Product Overview
The GE IC670MDL740 Field Control Discrete Output Module is a discrete output module used to send on/off control signals from an industrial automation system to field devices.
In a typical control cabinet, the controller does not directly drive every solenoid, relay, indicator, or other discrete actuator. Instead, the control logic determines the required output state, and the I/O module handles the corresponding field-side output. The IC670MDL740 fits into this type of distributed I/O arrangement.
The module belongs to the GE Field Control family and is intended for systems where discrete commands need to be distributed between the controller and field equipment. Typical examples include switching a valve solenoid, activating an interposing relay, controlling machine actuators, or providing discrete operating commands to external equipment.
For maintenance engineers, the IC670MDL740 is best viewed as the interface between the control-system logic and the discrete devices installed in the field.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE |
| Model | IC670MDL740 |
| Product Type | Field Control Discrete Output Module |
| Product Family | Field Control |
| Main Function | Discrete Signal Output |
| System Role | Distributed I/O |
| Signal Type | Discrete Output |
| Application | Industrial Automation and Machine Control |
| Typical Use | Solenoids, Relays, Actuators and Discrete Control Devices |
| Dimensions | 103.9 × 50.3 × 150 mm |
| Weight | 0.3 kg |
Product Features
The IC670MDL740 is intended for applications where the control system needs to switch or command discrete field devices.
Key characteristics include:
- GE Field Control family
- Discrete output functionality
- Interfaces control logic with discrete field devices
- Suitable for distributed I/O installations
- Applicable to machine-control applications
- Suitable for actuator and relay control
- Can be used for solenoid-related control circuits
- Supports modular industrial control architectures
- Dimensions of 103.9 × 50.3 × 150 mm
- Stated weight of 0.3 kg
The actual field-device compatibility should be verified against the output characteristics, load requirements, wiring arrangement, and complete Field Control configuration.
Working Principle
A practical signal path can be represented as:
Controller → Field Control I/O Network → IC670MDL740 → Field Device → Machine / Process
The controller determines whether a particular output should be active or inactive according to the programmed control sequence. The Field Control system transfers that command to the corresponding output module.
The IC670MDL740 then switches the associated discrete output circuit according to the system command.
For example, in a packaging machine, the controller may issue an output command to energize a solenoid valve. The output module acts as the interface between the control-system command and the field circuit. Once the valve has operated, a separate discrete input can be used to monitor a related position or status signal.
This separation between control logic and field wiring makes troubleshooting more structured. When an actuator does not respond, the engineer can check the controller command, I/O communication, output channel, wiring, and field device individually.
Industrial Applications
The IC670MDL740 is suitable for industrial systems that require discrete commands to be sent to field equipment.
| Application | Typical Use |
|---|---|
| Packaging Machinery | Solenoid and actuator control |
| Material Handling | Conveyor and equipment commands |
| Machine Tools | Discrete machine functions |
| Assembly Equipment | Pneumatic and electrical actuator control |
| Process Equipment | Valve and auxiliary device control |
| Motor Control Panels | Relay and contactor interface |
| Production Lines | Machine sequence outputs |
| Industrial Automation | Distributed discrete control |
The module is particularly useful where field devices are distributed around a machine or process and need to be controlled through a centralized automation system.
Compatible System Components
The IC670MDL740 normally operates as part of a larger Field Control installation.
| Component | Function |
|---|---|
| IC670MDL740 | Sends discrete output commands |
| Field Control I/O Station | Provides the distributed I/O structure |
| Controller | Executes the control program |
| Solenoid Valve | Converts an electrical command into mechanical action |
| Interposing Relay | Interfaces the output with an external load |
| Contactor | Controls higher-power equipment circuits |
| Discrete Sensors | Provide feedback to the controller |
| I/O Terminal / Wiring | Connects output channels to field devices |
| Communication Network | Transfers I/O data between the controller and field system |
The output module should be selected together with the connected load and the complete Field Control architecture.
Installation and Maintenance
Before installing or replacing the IC670MDL740, the output circuit and connected field device should be identified. This is particularly important when multiple discrete outputs control similar actuators.
Recommended checks include:
- Confirm the complete IC670MDL740 part number.
- Verify the Field Control system configuration.
- Confirm the required output characteristics.
- Check the connected field-device load.
- Verify terminal wiring.
- Inspect connectors and terminals.
- Check module seating.
- Inspect field wiring for loose or damaged connections.
- Verify the associated I/O station.
- Check controller communication.
- Review output-channel diagnostics.
- Confirm the expected output state during commissioning.
- Check the connected relay, solenoid, or actuator if the output does not operate.
If an output device remains energized or fails to respond, the module should not immediately be assumed to be defective. The control command, channel configuration, wiring, external load, and field device should all be checked.
Recommended Related Models
For the IC670MDL740, related components should be selected according to the required output function and Field Control system architecture.
| Model / Component | Type | Primary Function | Application |
|---|---|---|---|
| GE IC670MDL740 | Discrete Output Module | Discrete control output | Field Control systems |
| GE IC670MDL640 | Discrete Input Module | Discrete signal acquisition | Equipment status and feedback |
| GE Field Control I/O Modules | I/O Module Family | Distributed signal processing | Industrial automation |
| GE Analog Input Modules | Input Module | Continuous signal acquisition | Process measurement |
| GE Field Control Interface Components | System Hardware | I/O communication and integration | Distributed I/O |
| GE Industrial Controllers | Controller | Control logic execution | Machine and process automation |
When selecting a replacement for the IC670MDL740, the output characteristics, connected load, Field Control architecture, wiring arrangement, and controller configuration should all be checked. Physical dimensions alone are not sufficient for determining compatibility.
Key Advantages
- Discrete output functionality
- GE Field Control architecture
- Suitable for distributed I/O
- Interfaces control logic with field actuators
- Suitable for solenoid and relay applications
- Useful for machine sequence control
- Supports modular automation installations
- Suitable for industrial control applications
- Dimensions of 103.9 × 50.3 × 150 mm
- Stated weight of 0.3 kg
Technical FAQs
What types of devices can the IC670MDL740 control?
Typical applications include compatible discrete loads such as solenoid-operated devices, relays, contactors, and other field actuators. The actual load must be checked against the module’s applicable output specifications before connection.
What should be checked if an output channel is commanded ON but the field device does not operate?
Check the controller command, I/O communication, output-channel status, terminal wiring, external power circuit, and the connected load. If these are correct, the output channel itself can then be investigated.
Why can an output module fault be confused with a field-device problem?
The output module is only one part of the control path. A damaged cable, failed relay, missing field power, open connection, or defective solenoid can produce symptoms similar to an I/O fault. Testing the signal path section by section helps isolate the actual problem.
Is the IC670MDL740 interchangeable with a discrete input module?
No. A discrete input module receives field status signals, while the IC670MDL740 sends control signals to field devices. They perform opposite I/O functions and should not be substituted based on physical compatibility alone.
