Product Overview
The GE IC697PWR748 Power Module is an industrial power supply module designed for use with GE Fanuc Series 90-70 PLC systems. As an essential part of the Series 90-70 control platform, the module provides the electrical power required by the PLC rack and its installed automation components, helping maintain stable operation of CPUs, I/O modules, communication modules, and other rack-mounted devices.
The IC697PWR748 is intended for industrial control environments where reliable power conversion and distribution are essential. A PLC system depends on a stable internal power source because fluctuations, overload conditions, or power interruptions can affect controller operation, communication, I/O processing, and machine control. By providing regulated power to the rack, the power module supports dependable operation of the complete automation system.
The module is designed for integration into a Series 90-70 rack and works as part of the PLC’s centralized power architecture. It is particularly useful in control panels where multiple PLC modules must operate continuously and reliably under demanding industrial conditions.
With dimensions of approximately 200 × 55 × 145 mm and a weight of approximately 1.3 kg, the IC697PWR748 provides a compact rack-mounted solution while offering the robust construction expected from industrial PLC power equipment.
Typical applications include manufacturing automation, process control, machine automation, water and wastewater treatment, energy systems, material handling, chemical processing, oil and gas facilities, transportation infrastructure, and other industrial applications based on GE Fanuc Series 90-70 PLC technology.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc |
| Model | IC697PWR748 |
| Product Family | Series 90-70 |
| Product Type | Power Module |
| Primary Function | PLC Rack Power Supply |
| Installation | Rack Mounted |
| Compatible Platform | GE Fanuc Series 90-70 PLC |
| Power Architecture | PLC Backplane Power Distribution |
| Application | Industrial Automation and Process Control |
| Cooling | Natural / Rack Air Cooling |
| Dimensions | 200 × 55 × 145 mm |
| Weight | Approximately 1.3 kg |
| Mounting Environment | Industrial Control Cabinet |
Note: Exact input/output electrical ratings and rack compatibility should be verified against the specific Series 90-70 hardware configuration and applicable technical documentation before installation or replacement.
Function and Working Principle
The primary function of the GE IC697PWR748 is to provide stable electrical power to a Series 90-70 PLC rack.
A typical power architecture can be represented as:
Industrial AC Power
↓
GE IC697PWR748 Power Module
↓
Series 90-70 Backplane
↓
CPU + I/O + Communication Modules
↓
Sensors / Actuators / Industrial Equipment
The power module receives the system’s incoming electrical supply and provides the appropriate regulated power required by the PLC rack. The backplane then distributes the available operating power to compatible modules installed in the rack.
During normal operation, the power supply performs several important functions:
- Converts incoming electrical power into suitable PLC operating power
- Supplies the Series 90-70 backplane
- Supports CPU module operation
- Powers compatible I/O modules
- Supports communication module operation
- Maintains stable internal power distribution
- Helps protect the PLC system from abnormal electrical conditions
- Supports continuous industrial control operation
Reliable power delivery is particularly important in applications where PLC downtime can interrupt production or affect critical process operations.
Role in Industrial Control Systems
Within a GE Fanuc Series 90-70 control system, the IC697PWR748 functions as the electrical foundation of the PLC rack.
A typical automation structure is:
Industrial Power Source
↓
IC697PWR748 Power Module
↓
Series 90-70 PLC Rack
↓
CPU / Controller
↓
Digital & Analog I/O
↓
Field Sensors and Actuators
↓
Industrial Machinery
The power module does not perform PLC program execution or directly process field signals. Instead, it provides the stable power necessary for the controller and associated modules to perform these functions.
A properly selected power module helps maintain reliable:
- PLC processor operation
- Digital signal processing
- Analog signal processing
- Industrial communication
- Remote I/O operation
- HMI interaction
- SCADA monitoring
- Machine sequencing
- Process control
For this reason, power supply selection is an important part of Series 90-70 system design and maintenance.
Industrial Applications
Manufacturing Automation
The IC697PWR748 can be used in PLC control cabinets supporting:
- Automated assembly lines
- Production machinery
- CNC equipment
- Robotic work cells
- Conveyor systems
- Packaging machinery
Stable rack power allows the PLC controller and I/O modules to maintain consistent machine sequencing.
Process Automation
Series 90-70 systems have been used in industrial process control environments involving:
- Pump control
- Valve control
- Process monitoring
- Batch processing
- Temperature control
- Pressure monitoring
Reliable PLC power is essential when the controller must operate continuously for extended periods.
Water and Wastewater Treatment
Industrial PLC racks may control:
- Pump stations
- Filtration systems
- Water treatment equipment
- Chemical dosing systems
- Aeration systems
- Valve networks
A dependable power module helps maintain controller availability throughout continuous treatment processes.
Energy and Utility Systems
Applications can include:
- Auxiliary equipment control
- Generator support systems
- Electrical monitoring
- Utility automation
- Plant equipment control
The power module can form part of a larger PLC control cabinet used for monitoring and automation.
Material Handling
Series 90-70 PLC systems can be integrated into:
- Conveyor systems
- Sorting machinery
- Automated storage equipment
- Transfer stations
- Material handling lines
Stable rack power helps maintain communication between the PLC processor, I/O modules, and machine control equipment.
Chemical and Industrial Processing
The module can support PLC systems used for:
- Pump sequencing
- Motor control
- Valve operation
- Process instrumentation
- Batch control
- Equipment monitoring
Reliable power is especially important in process systems where unexpected controller shutdowns can interrupt production.
Installation and System Integration
Correct installation is essential for dependable PLC operation. Before installing an IC697PWR748, engineers should verify the complete Series 90-70 hardware configuration and electrical requirements.
Important considerations include:
- Series 90-70 rack compatibility
- Input power requirements
- Power supply capacity
- Rack configuration
- Module loading
- Grounding arrangement
- Cabinet ventilation
- Wiring condition
- Electrical protection
- Environmental conditions
Recommended Installation Procedure
- Disconnect the PLC system from the incoming power source.
- Confirm that the replacement module matches the existing system configuration.
- Inspect the Series 90-70 rack and backplane connector.
- Install the IC697PWR748 into the designated rack position.
- Secure the module correctly.
- Connect the appropriate incoming power wiring.
- Verify protective grounding.
- Inspect wiring terminals and connectors.
- Confirm that the rack configuration is correct.
- Restore system power.
- Check the power module status.
- Verify CPU startup.
- Confirm I/O module operation.
- Check PLC communication.
- Perform functional testing before returning the machine to production.
Replacement Considerations
When replacing an existing power module, engineers should compare:
- Model number
- Electrical ratings
- Rack requirements
- Total rack power demand
- Module compatibility
- Environmental specifications
- Physical dimensions
- Wiring arrangement
A replacement should never be selected solely because its physical dimensions are similar. Electrical compatibility and the complete rack power budget must also be confirmed.
Compatible System Components
| Component | Function |
|---|---|
| IC697PWR748 | PLC rack power supply |
| GE Fanuc Series 90-70 Rack | Mechanical and electrical module mounting |
| Series 90-70 CPU | PLC program execution |
| Digital Input Modules | Discrete signal acquisition |
| Digital Output Modules | Discrete equipment control |
| Analog Input Modules | Process measurement |
| Analog Output Modules | Analog process control |
| Communication Modules | PLC and network communication |
| Genius Bus Modules | Distributed I/O communication |
| Ethernet Modules | Industrial networking |
| HMI | Operator interface |
| SCADA System | Supervisory monitoring and control |
Recommended Alternative Models
| Model | Product Type | Typical Application |
|---|---|---|
| IC697PWR748 | Power Module | Series 90-70 PLC power supply |
| IC697PWR711 | Power Module | Series 90-70 rack power applications |
| IC697PWR713 | Power Module | Industrial PLC power supply |
| IC697PWR720 | Power Module | Series 90-70 automation systems |
| Compatible Series 90-70 Power Modules | Power Module | Replacement and system expansion |
When selecting an alternative, engineers should verify electrical specifications, rack compatibility, total system load, environmental requirements, and the configuration of the existing Series 90-70 PLC system.
Key Advantages
- Designed for GE Fanuc Series 90-70 PLC systems
- Provides reliable rack power distribution
- Supports CPU and I/O module operation
- Compact rack-mounted construction
- Suitable for industrial control cabinets
- Supports continuous PLC operation
- Integrates with Series 90-70 automation architectures
- Helps maintain stable PLC system operation
- Suitable for manufacturing and process automation
- Useful for legacy PLC maintenance and replacement projects
- Dimensions 200 × 55 × 145 mm
- Approximate weight 1.3 kg
Technical FAQs
What is the GE IC697PWR748?
The GE IC697PWR748 is a power module designed for the GE Fanuc Series 90-70 PLC platform. It provides the electrical power required by compatible PLC rack components.
What is the primary function of the IC697PWR748?
Its primary function is to supply and distribute regulated operating power to the Series 90-70 PLC rack and compatible modules installed within the system.
What are the dimensions of the IC697PWR748?
The module measures approximately 200 × 55 × 145 mm.
How much does the module weigh?
The approximate weight is 1.3 kg.
Which PLC system uses the IC697PWR748?
The module is intended for compatible GE Fanuc Series 90-70 PLC systems.
Does the IC697PWR748 control field devices directly?
No. The power module supplies electrical power to the PLC system. Field-device control is performed by the appropriate Series 90-70 CPU and output modules.
Why is the power module important in a PLC system?
The CPU, I/O, and communication modules depend on stable electrical power. A properly functioning power module helps maintain reliable controller operation and prevents power-related interruptions.
What should be checked before replacing the module?
Engineers should verify the model number, electrical requirements, rack compatibility, total rack load, wiring configuration, grounding, and environmental conditions before installing a replacement.
Can the module be used in a new PLC system?
The Series 90-70 is a legacy PLC platform, so new system designs should carefully evaluate current controller technologies and lifecycle requirements. However, compatible power modules remain relevant for maintaining existing Series 90-70 installations.
What are common symptoms of a power supply problem?
Potential symptoms can include PLC startup failure, unexpected controller resets, loss of I/O operation, communication interruptions, abnormal module status indications, or complete rack shutdown. Troubleshooting should begin by checking incoming power, wiring, grounding, rack connections, and the power module itself.
Maintenance and Troubleshooting
Regular inspection can help identify power-related problems before they result in production downtime.
Common Checks
Engineers should periodically inspect:
- Incoming power wiring
- Power terminals
- Grounding connections
- Rack connectors
- Cabinet temperature
- Ventilation paths
- Dust accumulation
- Signs of overheating
- Module condition
- PLC diagnostic information
Typical Troubleshooting Sequence
If the Series 90-70 PLC fails to start correctly:
Step 1 – Check Incoming Power
Confirm that the correct electrical supply reaches the PLC cabinet.
Step 2 – Inspect Wiring
Check terminals, connectors, conductors, and grounding connections for looseness or damage.
Step 3 – Inspect the Rack
Examine the rack and backplane connector for contamination, corrosion, or mechanical damage.
Step 4 – Check Module Status
Observe available status indicators and PLC diagnostics.
Step 5 – Check Rack Loading
Verify that the installed modules do not exceed the available power capacity.
Step 6 – Check Environmental Conditions
Excessive heat, dust, humidity, or poor ventilation can contribute to power supply problems.
Step 7 – Verify the Power Module
If external power, wiring, rack configuration, and environmental conditions are satisfactory, the power module may require further testing or replacement.
Only qualified personnel should perform electrical measurements and replacement work on energized industrial equipment.
Conclusion
The GE IC697PWR748 Power Module is an important power supply component for compatible GE Fanuc Series 90-70 PLC systems. By providing stable electrical power to the PLC rack, it supports the operation of CPUs, I/O modules, communication equipment, and other control components required for industrial automation.
With dimensions of approximately 200 × 55 × 145 mm and a weight of approximately 1.3 kg, the module provides a compact rack-mounted solution for existing Series 90-70 control cabinets. Its role as a reliable PLC power source makes it particularly valuable in legacy automation systems where maintaining existing control infrastructure is more practical than replacing the entire PLC architecture.
For replacement and maintenance projects, engineers should always verify the complete electrical and hardware configuration before installation. When correctly integrated with Series 90-70 racks, CPU modules, I/O systems, communication modules, HMI equipment, and industrial field devices, the IC697PWR748 can support stable PLC operation and dependable industrial process control.
