Product Overview
The GE IC697CGR772 Central Processing Unit (CPU) is a specialized controller designed for the GE Fanuc Series 90-70 PLC platform. As the central processing component of an industrial automation system, the CPU executes the user application program, processes input information, manages control logic, and generates output commands for connected field equipment.
In a PLC-based automation system, the CPU acts as the primary decision-making component. Signals collected from sensors and input modules are processed according to the programmed control logic. The resulting commands are then transferred to output modules, drives, actuators, and other control devices.
The IC697CGR772 is designed for applications requiring dependable PLC processing within industrial environments. It can form part of a larger control architecture containing I/O modules, communication interfaces, power supplies, operator interfaces, and distributed automation equipment.
Its role is especially important in applications where continuous and predictable control processing is required, including manufacturing equipment, machine automation, process systems, material handling, and other industrial control installations.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc / GE |
| Model | IC697CGR772 |
| Product Type | Central Processing Unit |
| Product Family | Series 90-70 |
| Primary Function | PLC program execution and control processing |
| Controller Type | Industrial PLC CPU |
| Application | Industrial automation and machine control |
| Installation | Series 90-70 PLC rack |
| Dimensions | 198 × 40 × 145.5 mm |
| Weight | 0.77 kg |
| System Architecture | Programmable Logic Controller |
| Processing Role | Central control and logic execution |
| I/O Integration | Compatible Series 90-70 I/O architecture |
| Communication | Dependent on system configuration |
| Mounting | Rack-mounted |
| Operating Environment | Industrial control environment |
| Service Application | PLC maintenance, replacement and system upgrades |
Function and Working Principle
The main function of the GE IC697CGR772 is to execute the PLC control program and coordinate the operation of the connected automation system.
The CPU receives information from input devices and I/O modules. It processes this information according to the application logic stored in the controller and then generates appropriate commands for output devices.
A simplified PLC control cycle can be represented as:
Field Sensors → Input Modules → IC697CGR772 CPU → Output Modules → Actuators
During normal operation, the CPU repeatedly performs control-processing tasks.
These tasks can include:
- Reading input states
- Processing programmed logic
- Executing control sequences
- Updating output commands
- Monitoring system status
- Processing internal variables
- Managing communication tasks
- Handling diagnostic information
- Coordinating connected automation equipment
The CPU therefore serves as the central processing point of the PLC system.
For example, a production machine may use sensors to detect the position of a product. The input module transfers this information to the CPU. The IC697CGR772 processes the signal according to the programmed sequence and then commands an output device to operate a motor, valve, cylinder, or other actuator.
This continuous processing cycle allows the automation system to respond to changing process conditions.
Role in Industrial Control Systems
The IC697CGR772 serves as the central control processor in a compatible Series 90-70 PLC architecture.
A complete system can contain:
- Series 90-70 CPU
- PLC power supply
- Main PLC rack
- Digital input modules
- Digital output modules
- Analog input modules
- Analog output modules
- Communication modules
- Interface modules
- Remote I/O
- Human Machine Interface (HMI)
- Industrial drives
- Sensors and actuators
The CPU coordinates these components by executing the application program and managing the flow of control information.
For a distributed automation system, the CPU may receive information from several I/O areas while simultaneously exchanging information with other system components.
This makes the processor one of the most important components in the PLC architecture.
Industrial Applications
The GE IC697CGR772 can be used in a variety of industrial automation applications where Series 90-70 PLC control processing is required.
Manufacturing Automation
Production lines require coordinated control of sensors, conveyors, motors, actuators, and inspection equipment. The CPU processes the machine logic required to synchronize these operations.
Machine Control
Automated machinery can use the PLC CPU to execute sequential operations, monitor safety-related process conditions, and control motors, valves, cylinders, and other equipment.
Material Handling
Conveyor systems, sorting equipment, automated storage systems, and transfer machines can use PLC processing to coordinate movement and monitor field conditions.
Process Automation
Industrial processes may use PLC CPUs to monitor process values and control pumps, fans, valves, motors, and other equipment.
Packaging Systems
Packaging machinery requires accurate sequencing between sensors, motors, actuators, and product-handling equipment. The CPU provides the processing required for these coordinated operations.
Installation and System Integration
The IC697CGR772 is designed for installation in a compatible GE Series 90-70 PLC rack.
Because the CPU is the central processing component, correct installation and configuration are particularly important.
Before installation, verify:
- Series 90-70 rack compatibility
- Power supply condition
- CPU model identification
- Existing PLC configuration
- Program and configuration backup
- I/O module arrangement
- Communication configuration
- Connector condition
- Cabinet environmental conditions
Basic Installation Procedure
- Place the PLC system into a safe maintenance condition.
- Back up the existing PLC program and configuration whenever possible.
- Disconnect system power according to approved electrical safety procedures.
- Verify that the replacement CPU is the correct IC697CGR772 model.
- Inspect the rack connector and module contacts.
- Install the CPU into the appropriate rack position.
- Secure the module properly.
- Restore the required power connections.
- Power up the PLC system.
- Observe CPU status and diagnostic indicators.
- Verify the PLC hardware configuration.
- Load or restore the appropriate control program if required.
- Check I/O communication.
- Verify communication with connected devices.
- Perform controlled functional testing before returning the machine to normal operation.
For legacy PLC systems, maintaining a complete backup of the existing application program and configuration is especially important before replacing a CPU.
Compatible System Components
The IC697CGR772 operates as part of a larger Series 90-70 control system.
| Component | Function |
|---|---|
| Series 90-70 Power Supply | Provides electrical power to the PLC system |
| Series 90-70 Rack | Provides mechanical and electrical module integration |
| Digital Input Modules | Receive discrete field signals |
| Digital Output Modules | Control discrete field equipment |
| Analog Input Modules | Acquire analog process signals |
| Analog Output Modules | Generate analog control signals |
| Communication Modules | Provide industrial network communication |
| I/O Interface Modules | Connect the PLC with distributed I/O equipment |
| Bus Controllers | Support distributed network architectures |
| Remote I/O | Extends field signal acquisition |
| HMI | Provides operator monitoring and control |
| Industrial Drives | Control motors and machine movement |
The exact combination depends on the application and the original Series 90-70 system design.
Recommended Alternative Models
The following GE Series 90-70 processors and associated control products may be considered when evaluating maintenance or modernization options. They should not be treated as automatic direct replacements without checking system compatibility.
| Model | Type | Key Feature | Application |
|---|---|---|---|
| GE IC697CGR772 | Central Processing Unit | Central PLC processing | Series 90-70 control systems |
| GE IC697CPU782 | CPU Module | High-performance PLC processing | Industrial automation |
| GE IC697CPU788 | CPU Module | Advanced PLC control | Complex automation systems |
| GE IC697CPU780 | CPU Module | Series 90-70 processing | Machine and process control |
| GE IC697CPU771 | CPU Module | PLC control processing | General automation |
| GE IC697BEM771 | Bus Controller | Industrial bus communication | Distributed automation |
| GE IC697BEM761 | I/O Interface Module | I/O integration | Distributed I/O systems |
| GE IC697CMM742 | Ethernet Communication Module | Network connectivity | Industrial communication |
When selecting an alternative CPU, engineers should verify the application program, memory requirements, I/O configuration, communication architecture, firmware compatibility, and overall system requirements.
Key Advantages
- Provides central PLC processing for compatible Series 90-70 systems
- Executes programmed industrial control logic
- Coordinates input and output operations
- Supports integration with distributed I/O and automation equipment
- Suitable for manufacturing and machine-control applications
- Supports process and material-handling automation
- Rack-mounted industrial design
- Dimensions of 198 × 40 × 145.5 mm
- Product weight of approximately 0.77 kg
- Suitable for maintenance and replacement applications
- Can serve as the central processing component of a Series 90-70 PLC system
Technical FAQs
What is the GE IC697CGR772?
The GE IC697CGR772 is a Central Processing Unit (CPU) designed for compatible GE Fanuc Series 90-70 PLC systems.
What is the main function of IC697CGR772?
Its main function is to execute the PLC application program, process input information, and generate control commands for connected output devices.
Is IC697CGR772 an I/O module?
No. The IC697CGR772 is the central processing unit. Separate input and output modules are used to connect the PLC system to field devices.
What are the dimensions of GE IC697CGR772?
The specified dimensions are 198 × 40 × 145.5 mm.
How much does IC697CGR772 weigh?
The specified product weight is approximately 0.77 kg.
Where is IC697CGR772 installed?
The CPU is installed in a compatible GE Series 90-70 PLC rack.
What equipment works with IC697CGR772?
The CPU can operate as part of a Series 90-70 system containing power supplies, PLC racks, I/O modules, communication modules, interface modules, remote I/O, HMIs, drives, sensors, and actuators.
What should be backed up before replacing IC697CGR772?
The PLC application program, hardware configuration, communication settings, and other relevant controller data should be backed up whenever possible before CPU replacement.
Can IC697CGR772 control industrial machines?
Yes. As the central processor of a compatible PLC system, it can execute control logic used to coordinate industrial machinery and processes.
What should be checked when selecting a replacement CPU?
The CPU model, system configuration, program requirements, memory requirements, I/O architecture, communication functions, and compatibility with the existing Series 90-70 installation should all be verified.
Conclusion
The GE IC697CGR772 Central Processing Unit is a central control component designed for compatible GE Fanuc Series 90-70 PLC systems. It performs the core processing functions required to execute application logic, evaluate input information, control outputs, and coordinate industrial automation equipment.
With dimensions of 198 × 40 × 145.5 mm and a specified weight of approximately 0.77 kg, the IC697CGR772 provides a compact rack-mounted solution for industrial PLC control applications.
Its role makes it suitable for manufacturing automation, machine control, material handling, packaging systems, and process automation. When integrated with appropriate I/O modules, power supplies, communication equipment, HMIs, and field devices, the CPU can form the central processing element of a complete industrial control system.
For maintenance engineers and system integrators, CPU replacement requires more than simply matching the physical dimensions. The existing PLC program, hardware configuration, I/O architecture, communication settings, and system requirements should be carefully reviewed before commissioning the replacement unit. Proper configuration and controlled testing are essential for restoring stable and reliable automation system operation.
