Product Overview
The GE IC697CHS750 5-Slot Rear I/O Rack is an industrial PLC rack designed for use with compatible GE Fanuc Series 90-70 automation systems. It provides a physical and electrical platform for installing PLC modules and organizing the control hardware within an industrial cabinet.
In a modular PLC architecture, the rack is more than a mechanical enclosure. It provides the structural foundation that allows compatible processors, I/O modules, communication modules, and other system components to operate together as an integrated control system.
The IC697CHS750 features a 5-slot rear I/O rack configuration, making it suitable for control systems that require several Series 90-70 modules while maintaining a compact hardware arrangement.
The rear I/O design also helps separate field wiring and module installation requirements from the front-facing control hardware, contributing to an organized industrial cabinet layout.
With dimensions of 260 × 410 × 150 mm and a specified weight of 4.01 kg, the IC697CHS750 is suitable for industrial control cabinets where a robust rack structure and dependable module integration are required.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc / GE |
| Model | IC697CHS750 |
| Product Type | 5-Slot Rear I/O Rack |
| Product Family | Series 90-70 |
| Rack Type | Rear I/O Rack |
| Number of Slots | 5 |
| Primary Function | PLC module mounting and system interconnection |
| Application | Industrial PLC and automation systems |
| Installation | Industrial control cabinet |
| Dimensions | 260 × 410 × 150 mm |
| Weight | 4.01 kg |
| System Architecture | Modular PLC |
| Module Integration | Series 90-70 compatible modules |
| Mounting | Cabinet / rack-mounted |
| Operating Environment | Industrial automation |
| Service Application | PLC installation, expansion, maintenance and replacement |
Function and Working Principle
The GE IC697CHS750 provides the mechanical and electrical infrastructure required to install compatible Series 90-70 modules.
Unlike a CPU or communication module, the rack itself does not execute application logic. Instead, it provides the physical mounting structure and system interconnection required for the installed modules.
A simplified PLC structure can be represented as:
Power Supply + CPU + I/O Modules + Communication Modules → IC697CHS750 Rack → Field Control System
The rack provides dedicated module positions and connects the installed components through the appropriate backplane architecture.
This allows the PLC system to operate as an integrated unit.
The rack’s functions include:
- Supporting compatible PLC modules
- Providing module mounting positions
- Establishing electrical interconnections
- Organizing PLC hardware
- Supporting I/O system expansion
- Simplifying cabinet installation
- Providing a structured platform for PLC maintenance
The five-slot arrangement allows engineers to configure a compact PLC system according to the application’s requirements.
Role in Industrial Control Systems
The IC697CHS750 is a foundational component of the Series 90-70 PLC architecture.
A typical installation may contain:
- Series 90-70 CPU
- Power Supply Module
- Digital Input Modules
- Digital Output Modules
- Analog Input Modules
- Analog Output Modules
- Communication Modules
- Bus Controllers
- Interface Modules
- Industrial network equipment
The rack holds the appropriate modules and provides the internal system connections required for coordinated operation.
For example, an automation system may use one slot for a CPU, another for a communication module, and additional slots for digital or analog I/O. The IC697CHS750 provides the physical platform for organizing these components within the control cabinet.
This modular architecture allows system designers to configure the PLC according to the number and type of control functions required.
Industrial Applications
The GE IC697CHS750 can be used in a broad range of industrial automation applications.
Manufacturing Automation
Factory production lines frequently require modular PLC systems containing processors, I/O modules, and communication interfaces. The five-slot rack provides a structured platform for these components.
Machine Control
Automated machines can use a compact PLC rack to house the controller and associated I/O hardware required for machine sequencing.
Process Automation
Industrial processes may require multiple analog and digital I/O modules to monitor and control pumps, valves, motors, and instrumentation.
Material Handling
Conveyor systems, sorting equipment, and automated storage systems can use modular PLC hardware installed within a structured rack.
Packaging Automation
Packaging machinery often requires coordinated control of sensors, motors, actuators, and communication devices. A compact rack can simplify the installation of the associated PLC hardware.
Utility Systems
Water treatment, power infrastructure, and other utility applications can use modular PLC architectures to provide centralized and distributed control.
Installation and System Integration
The IC697CHS750 should be installed as part of a compatible GE Series 90-70 PLC system.
Before installation, engineers should verify:
- Rack compatibility
- Number of required modules
- Power supply requirements
- CPU configuration
- I/O module arrangement
- Communication module requirements
- Cabinet dimensions
- Mounting hardware
- Grounding requirements
- Environmental conditions
Basic Installation Procedure
- Isolate the PLC system from power according to approved safety procedures.
- Confirm the IC697CHS750 rack model.
- Inspect the rack for mechanical damage.
- Install the rack securely inside the control cabinet.
- Verify adequate clearance for module installation and wiring.
- Install the appropriate Series 90-70 modules.
- Confirm that each module is correctly seated.
- Install the required power supply and controller hardware.
- Connect associated field and communication wiring.
- Verify grounding and cabinet bonding.
- Restore system power.
- Check module status indicators.
- Verify PLC communication and I/O operation.
- Perform controlled system commissioning.
The physical location of the rack should provide adequate ventilation and allow technicians to access modules and wiring for future maintenance.
Compatible System Components
The IC697CHS750 is designed to work with a range of compatible Series 90-70 components.
| Component | Function |
|---|---|
| Series 90-70 CPU | Executes PLC control logic |
| Series 90-70 Power Supply | Provides system operating power |
| Digital Input Modules | Receive discrete field signals |
| Digital Output Modules | Control discrete field devices |
| Analog Input Modules | Acquire analog process values |
| Analog Output Modules | Generate analog control signals |
| Bus Controllers | Provide industrial bus communication |
| Communication Modules | Connect the PLC to external networks |
| I/O Interface Modules | Integrate distributed I/O |
| Driver Interface Modules | Support drive-related system integration |
| Remote I/O Equipment | Extends field-level I/O |
| HMI | Provides operator monitoring and control |
The final module arrangement should be determined by the actual Series 90-70 application and system configuration.
Recommended Alternative Models
The following GE products can be considered when evaluating related PLC rack, controller, and system integration requirements.
| Model | Type | Key Feature | Application |
|---|---|---|---|
| GE IC697CHS750 | 5-Slot Rear I/O Rack | Compact five-slot PLC rack | Series 90-70 automation |
| GE IC697BEM771 | Bus Controller | Industrial bus communication | Distributed control |
| GE IC697BEM761 | I/O Interface Module | Distributed I/O integration | PLC systems |
| GE IC697BEM763 | Driver Interface Module | Drive system interface | Machine automation |
| GE IC697CGR772 | Central Processing Unit | Central PLC processing | Series 90-70 control |
| GE IC697CGR935 | Single-Slot Controller Module | Compact controller architecture | Industrial automation |
| GE IC697CMM741 | Communication Module | PLC network communication | Industrial networking |
| GE IC697CMM742 | Ethernet Communication Module | Ethernet connectivity | Automation networks |
These models perform different functions and should not be assumed to be direct substitutes for the IC697CHS750. Rack compatibility and system architecture should always be verified before selection.
Key Advantages
- Five-slot configuration for compatible Series 90-70 modules
- Provides a structured PLC installation platform
- Supports modular industrial control architectures
- Provides mechanical and electrical module integration
- Suitable for compact control cabinet installations
- Supports system expansion and maintenance
- Compatible with a range of Series 90-70 automation components
- Dimensions of 260 × 410 × 150 mm
- Product weight of approximately 4.01 kg
- Suitable for manufacturing and process automation
- Supports organized PLC cabinet layouts
Technical FAQs
What is the GE IC697CHS750?
The GE IC697CHS750 is a 5-Slot Rear I/O Rack designed for compatible GE Fanuc Series 90-70 PLC systems.
What is the main function of IC697CHS750?
Its primary function is to provide the mechanical mounting structure and electrical interconnection required for compatible Series 90-70 PLC modules.
How many slots does IC697CHS750 have?
The IC697CHS750 is a 5-slot rack.
What are the dimensions of GE IC697CHS750?
The specified dimensions are 260 × 410 × 150 mm.
How much does IC697CHS750 weigh?
The specified product weight is approximately 4.01 kg.
Is IC697CHS750 a PLC CPU?
No. It is a PLC rack. The CPU, I/O modules, and communication modules are installed separately within the rack.
What modules can be installed in the rack?
Compatible Series 90-70 processors, I/O modules, communication modules, and interface equipment can be installed according to the system configuration.
Where is IC697CHS750 installed?
The rack is installed inside an industrial control cabinet or suitable equipment enclosure.
Why is the rack important in a PLC system?
The rack provides the mechanical support and electrical interconnection required for multiple PLC modules to operate as an integrated control system.
What should be checked before replacing IC697CHS750?
Engineers should verify rack compatibility, slot requirements, module configuration, cabinet dimensions, power supply arrangement, wiring, grounding, and the overall Series 90-70 system architecture.
Conclusion
The GE IC697CHS750 5-Slot Rear I/O Rack is a key hardware component for compatible GE Fanuc Series 90-70 PLC systems. Rather than performing control processing itself, the rack provides the mechanical structure and electrical interconnection required to integrate processors, I/O modules, communication interfaces, and other PLC components into a complete automation system.
With a five-slot configuration, dimensions of 260 × 410 × 150 mm, and a specified weight of approximately 4.01 kg, the IC697CHS750 provides a practical platform for modular PLC installations where organized hardware integration and efficient cabinet utilization are important.
The rack is suitable for manufacturing automation, machine control, process automation, packaging, material handling, and utility applications. Its modular design allows engineers to configure a PLC system according to the required combination of controller, I/O, communication, and interface functions.
For maintenance engineers and system integrators, correct rack selection is essential because the rack determines how compatible Series 90-70 modules are physically and electrically integrated. Before installation or replacement, the required module count, system configuration, cabinet space, power arrangement, and compatibility of all installed components should be carefully verified.
