Product Overview
The GE IC697ACC624 Rack Fan Assembly is an industrial cooling module designed for GE Series 90-70 and RX7i PLC rack systems. It is used to maintain optimal operating temperature inside PLC cabinets by providing forced-air cooling across backplane-mounted modules such as CPUs, I/O cards, and communication modules.
This component is essential in environments where heat buildup could affect system stability, reliability, or lifespan of electronic modules.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE (GE Fanuc / Emerson) |
| Model | IC697ACC624 |
| Product Type | Rack Fan Assembly |
| System Compatibility | Series 90-70 / RX7i racks |
| Function | Forced-air rack cooling |
| Fan Quantity | Dual fan assembly |
| Input Voltage | 120/240 VAC (varies by version) |
| Frequency | 50–60 Hz |
| Power Consumption | ~16–20 W per fan |
| Airflow | High-efficiency rack airflow (system dependent) |
| Noise Level | Low-noise industrial design |
| Filter | Replaceable foam air filter |
| Mounting Type | Rack-mounted assembly |
| Compatibility | IC697CHS750, IC697CHS109, IC698CHS009 |
| Operating Temperature | -28°C to +60°C |
| Material | Industrial metal/plastic housing |
| Dimensions | 483 × 89 × 159 mm |
| Weight | 1.36 kg |
Function and Working Principle
The IC697ACC624 operates as a forced ventilation system for PLC racks.
Its working process includes:
- Drawing ambient air into the rack enclosure
- Passing airflow across heat-generating modules (CPU, I/O, communication cards)
- Removing excess heat through exhaust airflow
- Maintaining stable internal rack temperature
- Preventing thermal shutdown or performance degradation
The dual-fan configuration ensures continuous airflow even if one fan experiences reduced performance.
Role in Industrial Control Systems
Within GE PLC systems, the IC697ACC624 provides:
- Thermal protection for rack-mounted PLC components
- Improved system reliability under continuous operation
- Extended lifespan of electronic modules
- Stable operating environment for high-density racks
- Prevention of overheating-related system faults
Industrial Applications
The IC697ACC624 is widely used in:
- Large industrial automation control cabinets
- Manufacturing production lines
- Power generation and distribution systems
- Oil & gas processing facilities
- Water treatment and pumping stations
- High-density PLC rack installations
Installation and System Integration
Recommended installation practices include:
- Mounting directly onto compatible GE rack systems
- Ensuring proper airflow direction (bottom-to-top cooling design)
- Maintaining minimum spacing between racks for airflow
- Regular cleaning or replacement of air filters
- Wiring fan power to PLC-controlled or dedicated supply source
Compatible System Components
The IC697ACC624 typically works with:
- GE Series 90-70 PLC racks (IC697CHS series)
- RX7i rack systems
- CPU modules and I/O modules
- Communication modules
- Industrial control cabinet ventilation systems
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| IC697ACC624 | Rack Fan Assembly | Dual-fan cooling system | GE 90-70 / RX7i racks |
| IC697ACC724 | Fan Assembly | Enhanced cooling version | Larger rack systems |
| IC694PWR321 | Power Module | Rack power supply | RX3i systems |
| Cabinet Cooling Fans (Generic) | Cooling Unit | Cabinet-level cooling | Non-GE systems |
| IC695PSA040 | Power Supply | RX3i backplane power | System power support |
Key Advantages
- Efficient dual-fan rack cooling design
- Improves PLC system reliability
- Prevents overheating of critical modules
- Supports continuous 24/7 operation
- Replaceable filters for maintenance
- Compatible with multiple GE rack types
Technical FAQs
What is the IC697ACC624 used for?
It is used to cool GE PLC racks and prevent overheating of modules.
Is it required for all PLC systems?
No, only for high-density rack systems where heat buildup is significant.
Can filters be replaced?
Yes, the air filter is replaceable and maintainable.
What happens if it fails?
Overheating may occur, potentially causing PLC faults or shutdowns.
Conclusion
The GE IC697ACC624 Rack Fan Assembly is a critical thermal management component for GE Series 90-70 and RX7i PLC systems. With dual-fan airflow, industrial-grade durability, and effective heat dissipation, it ensures stable and reliable operation of PLC racks in demanding industrial environments.
