Product Overview
The GE IC695ALG626CA PACSystems RX3i Analog Input Module is an analog signal acquisition module used in GE PACSystems RX3i PLC systems. It provides the connection between industrial field instruments and the PLC control program by collecting continuous measurement signals from external devices.
Unlike discrete input modules that only identify switching conditions, the IC695ALG626CA processes variable analog signals generated by sensors and transmitters. It allows the RX3i controller to monitor real-time process values and use this information for control logic, alarm handling, data processing, and automation sequences.
The module is typically integrated into systems that require accurate process monitoring, including manufacturing equipment, process automation systems, and industrial machinery. It works together with RX3i CPUs, communication modules, output modules, and field instruments to build a complete automation control architecture.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE |
| Model | IC695ALG626CA |
| Product Family | PACSystems RX3i |
| Product Type | Analog Input Module |
| Module Function | Analog Signal Acquisition |
| Signal Role | Process Measurement Input |
| System Application | PLC Automation Control |
| Installation | PACSystems RX3i Rack System |
| Dimensions | 145 × 34 × 140 mm |
| Weight | 0.227 kg |
Product Features
The GE IC695ALG626CA PACSystems RX3i Analog Input Module provides analog measurement acquisition capability for industrial control systems.
Key characteristics include:
- GE PACSystems RX3i analog input module
- Model IC695ALG626CA
- Designed for continuous analog signal acquisition
- Converts field measurement signals into PLC process data
- Supports integration with RX3i controller systems
- Suitable for industrial monitoring applications
- Connects sensors and transmitters with PLC logic
- Supports modular automation system expansion
- Suitable for process and machine control applications
- Designed for long-term industrial operation
The module should be selected according to the required signal type, connected instruments, PLC configuration, and application requirements.
Working Principle
The IC695ALG626CA operates by receiving analog signals from field devices and converting them into digital values that can be processed by the PACSystems RX3i CPU.
A simplified signal path is:
Process Sensor → Analog Input Module → Signal Conversion → RX3i CPU → Control Program
During operation, industrial transmitters and sensors generate electrical signals representing physical conditions such as temperature, pressure, flow, or level. The analog input module receives these signals and converts them into usable data values for the PLC system.
The RX3i CPU then processes the acquired information according to the application program, enabling functions such as monitoring, regulation, alarms, and automated control.
The module acts as the measurement interface between field equipment and the PLC software layer.
Role in PACSystems RX3i Control Architecture
The IC695ALG626CA operates within the signal acquisition layer of the GE PACSystems RX3i automation structure.
A typical system layout can be represented as:
Field Instruments → Analog Input Module → RX3i CPU → Output Modules → Industrial Equipment
| System Layer | Typical Function |
|---|---|
| Sensors / Transmitters | Provide analog process measurements |
| Analog Input Module | Converts signals into PLC data |
| RX3i CPU | Executes control logic |
| Output Modules | Drive actuators and equipment |
| Communication Modules | Exchange automation data |
| Engineering Software | Configure and maintain PLC systems |
The module provides measurement information to the CPU but does not execute independent control programs.
Industrial Applications
The GE IC695ALG626CA PACSystems RX3i Analog Input Module is suitable for automation systems requiring continuous process data collection.
| Application | Typical Use |
|---|---|
| Process Automation | Monitoring operating parameters |
| Manufacturing Equipment | Collecting analog sensor feedback |
| Machine Control | Measuring equipment conditions |
| Water Treatment | Monitoring flow and level signals |
| Energy Systems | Acquiring operating data |
| Chemical Processing | Tracking process variables |
| Factory Automation | Expanding PLC input capability |
| Production Lines | Integrating field measurement devices |
The actual application depends on the connected instruments and the overall RX3i system design.
Installation and Maintenance
Correct configuration and wiring are important for maintaining stable analog signal processing.
Recommended maintenance checks include:
- Confirm the correct IC695ALG626CA model.
- Verify compatibility with the PACSystems RX3i rack.
- Check hardware configuration settings.
- Confirm module addressing.
- Inspect analog signal wiring.
- Verify sensor and transmitter connections.
- Check terminal connections.
- Monitor PLC diagnostic information.
- Verify signal stability.
- Inspect installation conditions.
- Record replacement information.
- Test system operation after installation.
If measurement values are inaccurate or unstable, troubleshooting should include field instruments, signal cables, grounding conditions, module configuration, and PLC program settings.
Related Components
The IC695ALG626CA works together with other GE PACSystems RX3i system components.
| Component | Function |
|---|---|
| GE PACSystems RX3i CPU | Executes PLC application logic |
| Analog Input Modules | Collect process measurement signals |
| Discrete Input Modules | Acquire digital status signals |
| Output Modules | Control external devices |
| Communication Modules | Provide network connectivity |
| Power Supply Modules | Supply rack operating power |
| Engineering Software | Configure PLC hardware |
| Field Transmitters | Provide analog measurement data |
These components together form a complete industrial automation control system.
Recommended Related Models
| Model / Product Family | Product Type | Typical Application |
|---|---|---|
| GE IC695ALG626CA | PACSystems RX3i Analog Input Module | Industrial analog signal acquisition |
| GE IC695ALG600 Series | RX3i Analog Input Modules | Process measurement applications |
| GE IC695ALG608 | RX3i Analog Input Module | Multi-channel analog monitoring |
| GE IC695ALG616 | RX3i Analog Input Module | Industrial signal processing |
| GE RX3i Discrete Input Modules | Digital Input Hardware | Machine status monitoring |
| GE RX3i Output Modules | Digital / Analog Output Hardware | Equipment control |
Selection should be based on signal requirements, channel configuration, field devices, and existing RX3i architecture.
Key Advantages
- GE PACSystems RX3i automation component
- Provides analog process signal acquisition
- Integrates with RX3i PLC control systems
- Supports real-time measurement monitoring
- Connects field instruments with PLC programs
- Suitable for modular automation expansion
- Supports industrial process applications
- Helps maintain existing RX3i installations
- Provides stable measurement data collection
- Suitable for long-term automation systems
Technical FAQs
What type of process information can the IC695ALG626CA collect?
The module is used for acquiring continuous analog measurements from industrial sensors and transmitters, allowing the PLC system to monitor changing process conditions.
How does an analog input module differ from a discrete input module in an RX3i system?
An analog input module processes variable measurement signals, while a discrete input module only detects binary states such as ON/OFF conditions.
What should be considered when connecting field transmitters to this module?
Signal type compatibility, wiring method, grounding conditions, PLC configuration, and transmitter settings should be verified before commissioning.
Why might an RX3i system show incorrect analog values after module replacement?
Incorrect configuration parameters, wiring errors, unsuitable signal settings, or problems with the connected field device can cause abnormal measurement readings.
