Product Overview & Description
The 3500/42M 140734‑02 + 140471‑01 module is a sophisticated two-card solution engineered for rack-mounted machinery health monitoring. The front card (140734‑02) provides comprehensive signal conditioning—accommodating proximity, seismic, velocity, and acceleration inputs to measure radial vibration, axial displacement, eccentricity, shaft absolute position, REBAM diagnostics, and circular acceptance analysis. The rear card (140471‑01) introduces dedicated tachometer (speed) I/O, enabling precise rotational velocity tracking. Together, they deliver high-resolution multi-domain monitoring—ideal for critical rotating equipment. Hot-swap capability ensures maintenance without system interruption.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | 3500/42M 140734‑02 + 140471‑01 |
| Brand | (omitted) |
| Series | 3500 Machinery Protection – Proximitor/Seismic Monitor |
| Type | Four‑channel proximitor/seismic monitor with tachometer I/O |
| Dimensions (mm) | Front card: ~165 × 133 × 85 mm; Rear card: standard rack‑mount depth (≈ 160 mm) |
| Weight (kg) | Front: ~1.0 kg; Rear: ~0.35 kg |
| Input Channels | Four differential channels (~10 kΩ) accepting proximity, velocity, and acceleration sensors |
| Measured Parameters | Vibration, axial displacement, expansion, eccentricity, velocity, acceleration, shaft position |
| Power Consumption | Approximately 8 W (24 V DC rack) |
| Outputs | Buffered analog outputs, dual 4–20 mA loops, and tachometer output |
| Sensitivity | Displacement: ~3.94 mV/µm or ~7.87 mV/µm; Velocity: ~20 mV/(mm/s); Tach: per sensor specifics |
| LED Indicators | Operational status, TA input, TX/RX, bypass, channel fault status |
| Operating Range | –40 °C to +85 °C industrial grade |
| Mounting | Rack-mount; hot-swappable front and rear modules |
Applications
This module excels in providing robust, real‑time condition monitoring for rotating machinery—from turbines and compressors to pumps and gearboxes. It supports multi-domain diagnostics (displacement, vibration, velocity, acceleration, and speed), enabling early detection of misalignment, imbalance, shaft resonance, or bearing wear. The tachometer output supports speed synchronization for data correlation and diagnostics. Its hot-swap design and output versatility make it a solid choice for integration into control systems, condition‑monitoring platforms, and predictive‑maintenance schemes.
Advantages
-
All-in-one monitoring: Monitors vibration, displacement, shaft velocity, and structural behavior within one cohesive module.
-
High-quality outputs: Buffered analog and 4–20 mA loops ensure reliable data feeds; dedicated tachometer channel enables accurate speed feedback.
-
Service on-the-fly: Hot‑swappable capability allows module servicing without production downtime.
-
Compact, clear installation: Internal termination keeps wiring neat and reduces clutter.
-
Wide integration: Compatible with DCS, SCADA, PLCs, and analytics systems.
-
Built for extremes: Sturdy design sustains wide temperature variation and industrial stress.
Related Models (Same Series or Related)
| Model | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| 3500/42M + 128229‑01 | Monitor with standard internal I/O | Similar front + ~160 mm rear | ~1.0 + ~0.2 |
| 3500/42M + 128240‑01 | Module with external I/O termination | Similar | Comparable |
| 3500/40M 140734‑01 | Proximity-only front card | Same front size | ~1.0 |
| 3500/42M + 135489‑01 | Barrier-protected internal I/O module | Similar | Similar |
| 3500/40M 140471‑01 | Velocity-only I/O module with integrated termination | Similar | ~0.3 |
Popular Models (Same Brand)
| Model | Description | Dimensions (mm) | Weight (kg) |
|---|---|---|---|
| 3500/22M | Transient waveform capture interface | Standard front size | ~0.9 |
| 3500/32M | 4-channel alarm relay module | Standard front size | ~0.9 |
| 3500/33 | Temperature monitoring (RTD/Thermocouple) module | Standard front size | ~0.9 |
| 3500/50M | Tachometer/speed input module | Standard front size | ~0.9 |
| 3500/60 | Multifunction temperature monitoring module | Standard front size | ~0.9 |
FAQ (10 Q&A)
-
Q: What does the front card (140734‑02) do?
A: It processes displacement, vibration, velocity, and acceleration sensor signals to produce comprehensive mechanical diagnostics. -
Q: What role does the rear card (140471‑01) serve?
A: It provides a tachometer (speed) input and connections while maintaining hot‑swap capability. -
Q: How many channels are supported?
A: Four measurement channels, each configurable for various sensor types. -
Q: What are the operating temperature limits?
A: Suitable for −40 °C to +85 °C, ideal for wide-ranging industrial environments. -
Q: How much power does the module use?
A: Approximately 8 W powered from standard 24 V DC rack supply. -
Q: What outputs are available for integration?
A: Buffered analog outputs, dual 4–20 mA loops, and dedicated tachometer feedback. -
Q: Can it be serviced without shutting down systems?
A: Yes—hot‑swap capability ensures zero downtime during maintenance. -
Q: What are the size and weight of the module?
A: Front card: ~165 × 133 × 85 mm (~1.0 kg); Rear card: ~160 mm deep, ~0.35 kg. -
Q: What sensor sensitivities are supported?
A: Typical sensitivities include ≤8 mV per micron (displacement), 20 mV per mm/s (velocity), plus tachometer according to sensor. -
Q: How does it integrate with control systems?
A: Outputs suit analog recorders, DCS, SCADA, and analytics platforms; tach input aids synchronization and speed‑related diagnostics.
