Emerson KL3102X1-BA1 Analog Output HART PLC Processor Module
Product Overview
The Emerson KL3102X1-BA1 is a highly reliable analog output (AO) module featuring HART communication protocol capabilities, designed for integration within Emerson’s DeltaV distributed control system (DCS). This PLC processor module supports precise analog signal output, enhancing communication between field devices and the control system through digital HART protocol overlay. Its compact design and advanced diagnostic features enable efficient control and monitoring in complex industrial processes, ensuring high performance and system robustness.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | KL3102X1-BA1 |
| Module Type | Analog Output HART PLC Processor |
| Channels | 2 Analog Outputs |
| Communication Protocol | HART (Highway Addressable Remote Transducer) |
| Compatible System | Emerson DeltaV DCS |
| Signal Output Range | 4–20 mA standard |
| Dimensions (L x W x H) | 94 x 12.5 x 60 mm |
| Weight | 0.048 kg |
| Power Supply | 24 V DC nominal |
| Operating Temperature | 0 to 60 °C |
| Mounting | DIN rail or rack mounting |
| Diagnostic Features | Built-in HART diagnostics and alerts |
Applications
-
Process Control Systems: Provides accurate analog output signals with HART communication for enhanced control of valves, transmitters, and other process equipment.
-
Field Device Communication: Supports HART-enabled devices allowing two-way communication for device configuration, diagnostics, and monitoring.
-
Automation Systems: Essential for seamless integration into Emerson DeltaV DCS environments to optimize process automation.
-
Refineries and Chemical Plants: Ideal for critical environments requiring precise analog outputs combined with diagnostic capabilities.
-
Industrial Monitoring: Suitable for real-time monitoring and adjustment of process variables, ensuring safety and efficiency.
Advantages
-
HART Protocol Support
Enables advanced diagnostics and two-way digital communication on top of standard analog signals, improving device management and system reliability. -
Compact and Lightweight Design
At just 94 x 12.5 x 60 mm and 0.048 kg, the module saves valuable space in control cabinets and panels. -
Seamless DeltaV Integration
Designed for easy integration with Emerson DeltaV DCS, ensuring fast setup and compatibility. -
Accurate Analog Output
Provides stable 4–20 mA output with minimal drift, essential for precise process control. -
Built-in Diagnostics
Proactively detects faults and provides alerts to maintain system health and reduce downtime.
Brand
Emerson is a global leader in automation and control technologies, offering innovative and reliable solutions through its DeltaV series for efficient and scalable industrial process control.
Series
This module is part of the DeltaV series, Emerson’s flagship control system family, known for modular, scalable, and robust automation solutions.
Recommended Models in the DeltaV Series
| Model | Description | Channels | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| KL3102X1-BB1 | Analog Output PLC Processor, 2 channels | 2 AO | 94 x 12.5 x 60 | 0.05 |
| KL3302X1-BA1 | Analog Input HART Processor, 2 channels | 2 AI | 94 x 12.5 x 60 | 0.047 |
| KL3108X1-BA1 | Analog Output PLC Processor, 8 channels | 8 AO | 160 x 30 x 60 | 0.12 |
| KL3404X1-AA1 | Digital Input Processor, 16 channels | 16 DI | 140 x 45 x 60 | 0.09 |
| KL3204X1-AA1 | Digital Output Processor, 16 channels | 16 DO | 140 x 45 x 60 | 0.1 |
Popular Emerson DeltaV Models
| Model | Description | Channels | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| KL3104X1-BA1 | Analog Output PLC Processor, 4 channels | 4 AO | 120 x 15 x 60 | 0.07 |
| KL3308X1-BA1 | Analog Input HART Processor, 8 channels | 8 AI | 160 x 30 x 60 | 0.11 |
| KL3102X1-BC1 | Analog Output PLC Processor with isolation | 2 AO | 94 x 12.5 x 60 | 0.05 |
| KL3600X1-AA1 | Foundation Fieldbus Processor | Multiple | 140 x 45 x 60 | 0.13 |
| KL4000X1-AA1 | Wireless I/O Processor Module | Multiple | 150 x 60 x 80 | 0.18 |
Frequently Asked Questions (FAQ)
Q1: What type of signals does the KL3102X1-BA1 module output?
A1: It outputs standard 4–20 mA analog signals with HART protocol communication.
Q2: Can the module communicate digitally with HART devices?
A2: Yes, it supports two-way digital communication via the HART protocol overlay.
Q3: What are the physical dimensions of this module?
A3: The module measures 94 x 12.5 x 60 mm.
Q4: How much does the KL3102X1-BA1 weigh?
A4: It weighs approximately 0.048 kg.
Q5: Is the module compatible with all Emerson DeltaV controllers?
A5: Yes, it is designed for seamless integration with DeltaV systems.
Q6: What type of mounting options are available?
A6: The module supports DIN rail and rack mounting.
Q7: Does the module have any built-in diagnostics?
A7: Yes, it includes built-in HART diagnostics and fault alert features.
Q8: What is the operating temperature range?
A8: The module operates reliably from 0 to 60 °C.
Q9: How many channels does this module support?
A9: It supports 2 analog output channels.
Q10: Can the module support high-density control racks?
A10: Yes, its compact design is ideal for high-density control rack applications.
