Product Introduction
The IS220PAICH1B is an Analog Input/Output Pack module designed for use within the Mark VIe distributed control system family. It functions as a high-performance analog I/O interface, converting analog signals from field sensors and transmitters (such as 4-20 mA loops, voltage inputs) into digital form for the control system, and providing analog output capability for control loops.
This module is engineered for process automation, power generation, turbine control, and other industrial automation applications where analog sensor data is critical. The pack features configurable input ranges, selectable output options, diagnostic indicators, and dual-Ethernet communication links, making it suitable for high-availability systems.
As part of the modular I/O rack architecture of Mark VIe systems, the IS220PAICH1B allows straightforward installation, replacement and integration, supporting both new builds and retrofits of analog I/O capabilities.
Technical Specifications
| Parameter | Description |
|---|---|
| Module Type | Analog I/O Pack (input and output) |
| Analog Input Channels | Up to ten analog inputs: first 8 configurable (5 V/10 V or 0-20 mA); last 2 configurable (1 mA or 0-20 mA) |
| Analog Output Channels | Two 0-20 mA current-loop outputs |
| Supply Voltage | Typical 24 V DC (or 22.8 V DC for transmitter power) |
| Communication Interfaces | Dual RJ-45 Ethernet ports for I/O network redundancy |
| Mounting Type | Plug-in module for Mark VIe I/O rack |
| Operating Temperature | –40 °C to +85 °C (depending on variant) |
| Storage Temperature | –40 °C to +85 °C |
| Dimensions | Approx. 133 mm × 70.8 mm × 39.3 mm (13.3 cm × 7.08 cm × 3.93 cm) |
| Weight | Approx. 1.0 kg |
| Certifications | Hazardous-area rating optionally Zone 2 Group IIC; UL listing |
| Diagnostics | LED indicators for status, fault and health monitoring |
Applications
The IS220PAICH1B module is suited for a variety of industrial applications where analog signal management is required:
-
In power generation plants (gas, steam turbines), it monitors analog signals such as temperature sensors, flow transmitters, pressure loops and provides analog outputs for valve control and actuator commanding.
-
In petrochemical, refining or chemical-process facilities, the module handles analog signal acquisition and control loop outputs for process variables such as level, concentration, temperature, or differential pressure.
-
In automated manufacturing or process industries, the module is integrated into I/O racks for large-scale analog monitoring and control, enabling system modularity and servicing ease.
-
In plant retrofits, when upgrading analog measurement and control capabilities, the IS220PAICH1B allows reuse of existing racks and networks while enhancing analog I/O performance.
-
In distributed control networks requiring redundancy and diagnostics, this module contributes to system reliability and maintainability by offering dual-Ethernet links and status monitoring.
Advantages
Choosing the IS220PAICH1B yields several strong benefits:
-
High flexibility: The ability to configure multiple input types (voltage or current) and two analog outputs means the module covers a wide range of analog sensor and actuator use-cases.
-
Compact size and moderate weight: With an approximate size of 13.3 × 7.08 × 3.93 cm and weight about 1.0 kg, the module is space-efficient in control racks.
-
Rugged industrial design: The wide operating temperature range (–40 °C to +85 °C) supports demanding environmental conditions. The module’s certification for hazardous areas (Zone 2 / Group IIC) further enhances suitability.
-
Redundant network support: Dual Ethernet ports allow redundant network paths, improving system availability and failure tolerance.
-
Maintenance and diagnostics friendliness: LED indicators provide visual health/diagnostics; plug-in design allows quick replacement; compatibility with Mark VIe rack system simplifies servicing and upgrades.
-
Investment protection: Belonging to the established IS220 family and Mark VIe architecture, the module ensures compatibility with broad I/O ecosystem, facilitating long-term support and scalability.
-
Versatile signal handling: With both input and output analog channels, the module supports both measurement and actuation tasks in one unit, reducing the number of separate modules needed.
Brand and Series
-
Brand: GE Fanuc
-
Series: Mark VIe Distributed Control System – IS220 I/O Pack Series
-
Product Type: Analog I/O Pack Module
The IS220PAICH1B is part of the IS220 family of plug-in I/O modules designed for use in Mark VIe systems. The “PAICH” designation signals an analog input/output pack variant, and the “1B” revision marks a specific version. The IS220 series includes analogous modules for discrete I/O, communication, servo, protection, and power distribution.
Related Models – Same Series or Compatible
| Model | Function Description | Key Parameters (Size / Weight) |
|---|---|---|
| IS220PAICH2A | Higher-density Analog I/O Pack (input + output) | Approx. 170 mm × 100 mm × 35 mm ; ~0.72 kg |
| IS220PTCCH1A | Thermocouple Input Pack – dedicated temperature inputs | Approx. 82 mm × 122 mm × 60 mm ; ~0.36 kg |
| IS220PSCAH1A | Serial Communication I/O Pack – interfaces RS-232/422/485 devices | Approx. 292 mm × 130 mm × 27 mm ; ~0.36 kg |
| IS220PSVOH1A | Servo Valve Output Pack – provides analog/PWM outputs for servo valves | Approx. 224 mm × 89 mm × 100 mm ; ~0.45 kg |
| IS220PPDAH1A | Power Distribution I/O Pack – manages DC power distribution | Approx. 170 mm × 110 mm × 30 mm ; ~0.65 kg |
Popular Models – Same Brand
| Model | Function Description | Key Parameters (Size / Weight) |
|---|---|---|
| IS220UCSAH1A | Controller Pack – main CPU module for Mark VIe system | Approx. 233 mm × 177 mm × 44.45 mm ; ~2.27 kg |
| IS220PPRFH1A | PROFIBUS Master Gateway Pack – integrates PROFIBUS devices | Approx. 263 mm × 58 mm × 28 mm ; ~0.43 kg |
| IS220PAOCH1B | Analog Output Pack – precision analog output for control loops | Approx. 150 mm × 100 mm × 50 mm ; ~0.36 kg |
| IS220PCLAH1B | Power/Control Distribution Module – internal power & signal distribution | Approx. 227 mm × 175 mm × 88 mm ; ~1.3 kg |
| IS220PAICH1A | Earlier version Analog I/O Pack – input/output analog module | Approx. 173 mm × 109 mm × 30 mm ; ~0.7 kg |
FAQ (10 Questions & Answers)
Q1: What is the primary function of the IS220PAICH1B?
A1: It acts as an analog input/output interface module, converting field analog signals to digital form for the control system and providing analog outputs for control loops.
Q2: How many analog input channels does it support?
A2: It supports up to ten analog input channels; the first eight are configurable for voltage or current loop inputs, the last two can be set for specific current values.
Q3: Does the module provide analog outputs too?
A3: Yes—it provides two current-loop analog output channels (0-20 mA) for actuation or control purposes.
Q4: What are the physical dimensions and approximate weight?
A4: The module’s approximate external size is 13.3 cm × 7.08 cm × 3.93 cm and its weight is about 1.0 kg.
Q5: What power supply does it require?
A5: Typical supply is 24 V DC (or 22.8 V DC for transmitter powering), with design appropriate for Mark VIe I/O racks.
Q6: Can the module operate in hazardous-area environments?
A6: Yes—some versions are certified for Zone 2, Group IIC hazardous locations, and the module supports demanding industrial environmental ratings.
Q7: What sorts of sensors or transducers work with this module?
A7: It supports voltage inputs (e.g., 5 V, 10 V), current loops (0-20 mA), sensors such as temperature, flow, pressure transmitters, level sensors—making it highly flexible.
Q8: Does it support network redundancy?
A8: Yes—dual RJ-45 Ethernet ports allow redundant communication paths and improved system availability.
Q9: How does this module compare to the “2A” or “2B” higher-density versions?
A9: The “1B” version is a standard analog I/O pack with ten inputs and two outputs; higher density versions offer more inputs, higher current loop outputs, or other features, often at slightly larger size or weight.
Q10: What maintenance or service considerations apply?
A10: Being a plug-in module, it supports field replacement; monitoring of LED indicators helps diagnostics. During module swap, follow shutdown or safe-replace procedures to maintain system integrity.
