✅ Product Introduction
The Bently Nevada 3500/32M Relay Module (Part Number: 184704-01) is a 4-Channel Relay Output Module designed for use in the 3500 Machinery Protection System. This module provides independent, programmable alarm outputs, each capable of being configured with logical voting, latch functions, and fail-safe or non-fail-safe operations.
It acts as a hardware interface between the monitoring rack and external control systems such as shutdown circuits, alarms, or interlocks. This module is essential for turning monitored alarm conditions into real-world actions like equipment shutdown or process control triggers.
📐 Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/32M |
| Part Number | 184704-01 |
| Function | 4-Channel Relay Output Module |
| Channels | 4 Independent Relay Outputs |
| Relay Type | Electromechanical, SPDT (Single Pole Double Throw) |
| Logic Functions | AND, OR, VOTE, LATCH |
| Power Supply | From 3500 rack backplane |
| Installation Position | Slot next to TDI Module in 3500 rack |
| Contact Rating | 5A @ 24VDC / 240VAC (resistive load) |
| Relay Life | ≥100,000 operations (at rated load) |
| Hot Swappable | No (recommended to power down rack before replacement) |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | ≤ 95% non-condensing |
| Dimensions (H × W × D) | 241 mm × 24.4 mm × 242 mm |
| Weight | 0.7 kg |
| Certifications | Supports Zone 2/Div 2 installations with proper config |
| EMC Compliance | Industrial-grade electromagnetic compatibility |
🧩 Applications
-
Alarm Relay Output
Provides hardware relay outputs for alarms triggered by monitored parameters. -
Emergency Shutdown Integration
Used in machinery protection systems to trigger shutdowns based on critical condition thresholds. -
Control Logic Interfacing
Can perform programmable logic functions to combine multiple input alarms before triggering output. -
Redundant System Design
Used in high-reliability systems for multiple relay outputs to ensure protection even during module failures. -
Remote Signaling
Sends relay signals to DCS/PLC/SCADA systems to trigger remote alerts or automatic responses.
🛠️ Key Advantages
-
Programmable Logic Functions
Supports advanced logic like AND, OR, VOTING, and LATCH per channel. -
Independent Relay Channels
Each relay output is fully configurable and isolated. -
Seamless 3500 Integration
Designed to work natively with the 3500 rack system architecture. -
Fast Switching
Relay activation is rapid for real-time response in protection scenarios. -
Industrial-Grade Durability
Built for tough environments with wide temperature and humidity tolerances. -
Electrically Isolated Outputs
Helps prevent electrical noise or surges from damaging sensitive monitoring equipment. -
Failsafe Options
Supports failsafe or non-failsafe configurations for safety-critical applications. -
Diagnostic LEDs
LED indicators provide quick module and relay status visibility.
🏷️ Brand & Series
| Attribute | Detail |
|---|---|
| Brand | Bently Nevada |
| Series | 3500 Machinery Protection System |
| System Compatibility | Fully compatible with 3500 Rack System |
| Module Role | Relay Output Module |
| System Position | Installed adjacent to the TDI module |
🔁 Related Models (Same Series)
| Model | Function | Key Feature |
|---|---|---|
| 3500/33 | 16-Channel Relay Module | High-density relay output for larger systems |
| 3500/40M | Proximitor Monitor | Monitors shaft displacement and gap voltage |
| 3500/42M | Vibration & Position Monitor | Dual input channels for radial vibration and position |
| 3500/50M | Tachometer Module | Measures shaft speed, 1X, and reverse rotation |
| 3500/22M | Transient Data Interface (TDI) | Central configuration and data communication module |
⭐ Popular Models from the Same Brand
| Model | Function | Key Features |
|---|---|---|
| 3500/45 | Position Monitor | Measures axial thrust, differential expansion, etc. |
| 3500/60 | RTD Temperature Monitor | Monitors temperature via Resistance Temperature Devices |
| 3500/61 | Thermocouple Monitor | Supports multiple TC types for process temperature |
| 3500/65 | 16-Channel Temperature Monitor | High-density module for expanded temperature coverage |
| 3500/53 | Overspeed Detection Module | Critical protection for rotating machinery overspeed |
❓ FAQ – Top 10 Questions (QA Format)
Q1: What is the main purpose of the 3500/32M module?
A1: The 3500/32M outputs relay signals based on configured alarm conditions, enabling machinery shutdown, alarms, or interlock operations.
Q2: Can each relay channel be configured independently?
A2: Yes, all four channels are fully independent and programmable with unique logic and trip conditions.
Q3: Is this module hot-swappable?
A3: No, it’s recommended to power down the rack before installing or removing the module.
Q4: What kind of loads can the relays drive?
A4: The relays can handle up to 5A at 24VDC or 240VAC for resistive loads. Inductive loads require proper suppression.
Q5: How is logic configured for the relay outputs?
A5: Logic is configured using the 3500 configuration software. You can assign AND/OR/VOTE/LATCH functions to each output.
Q6: Is this module safe for hazardous area installations?
A6: Yes, when properly installed, it supports use in Zone 2 and Division 2 hazardous environments with corresponding certifications.
Q7: What is the relay response time?
A7: Response time is very fast, typically in milliseconds, depending on system logic and alarm processing.
Q8: How can I verify if a relay is working?
A8: Check the module’s LED indicators, monitor status via the TDI, and use test functions in the configuration software.
Q9: How long do the relays last?
A9: Under rated conditions, relay life is typically over 100,000 switching cycles.
Q10: Can I use multiple 32M modules in one system?
A10: Yes, systems can include several 32M modules to increase relay output capacity or create redundant output configurations.
