Product Overview

Accurate analog signal acquisition is essential in industrial automation systems where process variables such as pressure, flow, temperature, level, and other continuously changing measurements must be monitored by a PLC. The GE IC697ALG440 Analog Input Current Expansion Module is designed to provide additional analog current input capability for GE Fanuc Series 90-70 PLC control systems.

The IC697ALG440 expands the analog signal-processing capability of a Series 90-70 system by providing an interface between industrial field instruments and the PLC. It is intended for applications where current-based analog signals from field transmitters need to be acquired and processed by the control system.

In a typical industrial installation, field instruments measure physical process conditions and generate standardized analog current signals. The IC697ALG440 receives these signals and converts the electrical measurements into digital data that can be processed by the PLC CPU.

This allows the control system to monitor continuously changing process conditions rather than simply detecting ON/OFF states.

The specified dimensions of the IC697ALG440 are 138 × 70 × 25 mm, with an approximate product weight of 0.64 kg. Its compact module design allows it to be integrated into the GE Series 90-70 PLC rack architecture.

The module can be useful in process-control applications involving analog current transmitters, including pressure transmitters, flow transmitters, level transmitters, temperature transmitters, and other compatible industrial instrumentation.

For automation engineers, system integrators, OEM machine builders, and maintenance teams supporting legacy GE Series 90-70 installations, the IC697ALG440 provides an additional analog signal interface for industrial measurement and control systems.

Technical Specifications

Function and Working Principle

The primary function of the IC697ALG440 is to receive compatible analog current signals from field devices and provide corresponding digital process information to the Series 90-70 PLC.

A simplified signal path can be represented as:

Field Transmitter → Analog Current Signal → IC697ALG440 → A/D Conversion → PLC CPU → Control Program

A field transmitter measures a physical process variable and generates a proportional electrical current signal.

The current signal is connected to an input channel of the IC697ALG440.

The module processes the incoming signal and converts the analog information into a digital representation.

The PLC CPU can then use this information for:

• Process monitoring
• Alarm generation
• Control calculations
• Interlocking
• HMI display
• Data logging
• Closed-loop control
• Production monitoring

Current-based analog signals are widely used in industrial instrumentation because they can provide reliable signal transmission over industrial wiring distances.

The IC697ALG440 therefore acts as an important interface between field instrumentation and the PLC’s digital processing environment.

For example, a pressure transmitter may continuously measure pressure inside a process vessel.

As the pressure changes, the transmitter changes its analog current output accordingly.

The IC697ALG440 receives the current signal and makes the corresponding measurement available to the PLC.

The PLC program can then compare the measured value against configured limits.

If the pressure becomes too high, the control system may generate an alarm or initiate a predefined control sequence.

The same principle can be applied to flow, level, temperature, and other process measurements supported by the system.

Role in Industrial Control Systems

The IC697ALG440 serves as an analog current signal interface within the GE Series 90-70 PLC architecture.

A typical system may include:

• GE Series 90-70 PLC CPU
• IC697ALG440 Analog Input Current Expansion Module
• PLC rack
• GE PLC power supply
• Analog current transmitters
• Pressure transmitters
• Flow transmitters
• Level transmitters
• Temperature transmitters
• Signal conditioners
• HMI
• SCADA system
• Communication modules
• Remote I/O equipment
• Industrial network components
• Programming workstation

The field transmitters measure physical process conditions.

Their analog current signals are connected to the IC697ALG440.

The module processes the incoming signals and supplies the corresponding data to the PLC.

The Series 90-70 CPU can then use the acquired information within its control program.

The HMI or SCADA system can display process values to operators, while the PLC can use the data for alarms, interlocks, sequencing, and automatic control.

This makes the IC697ALG440 particularly useful in systems requiring additional analog current signal capacity.

Industrial Applications

The GE IC697ALG440 can be used in industrial control systems where analog current measurements must be acquired by a Series 90-70 PLC.

Typical applications include:

• Process automation
• Manufacturing systems
• Chemical processing
• Petrochemical facilities
• Oil and gas applications
• Power generation
• Water and wastewater treatment
• Industrial pumping systems
• HVAC systems
• Material processing
• Production lines
• Industrial instrumentation
• Machine automation

Pressure Monitoring

Industrial pressure transmitters can provide analog current signals representing process pressure.

The IC697ALG440 transfers the corresponding measurement into the PLC system for monitoring and control.

The PLC can use the pressure value to generate alarms, control valves, operate pumps, or initiate process sequences.

Flow Monitoring

Flow transmitters can continuously measure liquid or gas flow.

The analog current output is acquired by the module and processed by the PLC.

This information can be used for flow monitoring, process control, and production calculations.

Level Monitoring

Tank and vessel level transmitters can provide analog current measurements representing liquid level.

The PLC can use the acquired information to control pumps, valves, alarms, and other process equipment.

Temperature Monitoring

Compatible temperature transmitters can convert measured temperature into an analog current signal.

The IC697ALG440 can acquire the signal so that the PLC can monitor process temperature and execute appropriate control logic.

Industrial Process Control

In larger process systems, numerous analog transmitters may be distributed throughout the facility.

Additional analog input capacity allows more field measurements to be incorporated into the PLC architecture.

Installation and System Integration

Proper installation is important for reliable analog current measurement.

Recommended installation practices include:

• Install the module in the appropriate Series 90-70 PLC rack.
• Verify PLC and rack compatibility before installation.
• Disconnect power before inserting or removing the module.
• Confirm the field signal type before wiring.
• Verify transmitter loop wiring.
• Check terminal connections carefully.
• Use suitable industrial instrumentation cable.
• Use shielded cable where appropriate.
• Keep analog signal cables away from high-power conductors.
• Avoid routing instrumentation cables directly alongside motor cables.
• Apply appropriate grounding practices.
• Configure the PLC according to the module requirements.
• Verify the expected input range.
• Confirm PLC scaling.
• Compare PLC values with calibrated field instruments.
• Check signal stability during commissioning.

Analog current signals can still be affected by poor wiring, grounding problems, electrical interference, damaged field cables, or transmitter faults.

Potential sources of interference include:

• Variable speed drives
• Large motors
• Contactors
• Switching equipment
• High-current conductors
• Poor grounding
• Improper shielding

For this reason, instrumentation wiring should be planned separately from high-power electrical wiring whenever practical.

During commissioning, engineers should verify the complete signal path.

A useful troubleshooting sequence is:

Field Instrument → Wiring → Input Channel → PLC Configuration → Signal Scaling → HMI/SCADA

If the measured value is incorrect, each stage should be checked systematically.

Compatible System Components

The IC697ALG440 is intended to operate as part of a GE Series 90-70 control system.

Typical associated components include:

• GE Series 90-70 PLC CPU
• Series 90-70 PLC rack
• GE PLC power supply
• Analog input modules
• Analog current transmitters
• Pressure transmitters
• Flow transmitters
• Level transmitters
• Temperature transmitters
• Signal conditioners
• HMI systems
• SCADA systems
• PLC communication modules
• Remote I/O equipment
• Industrial network components
• Programming terminals
• Industrial control cabinets

A typical signal architecture can be represented as:

Field Transmitter → IC697ALG440 → Series 90-70 CPU → HMI / SCADA / Control System

The transmitter measures the physical process.

The IC697ALG440 receives the analog current signal.

The PLC processes the acquired value.

The HMI or SCADA system can then display the process information to the operator.

The PLC can also use the measurement for control calculations, alarms, interlocks, and automated sequences.

Recommended Alternative Models

Depending on the existing Series 90-70 system, signal requirements, and application, the following related analog input modules may be considered:

Alternative modules should not be selected only according to physical dimensions or general product descriptions.

Before selecting a replacement or alternative, engineers should verify:

• Input signal type
• Current range
• Number of channels
• Resolution
• Accuracy
• Isolation
• Wiring arrangement
• Rack compatibility
• PLC CPU compatibility
• Software configuration
• Environmental requirements

The electrical characteristics of an analog input module are particularly important. A module designed for one signal type or range may not be a suitable replacement for another module even when the physical dimensions are similar.

Key Advantages

• Designed for GE Series 90-70 PLC systems
• Analog current signal acquisition
• Provides additional analog input capability
• Interfaces with compatible industrial transmitters
• Supports process measurement applications
• Suitable for pressure monitoring
• Suitable for flow monitoring
• Suitable for level monitoring
• Suitable for temperature monitoring
• Supports continuous process-variable acquisition
• Converts analog information into PLC-processable data
• Suitable for PLC-based industrial control
• Compact module construction
• Dimensions of 138 × 70 × 25 mm
• Weight of approximately 0.64 kg
• Suitable for industrial automation
• Compatible with HMI and SCADA architectures
• Useful for OEM applications
• Useful for system integration
• Suitable for maintenance and replacement projects

Technical FAQs

What is the GE IC697ALG440?

The GE IC697ALG440 is an Analog Input Current Expansion Module designed for integration with GE Fanuc Series 90-70 PLC systems.

What does the IC697ALG440 do?

It provides additional analog current input capability, allowing compatible field transmitters to send continuously varying process measurements to the PLC.

What type of signals does the IC697ALG440 handle?

The IC697ALG440 is designed for analog current signals from compatible industrial instrumentation.

What are typical field devices connected to an analog current input?

Typical devices include pressure transmitters, flow transmitters, level transmitters, temperature transmitters, and other compatible industrial process transmitters.

What are the dimensions of the IC697ALG440?

The specified dimensions are 138 × 70 × 25 mm.

How much does the IC697ALG440 weigh?

The specified product weight is approximately 0.64 kg.

Is the IC697ALG440 a digital input module?

No. It is an analog input current module, designed to acquire continuously varying current signals rather than simple ON/OFF signals.

Can the IC697ALG440 be used with a Series 90-70 PLC?

Yes. The module is designed for the GE Fanuc Series 90-70 PLC architecture.

Why are current signals widely used in industrial automation?

Current-based analog signals are commonly used for industrial instrumentation because they can provide reliable transmission of measurement information over field wiring distances and are widely supported by industrial transmitters.

Can the module be used for pressure monitoring?

Yes. Compatible pressure transmitters can provide analog current signals that the module acquires for PLC-based monitoring and control.

Can the module be used for closed-loop control?

The analog measurements acquired by the IC697ALG440 can be processed by the PLC and used as feedback information in appropriately designed closed-loop control applications.

What should be checked before replacing the IC697ALG440?

Engineers should verify the input signal type, current range, channel configuration, resolution, accuracy, isolation, wiring requirements, Series 90-70 compatibility, software configuration, and environmental requirements.

Conclusion

The GE IC697ALG440 Analog Input Current Expansion Module is designed to provide additional analog current signal acquisition capability within GE Fanuc Series 90-70 PLC systems.

By interfacing compatible field transmitters with the PLC, the module allows continuously changing process variables such as pressure, flow, level, and temperature to be acquired and processed by the automation system.

The IC697ALG440 has specified dimensions of 138 × 70 × 25 mm and an approximate weight of 0.64 kg, making it a compact component for Series 90-70 rack-based installations.

When integrated with a Series 90-70 CPU, PLC rack, power supply, analog transmitters, HMI, SCADA system, and other industrial automation components, the IC697ALG440 can provide an effective interface for process measurement and monitoring.

For maintenance engineers and system integrators working with existing GE Series 90-70 installations, careful verification of signal type, wiring, module configuration, PLC compatibility, and signal scaling is essential before installation or replacement.
