Product Overview: Bently Nevada 3500/22M 288055‑01 + 146031‑01
This combination forms a Transient Data Interface (TDI) solution within the 3500 Series Machinery Protection System. The 288055‑01 is the main TDI module, which captures and relays both steady-state and transient data via Ethernet. The 146031‑01 acts as a companion I/O module, enabling the handling of Ethernet input/output. Together, they serve as a robust communications gateway for real‑time diagnostics, condition monitoring, and data-driven predictive maintenance.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Combination | 3500/22M 288055‑01 + 146031‑01 |
| Function | Transient Data Interface + I/O Module |
| Communication Interfaces | Ethernet (10/100Base-TX, fiber variant), and RS‑232/485 (TDI module) |
| Data Captured | Static data, dynamic vibration, transient waveforms |
| Protocols Supported | Proprietary Real‑time data protocol for condition monitoring |
| Configuration Interface | Configuration via dedicated rack software (e.g., System 1® tool) |
| Power Consumption | ~10.5 W (for the TDI module) |
| Operating Temperature | –30 °C to +65 °C (TDI); –40 °C to +70 °C (module combo dependent) |
| Storage Temperature | –40 °C to +85 °C |
| Humidity Rating | Up to 95% non‑condensing |
| Dimensions | Approx. 24.13 × 2.44 × 24.18 cm (depth × width × height per module) |
| Weight | TDI module ~0.91 kg; I/O module ~0.20 kg; Combined module set ~1.1 kg |
Product Description
The 3500/22M 288055‑01 captures both transient and static data from multiple monitoring channels and streams through Ethernet for real‑time analysis. The companion 146031‑01 I/O module facilitates Ethernet connectivity and data signal routing. Together, they replace older rack interface models with a consolidated, high-speed, resilient communication channel, ideal for integrating with supervisory systems and analytics platforms.
Applications
Deployed across mission‑critical monitoring systems, this module pair is widely used in:
-
Power generation (turbines, generators)
-
Oil & gas (compressors, pumps, refining equipment)
-
Petrochemical plants
-
Mining operations and heavy industrial machinery
-
Marine propulsion monitoring
-
Pulp & paper and Water/Wastewater infrastructure
It excels in capturing transient events like startups, shutdowns, and fault conditions while providing seamless system integration.
Product Advantages
-
All-in-One Communication Module – Combines rack interface and data acquisition in a single, compact package.
-
Transient Event Capture – Records dynamic waveform data critical for root‑cause analysis.
-
High‑Speed Ethernet – Ensures rapid data delivery with low latency.
-
Redundancy-Ready – Can be paired with dual modules for failover reliability.
-
Hot-Swappable – Replaceable without shutting down the rack.
-
Wide Environmental Tolerance – Withstands temperature extremes and high humidity.
-
Simplified Integration – Plug‑and‑play operation with monitoring software simplifies setup and maintenance.
Related or Similar Models (Same Series)
| Model | Function | Key Features | Weight (kg) | Dimensions (cm) |
|---|---|---|---|---|
| 3500/22M 288055‑01 | Transient Data Interface (TDI) | Captures static & transient data | 0.91 | 24.13 × 2.44 × 24.18 |
| 3500/22M 146031‑01 | I/O Ethernet Interface Module | Handles data I/O for TDI | 0.20 | ~24.13 × 2.44 × 24.18 |
| 3500/22M 146031‑02 | Enhanced I/O Revision | Redesigned for updated racks | 0.20 | Same |
| 3500/25 | Keyphasor Module | Phase reference and speed data | 0.50 | 24.1 × 3.8 × 23.1 |
| 3500/20 | Rack Interface Module | Basic static data communication | 0.47 | 24.1 × 3.8 × 23.1 |
Popular Models of the Same Brand
| Model | Function | Key Features | Weight (kg) | Dimensions (cm) |
|---|---|---|---|---|
| 3500/42M | Vibration Monitoring Module | Radial and thrust vibration tracking | 0.48 | 24.1 × 3.8 × 23.1 |
| 3500/15 | Power Supply Module | Provides system and backup power | 0.55 | 24.1 × 3.8 × 23.1 |
| 3500/05 (Rack) | Module Chassis | Houses multiple monitoring modules | 3.5 | 33 × 48 × 30 |
| 3500/53 | Overspeed Detection Module | Protects turbines by detecting high RPM | 0.50 | 24.1 × 3.8 × 23.1 |
| 3500/94M | Touchscreen Display Module | User-friendly live data visualization | 0.62 | 24.1 × 3.8 × 23.1 |
FAQ – Frequently Asked Questions (Q&A)
Q1: What exactly is this model combination?
A1: It’s the Transient Data Interface paired with its Ethernet I/O companion, bridging rack data to external analytics systems.
Q2: What types of data does it handle?
A2: It captures both static measurements and high-speed transient vibration, temperature, alarms, and event data.
Q3: Is it hot-swappable?
A3: Yes, it can be replaced without powering down the rack.
Q4: How does it support redundant setups?
A4: Dual modules can be installed to provide automatic failover in critical systems.
Q5: Which connection interface does it use?
A5: Primarily Ethernet (10/100Base-TX or fiber-optic), plus RS‑232/485 connectivity on the TDI.
Q6: What is the weight of the complete set?
A6: Together, they weigh around 1.1 kg.
Q7: Can it operate in extreme environments?
A7: Yes, it functions between –30 °C to +65 °C and tolerates high humidity.
Q8: How is it configured?
A8: Configuration is performed using rack configuration tools or System 1® software.
Q9: What industries benefit most from it?
A9: Power generation, oil & gas, petrochemicals, mining, marine, and heavy machinery sectors.
Q10: What are its main advantages?
A10: All-in-one communication, transient data capture, high-speed Ethernet, integration simplicity, and environmental resilience.
