Product: Honeywell FC‑MCAR‑02
1. Technical Specifications
| Parameter | Details |
|---|---|
| Model | FC‑MCAR‑02 |
| Product Type | SM RIO 36‑inch Carrier (Mounting / Backplane / Support Carrier for SM RIO modules) |
| Carrier Length | 36 inches (≈ 914.4 mm) |
| Width | ≈ 222.3 mm |
| Height / Depth | ≈ 105.4 mm |
| Weight | 6.1 kg |
| Operating Temperature | −40 °C to +70 °C |
| Storage Temperature | −40 °C to +85 °C |
| Relative Humidity | 10 % to 95 % (non‑condensing) |
| Pollution Degree | Pollution Degree 2 or better |
| Supply Voltage | +24 V DC (power rails provided) |
| Power Rail Current Capacity | Up to 40 A on 24 V supply rails |
| Ground Connections | 32 ground points (M5 screws) |
| Mounting Features | Four mounting holes; coupling between carriers via M5 screws; metal profile & plastic cover plates; cable carrier assembly included |
| Certifications / Safety | CE certification; UL recognized (in listings) |
2. Product Introduction
The FC‑MCAR‑02 is a heavy‐duty 36‑inch carrier designed for the SM RIO (Remote I/O) modules in industrial automation environments. It serves both as physical mounting structure and as the electrical backplane, providing power and ground rails, mechanical support, and coupling capability. It integrates features such as cable carrier assemblies, ground rails, dual 24 V supply rails, all in a form factor suited for harsh conditions and high reliability.
This carrier is intended for mounting two IOTA‑R24 assemblies (or multiple SM RIO modules) and is built to withstand wide temperature swings, humidity, airborne pollution, and continuous industrial usage. Its robust design helps organize wiring, maintain consistent power supply, and simplify module installation and servicing.
3. Applications
-
Mounting platform in automation panels for Safety Manager RIO (SM RIO) modules.
-
Backplane / support structure for remote I/O modules, especially IOTA‑R24 type.
-
Environments requiring stable mounting and reliable power distribution to multiple modules.
-
Industrial settings with temperature extremes, moisture, or airborne contamination.
-
Process control, safety systems, power generation, water/wastewater plants, chemical plants—where modular I/O is used.
-
Retrofits or expansions: where adding SM RIO modules requires matching mounting carriers.
4. Product Advantages
-
Structural rigidity: 36‑inch metal profile able to support multiple heavy modules and cable assemblies.
-
High current capacity: 24 V DC rails capable of supplying up to 40 A, enabling heavy module loading.
-
Grounding: 32 ground connections help maintain noise immunity, safety, and proper reference potentials.
-
Environmental robustness: Wide temperature range (‑40 to +70 °C), high humidity tolerance, pollution degree 2 or better.
-
Modularity: Can be coupled with other FC‑MCAR‑02 carriers; mounting design simplifies integration and cable routing.
-
Simplifies wiring & maintenance: Backplane power rails, cover plates, cable troughs help organize wires; consistent mounting points accelerate module installation or replacement.
-
Certifications: CE and UL recognition help with regulatory compliance and safety in installations.
5. Brand
Brand: Honeywell — a global automation, control systems, and equipment supplier known for robustness, quality, and reliability in industrial and safety‑critical systems.
6. Series
Series: The FC‑MCAR‑02 belongs to the SM RIO / Remote I/O Carrier series (sometimes associated with the FSC / SM RIO family). These carriers are backplanes / physical support structures intended for SM RIO modules and related I/O assemblies. “MCAR” stands for “Mounting Carrier” (MCAR), “02” is the version number.
7. Related Models (Same Series or Closely Related)
Here are five models in the same or similar series, for comparison. Some are other carriers / mounting hardware; some are I/O modules that could be mounted on carriers.
| Model | Function / I/O or Hardware Type | Key Specs | Dimensions / Weight | Notes |
|---|---|---|---|---|
| FC‑MCAR‑01 | Mounting Carrier, earlier version | 24 V DC rails, support for IOTA‑R24 assemblies; mounting profile & ground rails | ≈ same width / depth but shorter length; weight ~1.1 kg | Smaller footprint, supporting fewer modules than MCAR‑02 |
| FC‑CIPer‑Model30 | Controller / Logic Processor | Mixed I/O, powerful controller; supports remote I/O modules | Larger, heavier (≈2.5 kg or more) | Hosts many I/O modules including SM RIO possibly |
| MC‑TDOD13 | Digital Output Module, 16‑point | 16 digital outputs, 24 V DC | Module size moderate; weight smaller (≈1 kg or less) | Mounts onto carriers like MCAR series |
| FTA‑T‑01 | Safe Digital Input / Fail‑Safe Module | Input diagnostics, safety grade inputs | Standard module size; lighter than carrier | Fits into the same SM RIO or I/O rack system |
| FC‑TDOL‑07120 | Digital Output Module with line monitoring, 7 channel, 120 V output | Heavy load switching, fused outputs, loop monitoring | Larger size and heavier (~1 kg) than digital input/output modules | Attaches to racks/carriers including MCAR family |
8. Other Popular Models by Same Brand (Honeywell)
Five widely used Honeywell modules / carriers / hardware widely in use in automation systems, for comparison.
| Model | Function | Key Specs | Dimensions / Weight | Highlights |
|---|---|---|---|---|
| FC‑MCAR‑01 | Mounting Carrier, earlier variant | 24 V DC rails, ground connections; supports some number of IOTA‑R24 assemblies | Weight ~1.1 kg; smaller size than MCAR‑02 | Good for smaller rack build‑outs |
| MC‑TDOD13 | 16‑point Digital Output Module | 16 outputs, 24 V DC; safety or standard digital outputs | Module size ~ moderate; weight ~0.8‑1.2 kg | Used in many remote I/O expansions |
| FTA‑T‑01 | Fail‑Safe / Safe Digital Input Module | Safety rated inputs, diagnostics; often 24 V DC | Standard module dimensions; lighter than carriers | Critical for safety logic in control systems |
| FC‑TDOL‑0724P | Analog Input Module (protected) | 7 channels analog input, 24 V DC; ruggedized features | Size ~240 × 108 × 85 mm; weight ~0.62 kg | For harsh conditions and analog data acquisition |
| FC‑TDOL‑07120 | Digital Output with loop monitoring, 7 channel, 120 V output | Fused relay outputs; high voltage output capability | Larger size; weight ~1.0 kg | For heavy loads and line monitoring tasks |
9. FAQs (QA Format)
Below are ten questions & answers, practical and direct. Each ends with a blank line.
Q1: What is the purpose of the FC‑MCAR‑02?
A1: It is a carrier/backplane used to mount SM RIO modules (such as IOTA‑R24 assemblies), provide power rails, ground rails, and physical support in control or automation panels.
Q2: How many SM RIO or IOTA‑R24 modules does one FC‑MCAR‑02 support?
A2: It is designed to house two IOTA‑R24 assemblies or multiple SM RIO modules along a 36‑inch carrier length.
Q3: What power supply is needed?
A3: +24 V DC power is provided via power rails; the 24 V supply rails are rated to carry up to 40 A in aggregate.
Q4: What are the physical dimensions?
A4: Approximately 914.4 mm (36 in) in length, ≈ 222.3 mm in width, ≈ 105.4 mm in height (depth).
Q5: What is the weight of the carrier?
A5: 6.1 kg.
Q6: Under what temperatures does it operate reliably?
A6: Operating temperature from −40 °C to +70 °C; storage temperature −40 °C to +85 °C.
Q7: What about moisture and humidity tolerance?
A7: Relative humidity 10 %‑95 % non‑condensing; suitable for moist industrial locations provided no water ingress.
Q8: How does grounding work?
A8: It includes a ground rail with 32 M5 screws for connecting module grounds and chassis earth.
Q9: Can multiple FC‑MCAR‑02 carriers be coupled together?
A9: Yes — carriers can be connected via M5 screws through coupling holes in the power rails, to extend power or create multi‑carrier racks.
Q10: Is the product certified / safe for industrial installations?
A10: Yes — CE certified; UL recognition is in listings; pollution degree 2 or better; meant for industrial use.
