Overview
The Epro PR6423/014-010+CON021 is an 8 mm Eddy Current Sensor System designed for non-contact measurement of shaft vibration, displacement, position, and speed in rotating machinery monitoring applications.
The system combines an 8 mm eddy current probe with the CON021 signal converter to provide accurate and stable measurement signals for machinery protection systems. It is mainly used for detecting dynamic shaft movement and mechanical condition changes without direct contact with rotating components.
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Epro |
| Model | PR6423/014-010+CON021 |
| Product Type | 8 mm Eddy Current Sensor System |
| Sensor Type | Non-contact Eddy Current Displacement Sensor |
| Sensor Head Diameter | 8 mm |
| Weight | 0.22 kg |
| Measurement Principle | Eddy Current Technology |
| Main Function | Shaft Vibration, Displacement, Position and Speed Measurement |
| Application | Rotating Machinery Condition Monitoring |
| System Components | PR6423 Sensor Probe + CON021 Signal Converter |
Applications
Turbine Monitoring
The Epro PR6423/014-010+CON021 is used for monitoring shaft vibration and displacement in steam turbines, gas turbines, and hydro turbines to improve equipment reliability.
Compressor Condition Monitoring
The sensor provides accurate shaft movement measurement for compressors, helping identify abnormal operating conditions and mechanical changes.
Generator Protection
It supports generator monitoring by detecting shaft position variations and vibration behavior during operation.
Pump and Fan Monitoring
The system is suitable for industrial pumps, fans, and rotating equipment where stable shaft condition measurement is required.
Gearbox Monitoring
It helps monitor rotating components inside gearboxes by providing accurate displacement and vibration signals.
How It Works
The Epro PR6423/014-010+CON021 works based on eddy current sensing technology.
The sensor probe generates an electromagnetic field near the rotating shaft. When the distance between the probe and the conductive shaft surface changes, the electrical characteristics of the sensor output change accordingly.
The CON021 converter processes the probe signal and converts it into a suitable measurement output for machinery monitoring and protection systems.
The typical signal process is:
Rotating Shaft → PR6423 Eddy Current Probe → CON021 Converter → Monitoring System
Because the sensor operates without physical contact with the shaft, it provides stable measurement performance while avoiding mechanical wear during high-speed operation.
Key Benefits
| Feature | Benefit |
|---|---|
| Non-contact Measurement | Prevents mechanical wear and improves long-term reliability. |
| Accurate Shaft Detection | Provides precise vibration and displacement monitoring. |
| High Dynamic Response | Suitable for high-speed rotating machinery applications. |
| Continuous Monitoring | Supports predictive maintenance and equipment protection. |
| Compact 8 mm Probe Design | Allows installation in limited equipment spaces. |
| Reliable Industrial Performance | Designed for demanding machinery monitoring environments. |
Related Components
| Component | Function |
|---|---|
| PR6423/014-010 Sensor Probe | Detects shaft displacement and vibration changes. |
| CON021 Signal Converter | Processes probe signals and provides monitoring outputs. |
| Extension Cable | Connects the sensor probe with the converter. |
| Machinery Monitoring System | Receives and analyzes measurement signals. |
| Protection Module | Provides alarm and shutdown functions. |
| Rotating Equipment | Provides the monitored mechanical target. |
Installation
The Epro PR6423/014-010+CON021 should be installed according to the requirements of the machinery protection and monitoring system.
Before installation, check:
- Correct sensor model
- Probe mounting position
- Shaft surface condition
- Sensor installation gap
- Cable connection
- Converter compatibility
The probe must maintain the correct installation distance from the rotating shaft surface to ensure accurate measurement. Incorrect sensor positioning may result in unstable output signals or inaccurate vibration readings.
After installation, calibration and functional testing should be performed to confirm correct signal transmission and reliable monitoring operation.
Troubleshooting
| Problem | Possible Cause | Recommended Check |
|---|---|---|
| No Signal Output | Sensor or cable connection failure | Check probe wiring and CON021 connections. |
| Incorrect Measurement Data | Improper sensor gap adjustment | Verify probe installation distance. |
| Signal Instability | Cable interference or loose connection | Inspect cable routing and connection condition. |
| False Alarm from Monitoring System | Machine vibration issue or sensor fault | Check equipment condition and sensor output. |
| Measurement Deviation | Converter or sensor performance problem | Verify converter operation and system calibration. |
Recommended Models
| Model | Product Type | Application |
|---|---|---|
| PR6423/014-010+CON021 | 8 mm Eddy Current Sensor System | Shaft vibration and displacement monitoring |
| PR6423/010-010-CN+CON021 | 8 mm Eddy Current Sensor System | Rotating machinery protection |
| PR6423/004-010+CON021 | 8 mm Eddy Current Sensor System | Industrial condition monitoring |
| PR6423/002-100-CN+CON021 | 8 mm Eddy Current Sensor System | Turbomachinery monitoring |
| CON021 | Signal Converter | Eddy current signal processing |
| MMS Series | Machinery Monitoring System | Machine protection applications |
Related Products
| Product / Series | Product Type | Main Use |
|---|---|---|
| Epro PR6423 Series | Eddy Current Sensor | Shaft displacement measurement |
| Epro CON021 Series | Signal Converter | Sensor signal conversion |
| Epro MMS Series | Machinery Monitoring System | Rotating equipment protection |
| Eddy Current Probe Series | Non-contact Sensor | Vibration and position monitoring |
| Vibration Monitoring Modules | Protection Equipment | Fault detection |
| Turbomachinery Monitoring Systems | Monitoring Platform | Critical equipment protection |
Technical FAQs
1. What is the main function of the Epro PR6423/014-010+CON021?
It is used to measure shaft vibration, displacement, position, and speed of rotating machinery through non-contact eddy current sensing technology.
2. What is the purpose of the CON021 converter?
The CON021 converts the probe output signal into a processed signal that can be used by machinery monitoring and protection systems.
3. Why are eddy current sensors suitable for rotating machinery?
They provide non-contact measurement, allowing reliable operation on high-speed rotating shafts without mechanical wear.
4. What equipment can use the PR6423/014-010+CON021?
It is commonly used in turbines, compressors, generators, pumps, fans, and other critical rotating equipment.
5. What should be checked if the sensor output is abnormal?
Check the probe installation gap, cable connection, converter operation, sensor position, and monitoring system configuration.
