Product Overview
The GE IC697PWR710 is a Series 90-70 PLC rack-mounted power supply module designed to provide regulated DC power to all modules installed in a PLC baseplate. It converts AC or DC input into stable 5 VDC backplane power, which is essential for CPU, I/O, and communication module operation.
It is commonly used in industrial automation systems requiring reliable rack-level power distribution.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE (GE Fanuc / Emerson) |
| Model | IC697PWR710 |
| Product Type | PLC Power Supply Module |
| System Series | Series 90-70 |
| Input Voltage | 120/240 VAC or 125 VDC |
| Input Voltage Range | 90–264 VAC / 100–150 VDC |
| Output Voltage | 5.1 VDC (regulated) |
| Output Power | ~56 W max |
| Output Current | Up to ~11 A @ 5 VDC |
| Power Factor | >0.95 |
| Protection | Overvoltage & overcurrent protection |
| Ride-through Time | ~21 ms |
| Backplane Location | Leftmost slot in rack |
| System Support | VME-based backplane architecture |
| Mounting Type | Rack-mounted module |
| Material | Industrial-grade electronics |
| Dimensions | 111.5 × 381 × 165.1 mm |
| Weight | 1.36 kg |
Function and Working Principle
The IC697PWR710 operates as the primary DC power source for the PLC rack backplane.
Its working process includes:
- Accepting AC (120/240V) or DC (125V) input power
- Converting input into regulated 5.1 VDC output
- Supplying backplane power to all installed modules
- Maintaining voltage stability under load fluctuations
- Providing protection against overcurrent and overvoltage conditions
- Ensuring safe operation during brief power interruptions (ride-through capability)
This makes it essential for stable PLC system operation.
Role in Industrial Control Systems
Within GE Series 90-70 systems, the IC697PWR710 provides:
- Centralized rack power distribution
- Stable 5V logic power for CPU and I/O modules
- Electrical protection and system stability
- Support for multi-module PLC configurations
- Reliable operation in continuous industrial environments
Industrial Applications
The IC697PWR710 is commonly used in:
- Large-scale manufacturing automation
- Process control industries (oil & gas, chemical, refining)
- Power generation systems
- Water treatment facilities
- Industrial machinery control systems
- High-reliability PLC rack installations
Installation and System Integration
Recommended installation practices include:
- Installing in the leftmost slot of Series 90-70 rack
- Connecting to 120/240 VAC or 125 VDC input source
- Ensuring proper grounding for noise immunity
- Verifying total system load does not exceed ~56 W output capacity
- Using correct rack and backplane compatibility
Compatible System Components
The IC697PWR710 typically works with:
- GE Series 90-70 CPU modules
- Digital and analog I/O modules
- Communication modules (Genius, Ethernet via expansion)
- Rack backplane assemblies
- Industrial SCADA systems
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| IC697PWR710 | Power Supply | 56 W rack power module | Series 90-70 systems |
| IC697PWR711 | Power Supply | Higher/lower revision variant | Similar racks |
| IC695PSA040 | RX3i Power Supply | Modern universal backplane PSU | RX3i systems |
| IC694PWR321 | Power Module | Remote rack power supply | RX3i distributed systems |
| IC693PWR324 | Power Supply | Legacy flexible PSU | 90-30 systems |
Key Advantages
- Stable regulated 5.1 VDC output
- Wide AC/DC input compatibility
- High reliability for continuous operation
- Built-in electrical protection features
- Supports multi-module rack systems
- Industrial-grade durability
Technical FAQs
What is the IC697PWR710 used for?
It supplies regulated 5V power to Series 90-70 PLC rack modules.
Can it power multiple racks?
Yes, in some configurations, if total load is within limits.
What is its output voltage?
5.1 VDC regulated output.
Where is it installed?
In the leftmost slot of the PLC baseplate.
Conclusion
The GE IC697PWR710 is a critical rack power supply module for Series 90-70 PLC systems. With stable 5V output, strong protection features, and reliable industrial design, it ensures consistent operation of all PLC modules in demanding automation environments.
