Product Overview – CC‑TDIL11 (51308386‑175)
Introduction
The CC‑TDIL11 (code 51308386‑175) is a rugged industrial digital input module crafted for reliable signal detection in harsh environments. Compact yet robust, it captures 24 V DC digital signals for integration into process control systems, making it ideal for automation tasks requiring swift and accurate status reading.
Brand & Series
-
Brand: A reputable industrial automation instruments brand
-
Series: CC‑TDIL series – digital input modules designed for compact yet durable deployment
Key Specifications
| Parameter | Specification |
|---|---|
| Model | CC‑TDIL11 (51308386‑175) |
| Series | CC‑TDIL digital input series |
| Input Voltage | 24 V DC (range 5–30 V DC) |
| Input Type | Digital discrete inputs (e.g. TTL-level compatible) |
| Response Time | ≤ 1 ms |
| Power Consumption | Max 30 mA @ 24 V |
| Operating Temperature | –40 °C to +85 °C |
| Environmental Rating | IP65 (sealed against dust/water spray) |
| Communication Interface | Modbus RTU |
| Dimensions (W×H×D) | 76 × 46 × 27.5 mm |
| Weight | 0.035 kg (35 g) |
Applications
This module excels in:
-
On/off status capture from field sensors, switches, and alarms in assembly lines
-
Integration into process control systems requiring tight, reliable digital data ingress
-
Environments demanding sealed equipment—vehicle bays, outdoor cabinets, washdown areas
-
Compact machine interfaces where board‑space and wiring simplicity are vital
Advantages
-
Ultra‑compact and lightweight, easing installation in tight enclosures.
-
Fast response (≤ 1 ms) ensures real‑time signal capture and control integrity.
-
IP65 rating safeguards against dust and liquid, enhancing field durability.
-
Standard Modbus RTU interface simplifies networked system integration.
-
Low power draw (max 30 mA) reduces energy overhead within control panels.
Five Related or Same‑Series Models
| Model | Key Features | Dimensions (mm) | Weight (kg) | Notes |
|---|---|---|---|---|
| CC‑TDIL01 | 16-channel 24 V DC digital input, LED indicators | 100 × 75 × 50 | 0.5 | Broad channel count for dense digital I/O |
| CC‑PDIL01 | Similar module for Experion PKS C300 systems | ~100 × 75 × 50 | ~0.5 | Variant with sink/source compatibility |
| CC‑TDIL11‑Redundant | Digital input with redundancy and SOE capabilities | Larger, spec‑dependent | ~1.5 | For high‑availability SOE logging |
| CC‑TDIL11‑IP67 | Same functionality with IP67 enclosure | ~80 × 52 × 25 | 0.15 | Higher ingress protection |
| CC‑TDIL11‑Panel | Panel-mount Digital Input variant, ruggedized | ~80 × 52 × 25 | 0.15 | Designed for cabinet mounting |
Five Other Popular Models from the Same Brand
| Model | Functionality | Dimensions (mm) | Weight (kg) | Notes |
|---|---|---|---|---|
| CMX‑AI08 | 8-channel analog input module | 130 × 90 × 60 | 0.9 | High-density analog acquisition |
| CMX‑AO08 | 8-channel analog output module | 130 × 90 × 60 | 0.9 | Suitable for controlling multiple actuators |
| CDS‑Relay08 | 8 relay outputs (form A) | 125 × 85 × 55 | 0.9 | Electrically isolated for switching |
| CEN‑Serial‑GW | Serial-to-Ethernet gateway | 120 × 80 × 50 | 0.7 | Bridges older serial systems to ethernet |
| CBP‑PowerSupply‑24 | 24 V DC DIN‑rail power supply | 120 × 90 × 55 | 0.6 | Reliable panel power feed |
FAQ (10 Q&A)
Q1: What kind of voltage signals does it accept?
A1: It detects 24 V DC signals within a 5–30 V DC range, compatible with TTL-level.
Q2: How fast does it respond to changes?
A2: The module responds in under 1 ms—fast enough for most control logic needs.
Q3: Is it rugged enough for outdoor or washdown areas?
A3: Yes—IP65 rating protects against dust and water spray, suitable for tough environments.
Q4: What communications protocol does it use?
A4: It interacts via Modbus RTU over standard interface.
Q5: How large is the device?
A5: It measures just 76 × 46 × 27.5 mm—very compact for tight panels.
Q6: How much does it weigh?
A6: Approximately 35 grams—almost no added load to mounting hardware.
Q7: What temperature range can it handle?
A7: It operates from –40 °C up to +85 °C, covering most industrial zones.
Q8: How much current does it draw?
A8: No more than 30 mA at 24 V—negligible in most enclosure budgets.
Q9: Is this module suitable for SCADA integration?
A9: Yes—Modbus RTU makes it easily hookable to SCADA or DCS systems.
Q10: Does it show input status on the module?
A10: Status LEDs are not standard on this version; check variants for LED feedback.
