Product Overview
The Bently Nevada TK-3E 177313-01-02-00 Proximity System Test Kit is a service and diagnostic kit used to test compatible proximity measurement systems associated with rotating machinery.
In a typical machinery-monitoring installation, proximity probes are used to detect shaft movement and displacement. The resulting signal travels through the probe cable and associated interface electronics before reaching the monitoring system. When a channel produces an unexpected indication, the technician needs to determine whether the problem is related to the probe, cabling, electronics, or the machine itself. A dedicated proximity system test kit is useful for this type of investigation.
The TK-3E 177313-01-02-00 is primarily suited to commissioning, maintenance, troubleshooting, and post-repair verification. Unlike a permanently installed monitoring module, it is brought into the test setup when the proximity measurement chain needs to be evaluated.
It can be particularly useful after replacing a proximity probe, extension cable, or related monitoring component, allowing the technician to check the measurement system before returning the equipment to normal service.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Model | TK-3E 177313-01-02-00 |
| Product Type | Proximity System Test Kit |
| Series / Family | TK-3E |
| Main Function | Proximity System Testing and Verification |
| System Role | Test and Calibration Equipment |
| Application | Machinery Condition Monitoring |
| Typical Use | Proximity Probe and Measurement-System Testing |
| Dimensions | 195 × 299 × 248 mm |
| Weight | 5.22 kg |
Product Features
The TK-3E 177313-01-02-00 is intended for practical testing and troubleshooting of compatible proximity measurement systems.
Key characteristics include:
- Bently Nevada TK-3E proximity system test kit
- Suitable for proximity-system verification
- Useful during commissioning and maintenance
- Applicable to measurement-channel troubleshooting
- Supports controlled evaluation of the proximity signal path
- Suitable for field-service and workshop applications
- Useful when verifying equipment after component replacement
- Applicable to rotating-machinery condition monitoring
- Dimensions of 195 × 299 × 248 mm
- Stated weight of 5.22 kg
The exact test arrangement should be determined according to the equipment under evaluation and the applicable service procedure.
Working Principle
The TK-3E is used as temporary test equipment within a proximity measurement setup.
A simplified arrangement is:
Test Kit → Proximity Measurement System → Monitoring Equipment
During normal operation, the proximity probe detects shaft movement and sends its signal through the associated measurement chain. During maintenance, the test kit can be incorporated into the setup to establish a controlled test condition and observe the response of the connected equipment.
This approach is useful when a monitoring channel produces an unexpected indication. Instead of immediately replacing the probe, a technician can evaluate the signal path and determine whether the behavior is associated with the sensor, extension cable, interface electronics, monitoring module, or the actual machine condition.
The test kit therefore serves as a diagnostic aid within the maintenance process rather than as a normal operating component.
Industrial Applications
The TK-3E 177313-01-02-00 is relevant to maintenance and service environments where proximity-based monitoring is used on rotating machinery.
| Application | Typical Use |
|---|---|
| Turbomachinery Maintenance | Proximity-system verification |
| Compressor Systems | Measurement-channel testing |
| Pump Systems | Shaft-monitoring diagnostics |
| Power Generation | Machinery protection maintenance |
| Industrial Rotating Equipment | Condition-monitoring troubleshooting |
| Machinery Commissioning | Proximity-system checks |
| Maintenance Workshops | Bench testing and verification |
| Field Service | On-site diagnostic testing |
The actual application depends on the proximity system, monitoring architecture, and test procedure involved.
Compatible System Components
The test kit is normally used with the components that form the proximity measurement chain.
| Component | Function |
|---|---|
| TK-3E 177313-01-02-00 | Provides proximity-system test capability |
| Proximity Probe | Detects shaft displacement or movement |
| Probe Extension Cable | Transfers the probe signal |
| Proximity Interface Electronics | Processes the sensor signal |
| Monitoring Module | Receives and evaluates measurement information |
| Machinery Protection System | Monitors machine condition |
| Monitoring Rack | Houses compatible monitoring electronics |
| Test Cables / Accessories | Connect the test kit to the equipment under evaluation |
When troubleshooting a measurement problem, the complete signal path should be considered. A damaged cable, loose connection, or problem in the interface electronics can produce symptoms that resemble a failed proximity probe.
Installation and Maintenance
The TK-3E 177313-01-02-00 is portable service equipment rather than a permanently installed monitoring module. Proper handling is therefore important during transportation, testing, and storage.
Before use, inspect the test kit, cables, connectors, and accessories. The equipment under test should be identified and the intended connection arrangement established before testing begins.
Recommended checks include:
- Confirm the complete TK-3E 177313-01-02-00 part number.
- Verify compatibility with the proximity system under test.
- Inspect cables and connectors for physical damage.
- Check the test-kit enclosure and connection points.
- Confirm the intended test configuration.
- Follow the applicable testing procedure.
- Ensure all connections are properly secured.
- Avoid unsuitable test conditions.
- Record test results when required.
- Protect the kit during transportation.
- Store the equipment appropriately after use.
- Inspect accessories before subsequent testing.
If the measurement system passes the required test while the machine continues to show an abnormal condition, the actual mechanical condition of the equipment should also be investigated.
Recommended Related Models
Related equipment should be selected according to the proximity measurement system and the specific maintenance task.
| Model / Component | Type | Primary Function | Application |
|---|---|---|---|
| Bently Nevada TK-3E 177313-01-02-00 | Proximity System Test Kit | System testing and verification | Machinery maintenance |
| Bently Nevada TK-3E 177313-01-02 | Proximity System Test Kit | Proximity-system testing | Rotating machinery |
| Bently Nevada TK-3E 177313-01-01-00 | Proximity System Test Kit | System testing and verification | Field service |
| Bently Nevada TK3-2E 177313-02-02 | Proximity System Test Kit | Measurement-system testing | Machinery monitoring |
| Bently Nevada 7200 Series Proximity Probes | Proximity Probe | Shaft displacement measurement | Rotating equipment |
| Bently Nevada Proximity Extension Cables | Sensor Cable | Probe signal transmission | Proximity systems |
For replacement or service applications, the complete part number should be checked carefully. Similar TK-series equipment should not automatically be considered interchangeable without confirming the intended test configuration.
Key Advantages
- Dedicated proximity-system test equipment
- Suitable for maintenance and commissioning
- Useful for measurement-channel troubleshooting
- Supports controlled diagnostic testing
- Helps evaluate the proximity signal path
- Suitable for field and workshop applications
- Applicable to rotating-machinery service work
- Dimensions of 195 × 299 × 248 mm
- Stated weight of 5.22 kg
Technical FAQs
What is the main purpose of the TK-3E 177313-01-02-00?
The TK-3E 177313-01-02-00 is used for testing and verification of compatible proximity measurement systems. It is mainly used during commissioning, maintenance, and troubleshooting activities.
Why is a test kit useful when a proximity channel shows an abnormal reading?
An abnormal reading does not necessarily mean that the proximity probe has failed. The test kit allows technicians to investigate the measurement chain and distinguish potential sensor, cable, interface, monitoring, and machine-related issues.
Does the TK-3E 177313-01-02-00 remain installed during normal machine operation?
No. It is service and test equipment intended to be introduced into the system when testing or diagnostic work is required. It is not treated as a normal permanent monitoring component.
What should be verified before using this test kit?
The complete part number, equipment under test, proximity-system configuration, connection arrangement, associated accessories, and applicable testing procedure should be verified before use. The test kit itself should also be inspected for physical damage.
