Product Overview
The Bently Nevada TK-3E 177313-01-02 Proximity System Test Kit is a service and diagnostic kit used for testing compatible proximity measurement systems associated with rotating machinery.
In practical machinery maintenance, a proximity channel can show an unexpected reading for several different reasons. The probe itself may be affected, but the extension cable, connections, interface electronics, monitoring hardware, or the machine condition can also contribute to the observed signal. A dedicated test kit gives technicians a controlled way to examine the measurement system before replacing individual components.
The TK-3E 177313-01-02 is therefore suited to commissioning, preventive maintenance, troubleshooting, and post-repair verification. It is used as service equipment rather than as a permanent part of the machine’s normal monitoring signal path.
For field technicians, this type of test equipment is especially useful when a proximity probe or monitoring channel has been serviced and the complete signal chain needs to be checked before the equipment is returned to operation.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Model | TK-3E 177313-01-02 |
| Product Type | Proximity System Test Kit |
| Series / Family | TK-3E |
| Main Function | Proximity System Testing and Verification |
| System Role | Test and Calibration Equipment |
| Application | Machinery Condition Monitoring |
| Typical Use | Proximity Probe and Measurement-System Testing |
| Dimensions | 195 × 299 × 248 mm |
| Weight | 5.22 kg |
Product Features
The TK-3E 177313-01-02 is intended for hands-on testing and troubleshooting of compatible proximity measurement equipment.
Key characteristics include:
- Bently Nevada TK-3E proximity system test kit
- Suitable for proximity-system testing
- Useful during equipment commissioning
- Applicable to maintenance and troubleshooting
- Supports controlled evaluation of measurement channels
- Useful for checking the proximity signal path
- Suitable for field-service and workshop environments
- Applicable to rotating-machinery condition monitoring
- Dimensions of 195 × 299 × 248 mm
- Stated weight of 5.22 kg
The exact test configuration should be established according to the equipment being tested and the applicable service procedure.
Working Principle
The TK-3E is introduced into a proximity-system test arrangement when technicians need to evaluate the behavior of the connected measurement equipment.
A simplified signal relationship is:
Test Equipment → Proximity Measurement System → Monitoring Equipment
During normal operation, a proximity probe detects shaft movement and sends a signal through the associated measurement chain. During maintenance, the test kit can be used to establish a controlled test condition and observe how the connected system responds.
This is useful when the monitoring system reports an unexpected shaft-position or vibration-related indication. Instead of immediately replacing the probe, a technician can work through the measurement path and determine whether the observed behavior is related to the sensor, cabling, interface equipment, monitoring hardware, or the actual machine.
The test kit therefore forms part of a diagnostic process rather than the normal operating circuit.
Industrial Applications
The TK-3E 177313-01-02 can be used in maintenance and service environments involving rotating machinery and proximity-based monitoring.
| Application | Typical Use |
|---|---|
| Turbomachinery Maintenance | Proximity-system verification |
| Compressor Systems | Measurement-channel testing |
| Pump Systems | Shaft-monitoring diagnostics |
| Power Generation | Machinery protection maintenance |
| Industrial Rotating Equipment | Condition-monitoring troubleshooting |
| Machinery Commissioning | Proximity-system checks |
| Maintenance Workshops | Equipment verification |
| Field Service | On-site diagnostic testing |
The suitability of the test kit depends on the specific proximity system and monitoring equipment involved.
Compatible System Components
The TK-3E is generally used alongside the components that form the proximity measurement chain.
| Component | Function |
|---|---|
| TK-3E 177313-01-02 | Provides proximity-system testing capability |
| Proximity Probe | Detects shaft movement or displacement |
| Probe Extension Cable | Carries the probe signal |
| Proximity Interface Electronics | Processes the sensor signal |
| Monitoring Module | Receives and evaluates measurement information |
| Machinery Protection System | Monitors machine condition |
| Monitoring Rack | Houses monitoring electronics |
| Test Cables / Accessories | Connect the test equipment to the system under evaluation |
When diagnosing a problem, technicians should examine the entire signal path. A poor connection or damaged cable can create measurement symptoms that initially appear to be caused by the probe.
Installation and Maintenance
The TK-3E 177313-01-02 is portable service equipment. It should be handled as test equipment and used according to the applicable testing procedure.
Before use, inspect the test kit, cables, connectors, and accessories. The equipment under test should be positively identified before making connections.
Recommended checks include:
- Confirm the complete TK-3E 177313-01-02 part number.
- Verify compatibility with the proximity system.
- Inspect cables and connectors for damage.
- Check the test-kit enclosure and connection points.
- Confirm the intended test arrangement.
- Follow the applicable testing procedure.
- Ensure connections are properly secured.
- Avoid unsuitable test conditions.
- Record test results when required.
- Protect the kit during transportation.
- Store the equipment appropriately after use.
- Inspect accessories before the next test.
If the proximity system passes the required test but the machine continues to show abnormal behavior, the actual mechanical condition of the equipment should also be investigated.
Recommended Related Models
The most appropriate related equipment depends on the proximity system being serviced and the specific diagnostic task.
| Model / Component | Type | Primary Function | Application |
|---|---|---|---|
| Bently Nevada TK-3E 177313-01-02 | Proximity System Test Kit | System testing and verification | Machinery maintenance |
| Bently Nevada TK-3E 177313-01-01 | Proximity System Test Kit | Proximity-system testing | Rotating machinery |
| Bently Nevada TK-3E 177313-01-01-00 | Proximity System Test Kit | System testing and verification | Field service |
| Bently Nevada TK3-2E 177313-02-02 | Proximity System Test Kit | Measurement-system testing | Machinery monitoring |
| Bently Nevada 7200 Series Proximity Probes | Proximity Probe | Shaft displacement measurement | Rotating equipment |
| Bently Nevada Proximity Extension Cables | Sensor Cable | Probe signal transmission | Proximity systems |
When selecting replacement or associated equipment, the complete part number and system configuration should be checked. Similar-looking test equipment should not be treated as interchangeable without confirming the required application.
Key Advantages
- Dedicated proximity-system test equipment
- Suitable for maintenance and commissioning
- Useful for measurement-channel troubleshooting
- Supports controlled diagnostic testing
- Helps evaluate the proximity signal path
- Suitable for field and workshop applications
- Applicable to rotating-machinery service work
- Dimensions of 195 × 299 × 248 mm
- Stated weight of 5.22 kg
Technical FAQs
What is the TK-3E 177313-01-02 primarily used to test?
It is used for testing and verification work involving compatible proximity measurement systems. The kit is particularly relevant when technicians need to evaluate the sensor signal path during maintenance or troubleshooting.
Why should the complete proximity signal chain be checked during troubleshooting?
An abnormal measurement is not necessarily caused by the probe. Extension cables, connectors, interface electronics, monitoring modules, and machine conditions can all affect the final indication. Checking the complete chain helps narrow down the actual cause.
Is the TK-3E 177313-01-02 a permanent monitoring component?
No. It is service and test equipment intended to be introduced into the system when testing or diagnostic work is required. It should not be treated as a normal permanently installed monitoring module.
What should be verified before using the TK-3E on a machinery-monitoring channel?
The complete part number, equipment under test, connection arrangement, associated accessories, and applicable testing procedure should be verified. The test kit and its cables should also be inspected before use.
