Product Overview
The GE IC693MDL732 Positive Logic Output Module is a DC digital output module designed for GE Series 90-30 PLC systems. It is used to control external field devices such as relays, solenoids, motor starters, and indicator lamps by providing controlled DC output signals.
This module operates using positive logic (sourcing output), meaning it supplies current from the module to the load, making it suitable for a wide range of industrial automation applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE |
| Model | IC693MDL732 |
| Product Type | Positive Logic Output Module |
| System Compatibility | GE Series 90-30 PLC |
| Slot Requirement | 1 slot |
| Output Type | DC digital output |
| Logic Type | Positive logic (sourcing) |
| Number of Outputs | 8 channels |
| Output Grouping | 1 group (common terminal configuration) |
| Rated Voltage | 12 / 24 VDC |
| Output Voltage Range | 12–24 VDC |
| Output Current | 0.5 A per point |
| Max Current per Common | 2 A |
| Response Time | ≤ 2 ms |
| Isolation | 1500 V field-to-backplane isolation |
| Leakage Current | ≤ 1 mA (off-state) |
| Inrush Current | High inrush capability (short duration loads) |
| Indicators | LED status per output channel |
| Protection | Internal electronic protection (no external fuses) |
| Communication | PLC backplane communication |
| Mounting Type | Rack-mounted |
| Material | Industrial-grade electronic module |
| Dimensions | 150 × 100 × 70 mm |
| Weight | 0.4 kg |
| Operating Environment | Industrial automation systems |
| Temperature Range | 0°C to 60°C |
Function and Working Principle
The IC693MDL732 operates as a DC output switching module within a PLC system.
Its working principle includes:
- Receiving output commands from the PLC CPU
- Switching DC power to external field devices
- Operating in positive logic (sourcing current to loads)
- Completing circuits by supplying voltage to connected devices
- Providing electrical isolation between control logic and field wiring
In practice, the load is connected between the module output and ground, and the module sources current when activated.
Role in Industrial Control Systems
Within GE Series 90-30 PLC systems, the IC693MDL732 plays a key output control role:
- Controls external actuators such as solenoids and relays
- Provides fast and reliable DC switching control
- Ensures electrical isolation between PLC and field devices
- Supports real-time automation logic execution
- Enhances system flexibility in machine control applications
Industrial Applications
The GE IC693MDL732 is widely used in:
- Industrial automation systems
- Manufacturing production lines
- Motor control systems
- Conveyor systems
- Solenoid valve control
- Indicator and alarm systems
Installation and System Integration
Recommended installation practices include:
- Installing in GE Series 90-30 PLC racks
- Wiring loads between module outputs and ground
- Using appropriate external DC power supply (12/24 VDC)
- Ensuring correct load current does not exceed 0.5 A per point
- Verifying common terminal wiring for group configuration
Proper installation ensures safe and reliable switching operation.
Compatible System Components
The IC693MDL732 typically works with:
- GE Series 90-30 CPU modules (IC693CPU series)
- Digital input modules
- Power supply modules
- Relays, solenoids, and motor starters
- Industrial control panels
- Alarm and indicator devices
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| IC693MDL732 | Output Module | 8-point DC positive logic | Standard control systems |
| IC693MDL730 | Output Module | Positive logic output | Similar sourcing control |
| IC693MDL731 | Output Module | Negative logic output | Sinking applications |
| IC693MDL740 | Output Module | Relay output | Flexible switching |
| IC693CPU364 | CPU Module | High-speed processing | Complex automation |
Key Advantages
- Reliable positive logic (sourcing) output design
- 0.5A per point output capability
- Fast switching response (~2 ms)
- Strong electrical isolation (1500 V)
- Suitable for inductive and resistive loads
- Stable operation in industrial environments
Technical FAQs
What is the main function of IC693MDL732?
It controls external DC devices by sourcing output current from the PLC.
What type of logic does it use?
It uses positive logic (sourcing output).
How many outputs does it have?
It provides 8 output channels.
What devices can it control?
It can control relays, solenoids, motors, and indicators.
Conclusion
The GE IC693MDL732 Positive Logic Output Module is a reliable and widely used DC output solution for GE Series 90-30 PLC systems. With stable sourcing output, fast response time, and strong isolation, it is ideal for industrial automation environments requiring precise and dependable output control.
