Epro PR6426/010-140 32 mm Eddy-Current Sensor
Product Overview
The Epro PR6426/010-140 is a high-performance, non-contacting eddy-current displacement sensor featuring a 32 mm diameter probe tip. Engineered for precision position and vibration measurement, this sensor converts gap variations into a proportional AC voltage, supporting advanced machinery monitoring and control applications. Its robust stainless-steel construction, integrated coil assembly, and PTFE-insulated cable ensure long-term stability in harsh industrial environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | PR6426/010-140 |
| Series | PR6426 |
| Probe Tip Diameter | 32 mm |
| Gap Range | 0.5–5 mm |
| Output Signal | 0–10 V AC proportional to gap |
| Linearity | ±1 % full scale |
| Bandwidth | DC–10 kHz |
| Cable Type | PTFE-insulated shielded coaxial |
| Connector | M12 8-pin male |
| Operating Temperature | –40 °C to +125 °C |
| Shock Resistance | 50 g, 11 ms half-sine |
| Weight | 0.20 kg |
| Housing Material | 316 stainless steel |
| EMI/RFI Immunity | Integrated braided shield |
Applications
-
Rotating Machinery Monitoring: Real-time shaft position and vibration sensing in turbines, compressors, and pumps.
-
Gearbox & Bearing Analysis: Detect gear mesh frequencies and early bearing faults.
-
Thickness & Eccentricity Measurement: Monitor rotor concentricity in turbo-machinery and generators.
-
Research & Development: Precision gap measurement in test rigs and material testing equipment.
-
Process Control & Automation: Position feedback for servo valves and linear actuators.
Advantages
-
Large 32 mm Sensing Tip
Provides increased sensitivity and stable readings over wider gaps and larger target surfaces. -
High Bandwidth
Supports frequency response up to 10 kHz for capturing high-frequency vibration components. -
Rugged Construction
316 stainless-steel housing and shock rating up to 50 g ensure reliability in extreme conditions. -
Compact & Lightweight
At only 0.20 kg and a compact form factor, the sensor installs easily on confined machinery. -
EMI-Hardened Design
Braided cable shield and integrated filtering protect against electrical noise.
Brand
Epro is a leading manufacturer of precision eddy-current sensors and condition monitoring solutions. Renowned for robust industrial design and highly linear performance, Epro sensors are trusted across power generation, metallurgy, and research laboratories.
Related Models in the PR6426 Series
| Model | Part Number | Probe Dia. | Gap Range | Bandwidth | Weight (kg) |
|---|---|---|---|---|---|
| PR6426/010-100 | PR6426/010-100 | 32 mm | 0.5–5 mm | DC–10 kHz | 0.18 |
| PR6426/010-120 | PR6426/010-120 | 32 mm | 1–6 mm | DC–8 kHz | 0.19 |
| PR6426/020-140 | PR6426/020-140 | 20 mm | 0.5–4 mm | DC–12 kHz | 0.17 |
| PR6426/015-140 | PR6426/015-140 | 15 mm | 0.3–3 mm | DC–15 kHz | 0.16 |
| PR6426/010-160 | PR6426/010-160 | 32 mm | 0.5–5 mm | DC–6 kHz | 0.18 |
Popular Epro Sensor Models
| Model | Part Number | Description | Key Spec |
|---|---|---|---|
| PR6430/005-050 | PR6430/005-050 | 5 mm probe, DC–20 kHz bandwidth | Probe Dia. 5 mm |
| PR6423/010-100 | PR6423/010-100 | 10 mm probe for high-temp applications | Temp to +200 °C |
| PR6440/020-100 | PR6440/020-100 | 20 mm probe, long-term stability | Linearity ±0.5 % |
| PR6428/010-120 | PR6428/010-120 | 10 mm probe, integrated temperature sensor | Weight 0.22 kg |
| PR6415/015-050 | PR6415/015-050 | 15 mm probe, 0.5–5 mm gap | Shock 100 g |
Frequently Asked Questions (FAQ)
Q1: What principle does the PR6426/010-140 use?
A1: It employs eddy-current induction to translate gap distance into a proportional AC voltage.
Q2: How do I terminate the sensor cable?
A2: The sensor uses a standard M12 8-pin male connector compatible with most condition monitors.
Q3: What is the optimal gap for this sensor?
A3: A gap between 0.5 mm and 2.5 mm yields the best linearity and sensitivity.
Q4: Can the sensor withstand high electromagnetic interference?
A4: Yes, its braided shield and integrated filtering provide robust EMI/RFI immunity.
Q5: What environments can it operate in?
A5: Rated for –40 °C to +125 °C and shock up to 50 g, it suits harsh industrial settings.
Q6: Does it require calibration?
A6: The sensor is factory-calibrated; periodic verification intervals depend on application and usage.
Q7: How does the probe’s 32 mm diameter benefit measurement?
A7: Larger tip diameter increases signal strength and stability over irregular or coarse targets.
Q8: What is the output signal type?
A8: It delivers a 0–10 V AC signal proportional to the measured gap.
Q9: Can I use this sensor for vibration analysis?
A9: Yes, with its 10 kHz bandwidth it captures both low- and high-frequency vibration components.
Q10: Where can I find detailed documentation?
A10: Full datasheets, installation guides, and application notes are available from Epro’s official support portal.
