Product Overview
The Emerson SE4000L6P20 20-Pin Round Ribbon Cable Set is a multi-conductor cable assembly used for connecting compatible Emerson industrial automation hardware. It is intended for applications where control, signal, or interface connections need to be transferred between system components through a pre-assembled cable set.
With a 6-meter cable length, the SE4000L6P20 is suitable for installations where connected components are positioned some distance apart within an automation cabinet or between associated control-system assemblies. The pre-assembled configuration also simplifies installation compared with individually wiring each connection.
When replacing this cable set, the complete part number and connector/interface configuration should be matched rather than selecting a cable based only on length.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Emerson |
| Model | SE4000L6P20 |
| Product Type | 20-Pin Round Ribbon Cable Set |
| Number of Pins | 20-Pin |
| Cable Type | Round Ribbon Cable |
| Cable Length | 6 meters |
| Shipping Weight | 3 kg |
| Application | Industrial Automation / Control System |
| System Role | Signal and Hardware Interconnection |
Product Features
- Emerson 20-pin cable assembly
- 20-pin connection configuration
- Round ribbon cable construction
- 6-meter cable length
- Pre-assembled cable set for system interconnection
- Suitable for industrial automation equipment
- Useful for connecting compatible control-system hardware
- Simplifies installation compared with individual point-to-point wiring
- Shipping weight: 3 kg
Working Principle
The SE4000L6P20 functions as a physical electrical connection between compatible Emerson system components.
A typical arrangement can be represented as:
Control / Interface Hardware → SE4000L6P20 Cable Set → Compatible System Hardware
The multiple conductors within the cable assembly carry the corresponding electrical signals between the connected interfaces. Because the cable is supplied as a defined 20-pin assembly, the individual connections are organized within the cable rather than requiring separate field wiring for every signal.
The 6-meter length gives installation personnel additional flexibility when the connected components are not positioned directly next to each other.
Industrial Applications
| Application | Typical Use |
|---|---|
| Process Automation | Interconnection of compatible control hardware |
| Industrial Control Cabinets | Connecting separated system components |
| Manufacturing Automation | Signal and interface connections |
| Process Control | Hardware-to-hardware signal transmission |
| System Expansion | Connecting additional compatible components |
| Maintenance and Replacement | Replacing existing cable assemblies |
Compatible System Components
| Component | Function |
|---|---|
| Emerson SE4000L6P20 | 20-pin signal/interface connection |
| Compatible Controller | Performs control and processing functions |
| I/O Hardware | Interfaces with field signals |
| Controller Carrier | Provides mounting and system connections |
| Interface Module | Transfers signals between system components |
| Control Network Hardware | Supports system communication |
Exact compatibility should be confirmed from the complete Emerson system configuration and connector arrangement before installation.
Installation and Maintenance
The SE4000L6P20 should be routed carefully to avoid excessive bending, pulling, or mechanical stress on the cable and connectors.
Recommended checks include:
- Confirm the complete SE4000L6P20 part number.
- Verify the 20-pin connector configuration.
- Confirm the required 6-meter cable length.
- Check connector orientation before installation.
- Inspect connectors for bent, damaged, or contaminated contacts.
- Route the cable away from sources of excessive heat or mechanical interference.
- Avoid sharp bends and excessive tension.
- Ensure connectors are fully seated.
- Check cable continuity if communication or signal problems occur.
- Inspect the cable for cuts, abrasion, or damaged insulation during maintenance.
Because this is a multi-pin cable assembly, incorrect connector or pin configuration can cause system faults even when the cable length is correct.
Recommended Related Models
| Model / Component | Type | Primary Function | Application |
|---|---|---|---|
| Emerson SE4000L6P20 | 20-Pin Round Ribbon Cable Set | System interconnection | Industrial automation |
| Emerson SE3051C0 | 2-Wide Power/Controller Carrier | Controller and power hardware carrier | Control-system infrastructure |
| Emerson SE3009 | Controller | Control and processing | Process automation |
| Emerson KJ3223X1-BA1 | DeltaV Analog Input Card | Analog signal acquisition | Process control |
| Emerson KL3031X1-BA1 | RTD / Resistance CHARM | Temperature and resistance input | Process instrumentation |
| Emerson KL4001X1-BA1 | Controller Carrier | Controller system integration | Industrial automation |
When selecting a replacement cable, connector configuration and pin arrangement should be confirmed in addition to cable length.
Key Advantages
- 20-pin round ribbon cable assembly
- 6-meter cable length
- Pre-assembled connection solution
- Suitable for compatible Emerson automation hardware
- Simplifies multi-conductor system interconnection
- Useful for cabinet and distributed hardware installations
- Shipping weight of 3 kg
Technical FAQs
What is the Emerson SE4000L6P20 used for?
The SE4000L6P20 is a 20-pin cable set used to interconnect compatible Emerson industrial automation hardware and transfer the required electrical signals between system interfaces.
How long is the SE4000L6P20 cable?
The stated cable length is 6 meters, providing additional installation distance between compatible system components.
Why is the 20-pin configuration important?
The 20-pin configuration determines how the cable interfaces with the connected hardware. A cable with the correct length but an incompatible pin or connector arrangement may not be suitable as a replacement.
What should be checked when replacing an SE4000L6P20?
Verify the complete part number, 20-pin configuration, connector arrangement, cable length, and the interfaces of both connected components. The cable should also be inspected for physical damage before installation.
