Product Overview
The Bently Nevada 3500/94M (145988-01) is an industrial visualization interface module designed for integration within the Bently Nevada 3500 machinery protection and condition monitoring system.
This module provides VGA-based display output functionality, enabling real-time visualization of system data such as vibration, temperature, alarms, and diagnostics. It serves as a key bridge between the 3500 monitoring rack and external display devices used in control rooms and industrial monitoring stations.
Designed for continuous operation, it ensures stable and reliable graphical output in critical industrial environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 3500/94M |
| Part Number | 145988-01 |
| Product Type | VGA Display Module |
| Function | Video output and monitoring visualization |
| System Compatibility | Bently Nevada 3500 Series |
| Output Interface | VGA signal |
| Data Type | Machinery condition monitoring data |
| Dimensions | 241.3 × 24.4 × 241.8 mm |
| Weight | 0.73 kg |
| Installation | Rack-mounted module |
| Application | Industrial monitoring and visualization |
| Environment | Industrial-grade |
| Role | Display interface module |
| Reliability | Continuous duty operation |
Function and Working Principle
The Bently Nevada 3500/94M (145988-01) functions as a visualization output interface within the 3500 system architecture.
Key functions include:
- Converting monitoring system data into VGA display signals
- Transmitting real-time machinery condition information
- Supporting graphical visualization of vibration and process data
- Ensuring stable and continuous video output
It enables operators to clearly view system health information in real time.
System Role and Importance
Within the Bently Nevada 3500 ecosystem, this VGA display module plays a central role in visualization.
It enables:
- Real-time display of machinery condition parameters
- Integration of multiple monitoring inputs into visual output
- Improved operator awareness and system transparency
- Enhanced decision-making through graphical data representation
It is essential for translating monitoring data into actionable visual insights.
Industrial Applications
The Bently Nevada 3500/94M (145988-01) is widely used in:
- Oil and gas production facilities
- Power generation plants
- Petrochemical and refining industries
- Industrial automation control rooms
- Turbine and compressor monitoring systems
- Heavy rotating machinery environments
It is especially suitable for applications requiring continuous visual monitoring of equipment health.
Installation and Integration
Proper installation ensures stable performance:
- Installed in Bently Nevada 3500 rack systems
- Connected to VGA-compatible industrial monitors
- Integrated with monitoring and communication modules
- Configured for signal mapping and display output
- Requires proper grounding and shielded cabling
Correct installation ensures stable and high-quality video output.
Compatible System Components
The VGA Display Module works alongside:
- Bently Nevada 3500 rack platform
- Display Interface Modules (3500/93 series)
- Communication Gateway Modules (3500/90 and 3500/92 series)
- VGA Monitor Main and I/O modules (3500/94 series)
- Display Router Box modules
- Vibration and temperature monitoring modules
Together, these components form a complete industrial monitoring visualization system.
Recommended Alternative Models
| Model | Type | Key Feature | Application |
|---|---|---|---|
| 3500/94 (184826-01) | VGA monitor main module | Primary visualization control | Display systems |
| 3500/94 (147663-01) | VGA I/O module | Video output interface | Monitoring displays |
| 3500/93 | Display interface module | Operator visualization | Control room systems |
| 3500/92 | Communication gateway | System integration | Industrial networking |
| 3500/90 | Gateway module | Data communication | Plant-wide systems |
Key Advantages
- Stable VGA display output performance
- Real-time monitoring visualization
- Industrial-grade reliability
- Seamless integration with 3500 system
- Supports continuous operation environments
- Enhances operator visibility and control
Technical FAQs
What is the main function of this module?
It provides VGA display output for the Bently Nevada 3500 monitoring system.
What type of signal does it output?
It outputs VGA video signals for external industrial display devices.
Where is it used?
It is used in industrial control rooms and machinery monitoring environments.
Conclusion
The Bently Nevada 3500/94M (145988-01) is a critical visualization component within the Bently Nevada 3500 system. It ensures stable VGA output and enables real-time display of machinery condition data.
For industrial engineers and operators, it provides a reliable and efficient solution for system visualization, improving operational awareness and decision-making in demanding industrial environments.
