Product Overview: Honeywell FS-TIDI-1624
The Honeywell FS-TIDI-1624 is a high-performance digital input field termination assembly designed for industrial control systems. It ensures reliable signal transmission and enhanced system reliability in harsh environments. This module is equipped with 16 non-safe isolated 24V DC input channels, making it ideal for a wide range of applications from automation to process control.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | FS-TIDI-1624 |
| Type | Digital Input Field Termination Assembly |
| Input Channels | 16 |
| Nominal Input Voltage | 24V DC |
| Drop-out Voltage | 2.8V DC |
| Pick-up Voltage | 17.5V DC |
| Max. Input Voltage | 47.5V DC |
| Reverse Polarity Protection | Series diode |
| Max. Reverse Voltage | 300V |
| Input Current | Typically 9mA at 24V DC |
| Max. Switching Frequency | 20Hz |
| Dimensions (L × W × H) | 265 × 70 × 48 mm |
| Weight | 1.0 kg |
| Mounting | DIN EN rail TS32 / TS35 × 7.5 |
| Termination | Screw terminals |
| Max. Wire Diameter | 2.5 mm² (AWG 14) |
| Strip Length | 7 mm |
| Tightening Torque | 0.5 Nm |
| Galvanic Isolation | Input to Output: 1000V AC |
| Input to Input: 1000V AC | |
| Approvals | CE, TUV, UL, CSA |
| IP Rating | IP67 |
| MTBF | > 100,000 hours |
Product Introduction
The FS-TIDI-1624 is engineered to provide robust and reliable digital input connections in industrial environments. Its 16 non-safe isolated 24V DC input channels allow for versatile connectivity, making it suitable for various applications, including automation and process control. The module’s design ensures optimal signal reception and transmission, even in demanding conditions.
Applications
-
Industrial automation control systems
-
Process control systems
-
Emergency shutdown systems
-
Fire alarm systems
-
Burner management systems
-
Alarm systems
-
Safety Instrumented Systems (SIS)
-
Turbomachinery control systems
Advantages
-
Robust Design: Built to withstand harsh industrial environments, ensuring long-term reliability.
-
High Channel Density: 16 input channels in a compact form factor, optimizing panel space.
-
Easy Installation: Compatible with standard DIN EN rails, simplifying mounting and integration.
-
Versatile Connectivity: Supports a wide range of industrial applications, from automation to safety systems.
-
High Reliability: Designed for high Mean Time Between Failures (MTBF), reducing downtime.
-
Comprehensive Approvals: Meets international standards, ensuring compliance and safety.
Brand and Series
-
Brand: Honeywell
-
Series: FS Series
-
Product Type: Digital Input Field Termination Assembly
Related Models or Similar Terminal Blocks
| Model | Number of Positions | Rated Voltage (V DC) | Rated Current (A) | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| FS-TIDI-1624 | 16 | 24 | – | 265 × 70 × 48 | 1.0 |
| FS-TSDI-1624 | 16 | 24 | – | 120 × 100 × 35 | 0.45 |
| FS-TDO-1624 | 16 | 24 | – | 190 × 115 × 38 | 0.55 |
| FS-TDO-07120 | 7 | 120 | – | 190 × 115 × 38 | 0.55 |
| FS-TDOL-07120 | 7 | 120 | – | 190 × 115 × 38 | 0.55 |
Popular Honeywell Models
| Model | Type | Number of Positions | Rated Voltage (V DC) | Rated Current (A) | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| FS-TIDI-1624 | Digital Input Module | 16 | 24 | – | 265 × 70 × 48 | 1.0 |
| FS-TSDI-1624 | Digital Input Module | 16 | 24 | – | 120 × 100 × 35 | 0.45 |
| FS-TDO-1624 | Digital Output Module | 16 | 24 | – | 190 × 115 × 38 | 0.55 |
| FS-TDO-07120 | Digital Output Module | 7 | 120 | – | 190 × 115 × 38 | 0.55 |
| FS-TDOL-07120 | Digital Output Module | 7 | 120 | – | 190 × 115 × 38 | 0.55 |
Frequently Asked Questions (FAQ)
Q1: What type of signals can the FS-TIDI-1624 handle?
A1: It handles digital 24V DC input signals, commonly used in industrial control systems.
Q2: Is the FS-TIDI-1624 suitable for use in hazardous environments?
A2: Yes, it has robust protection features and is designed for use in industrial environments, but always check specific safety certifications for hazardous areas.
Q3: How is the FS-TIDI-1624 mounted?
A3: It is mounted on a standard DIN rail, making installation straightforward and compatible with common control panels.
Q4: What is the physical size of the FS-TIDI-1624?
A4: The module measures 265 mm in length, 70 mm in width, and 48 mm in height.
Q5: Can the input wiring handle different cable sizes?
A5: Yes, it supports wire diameters up to 2.5 mm² (AWG 14) with screw terminals.
Q6: Does the FS-TIDI-1624 include any protection against reverse polarity?
A6: Yes, it features a series diode for reverse polarity protection to prevent damage.
Q7: What is the weight of this module?
A7: The module weighs approximately 1.0 kg.
Q8: How many input channels does the FS-TIDI-1624 have?
A8: There are 16 digital input channels available.
Q9: Is the FS-TIDI-1624 compatible with safety instrumented systems?
A9: It is suitable for many control applications but is classified as non-safe isolated inputs, so verify compatibility based on your system’s safety requirements.
Q10: What kind of maintenance is required for the FS-TIDI-1624?
A10: Regular visual inspections and cleaning of terminal connections are recommended to ensure reliable performance.
