Logistics Information

The supplied 3 kg shipping weight supports inventory and transportation planning.

Suitable for Compatible Ingersoll Rand Equipment

The component is intended for use in equipment configurations where the complete part identification and application requirements match.

---

Technical FAQs

What is the Ingersoll Rand 47623601001 24266215?

The Ingersoll Rand 47623601001 24266215 is an industrial hose used as a flexible connection component in compatible Ingersoll Rand equipment.

What is the hose length?

The specified hose length is 28 inches, equivalent to approximately 711.2 mm.

What is the shipping weight?

The listed shipping weight is 3 kg.

What is the function of the hose?

An industrial hose provides a flexible connection between equipment components and allows the applicable system medium to pass between connected points.

Why is a flexible hose used instead of rigid piping?

A flexible hose can accommodate suitable vibration, minor movement, installation tolerances, and maintenance requirements.

Can another 28-inch hose replace the 24266215?

Not automatically. Length alone does not establish compatibility. The hose construction, connection configuration, pressure and temperature requirements, media compatibility, and host equipment should also be verified.

What should be checked before installing the hose?

Verify the complete 47623601001 / 24266215 identification, host equipment, connection configuration, routing, and applicable operating requirements.

What can cause premature hose failure?

Potential causes include excessive bending, twisting, abrasion, vibration, thermal exposure, chemical exposure, incorrect routing, excessive pressure, and normal material aging.

What should be done if the hose leaks?

Safely shut down and isolate the relevant equipment circuit before inspection. If the hose or connection is damaged, replace the affected component according to the applicable maintenance procedure.

Is the 3 kg specification the net hose weight?

No conclusion about net component weight should be drawn from the supplied value. 3 kg is the specified shipping weight and may include packaging.

---

Conclusion

The Ingersoll Rand 47623601001 24266215 Hose is an industrial replacement hose specified with a 28-inch length and a 3 kg shipping weight. Its flexible configuration is intended to provide a reliable connection between compatible equipment components while accommodating appropriate mechanical movement and vibration.

The approximately 711 mm length makes the hose suitable for connection arrangements requiring a moderate flexible routing distance. Proper installation remains important because incorrect routing, twisting, excessive bending, abrasion, or mechanical tension can reduce service life and affect equipment reliability.

For replacement and procurement purposes, the complete 47623601001 / 24266215 identification should be retained. Technicians should verify the host equipment, connection arrangement, hose construction, and operating requirements before installation rather than relying solely on the 28-inch length.

With correct part identification, careful installation, proper routing, regular inspection, and appropriate preventive maintenance, the Ingersoll Rand 47623601001 24266215 Hose can support dependable flexible connections within compatible industrial equipment and contribute to stable long-term machine operation.
