Product Overview: Emerson VE4036P2
Product Parameters
| Parameter | Specification |
|---|---|
| Model | VE4036P2 |
| Type / Function | Redundant Serial Interface Card (M‑series, DeltaV) |
| Number of Serial Ports | 2 ports per card (redundant pair) |
| Total Supported Data Sets | 32 (i.e. 16 per port) |
| Port Types | RS‑232, RS‑422/485 (half-duplex or full-duplex) |
| Baud Rate Range | 300 to 115,200 bps |
| Parity / Data Bits / Stop Bits | Even / Odd / None; 7 or 8 data bits; 1 or 2 stop bits |
| Isolation | Each port isolated from system and from each other |
| Local Bus Power Supply | 12 V DC at ~160 mA |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 %, non‑condensing |
| Shock / Vibration | 10 g, ½‑sine 11 ms; vibration: 3 mm peak‑to‑peak (5–13 Hz) and 0.5 g (13–150 Hz) |
| Protection / Ingress Rating | IP20 |
| Airborne Contaminants Standard | ISA‑S71.04 Class G3 |
| Dimensions (HxWxD) | ~ 107 mm × 41 mm × 105 mm (as per one supplier) |
| Weight | ~ 0.45 kg (450 g) (per card) |
| Redundancy Capability | 1:1 redundancy (active / standby card) |
Product Introduction
The VE4036P2 is a redundant serial interface card in the M‑series (Series 2) family, designed to bridge serial communication devices (e.g. Modbus, legacy serial equipment) with the DeltaV control system architecture. It contains a pair of serial cards plus a redundant terminal block, enabling continuous operation even if one path fails.
This module is tailored for industrial automation environments requiring high availability and guaranteed data links. Each card offers two serial ports supporting RS‑232 and RS‑422/485 protocols, and the system can automatically switchover in fault scenarios without interrupting the control operations. It’s plug‑and‑play in DeltaV systems: once configured via the control software, it integrates seamlessly into I/O carriers and works in conjunction with other modules.
Because it supports serial devices already in use in plants, it allows the existing instrumentation and controllers to be retained, bridging “brownfield” installations into modern automation systems without wholesale replacement.
Product Applications
-
Connecting Modbus RTU / ASCII devices (pressure transmitters, analyzers, PLCs) into DeltaV systems.
-
Interfacing with legacy serial equipment (e.g. older instrumentation, controllers) in modernization projects.
-
Redundant communication setups in safety‑critical applications (e.g. petrochemical, power plants).
-
Serial data acquisition and command/control in remote field devices.
-
Process control systems where continuous serial link uptime is required.
Product Advantages
-
Redundancy for Reliability
With 1:1 redundant cards, the module ensures continuous serial connectivity even if one card or port fails. -
Protocol Flexibility
Supports RS‑232 and RS‑422/485 (half or full duplex), enabling integration with a wide variety of field devices. -
Isolated Ports
Each serial port is electrically isolated from the system and from other ports, improving noise immunity and safety. -
Plug & Play Integration
DeltaV auto‑detects redundant I/O and treats the redundant pair as a single logical interface, simplifying configuration. -
Automatic Switchover
Upon detection of failure in the active card, it switches seamlessly to the standby card without requiring user intervention. -
Compact Design but Robust Specs
Despite its modest dimensions, it supports wide temperature ranges and shock/vibration resilience suited for industrial use. -
Preserves Existing Infrastructure
Allows reuse of serial devices already installed in plants, lowering upgrade costs and preserving investment. -
Diagnostics & Status Feedback
Offers realtime status indicators and diagnostic capabilities to detect communication faults, switchover events, or port issues.
Brand and Series Information
-
Brand: Emerson
-
Series / Product Family: M‑series Serial Interface, part of the DeltaV (Series 2 / S2) I/O architecture
The M‑series I/O cards provide fieldbus and serial interface capabilities to the DeltaV control environment, enabling modular extensions and high availability designs.
Related or Same‑Series Models (Comparison)
Below are five related interface / I/O cards in the same M‑series / DeltaV interface family that are often considered alternatives or complementary:
| Model | Type / Function | Serial / I/O Spec | Dimensions / Mounting | Weight | Key Feature / Use Case |
|---|---|---|---|---|---|
| VE4006P2 | M‑series Serial Interface (simplex) | 2 serial ports, no redundancy | ~107 × 41 × 105 mm | ~0.45 kg | Non‑redundant version, lower cost alternative |
| VE4014P2 | Redundant Profibus DP Interface | 2 Profibus DP ports, redundant | same card format | ~0.45 kg | For Profibus DP networks with redundancy needs |
| VE4007P2 | Profibus DP Interface (simplex) | 1 Profibus DP port | card module format | ~0.45 kg | Single port Profibus interface |
| VE4008P2 | Foundation Fieldbus Interface | 2 FF H1 ports | card format | ~0.45 kg | For fieldbus (FF) networks |
| VE4012P2 | DeviceNet Interface Card | 1 DeviceNet port, optionally redundant | card mounting format | ~0.45 kg | Serial / fieldbus interface for DeviceNet systems |
Popular Models from Emerson (Same Brand)
Here are five frequently used Emerson / DeltaV / M‑series or related devices that are well known in the same ecosystem:
| Model | Role / Function | Key Parameters / Use Case | Dimensions / Weight | Notable Feature |
|---|---|---|---|---|
| VE4031S2T2B6 | Digital Input Module (32 channels) | 32 input channels, isolation | ~0.5 kg (card) | Companion I/O module frequently paired with interface cards |
| VE4003S2B2 | Digital Output Module (32 channels) | 32 outputs, isolation, high density | ~0.7 kg (card) | High-density output within I/O racks |
| VE4022 | Profibus DP Interface Card | Serial / fieldbus interface for DP systems | ~0.43 kg (card) | Another fieldbus interface within the same product family |
| VE4050E1C0 | Variable Frequency Drive (VFD, 40 kW) | Motor drive, vector control | ~22 kg (cabinet) | Power device in the Emerson drive line |
| VE6020E2D0 | High-power Drive / VFD module | Larger kW class for industrial motors | ~30 kg | For heavier motor loads requiring higher capacity drives |
Frequently Asked Questions (10 QA) about VE4036P2
Q1: What serial protocols does VE4036P2 support?
A1: It supports RS‑232 and RS‑422/485 (half-duplex or full-duplex) for its serial ports, thus interoperating with many industrial devices.
Q2: How many serial ports are available?
A2: Each card has 2 serial ports, and as a redundant pair, the whole VE4036P2 provides two active ports (with standby) for high availability.
Q3: Does VE4036P2 support automatic switchover on failure?
A3: Yes. When the active card fails, the system automatically switches to the standby card without manual intervention, maintaining connectivity.
Q4: Are the serial ports electrically isolated?
A4: Yes — each port is individually isolated from the system bus and from other ports, protecting against noise or faults.
Q5: What is the supported baud rate range?
A5: It supports standard industrial baud rates from 300 up to 115,200 bps.
Q6: What is the operating temperature range?
A6: It operates reliably between –40 °C and +70 °C, suitable for harsh industrial environments.
Q7: What is the weight and size of this module?
A7: The module is approximately 0.45 kg and its dimensions are about 107 mm × 41 mm × 105 mm.
Q8: Can VE4036P2 be added while the system is running?
A8: Yes, similar to other DeltaV I/O, the VE4036P2 can be added online while the system is powered and in use.
Q9: What kind of devices can be connected through VE4036P2?
A9: It can interface with Modbus devices, legacy serial analyzers, serial PLCs, instrumentation with RS‑232 or RS‑422/485 ports.
Q10: What happens if communication fails on the primary card?
A10: The module detects faults and switches to the backup (standby) card, maintaining continuous operation and alerting operators to a switchover event.
