Product Overview: 3500/22M 138607‑01 + 146031‑01
This pair comprises a System Interface Module (138607‑01) and its companion I/O module (146031‑01) that work together within the 3500 Machinery Protection System. The first unit captures and buffers monitoring data from the rack (including alarms, static and dynamic values), while the second enables Ethernet communication and configuration access. Together, they establish a dependable gateway for diagnostic and control systems.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Combination | 3500/22M 138607‑01 + 146031‑01 |
| Function | System Interface + Ethernet I/O Module |
| Communication Methods | Buffered Output, Ethernet (10/100Base‑TX) |
| Supported Protocols | Modbus TCP/IP, Proprietary TCP, HTTP for configuration |
| Configuration Interface | Web browser via Ethernet IP |
| Power Consumption | Approx. 5 W |
| Operating Temperature | –30 °C to +65 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity Rating | Up to 95% non‑condensing |
| Ruggedness | Industrial‑grade construction |
| Weight | ~0.62 kg combined |
| Dimensions (HxWxD) | Approx. 24.1 × 3.8 × 23.1 cm per module |
Product Description
The 138607‑01 module acts as a buffer for static, dynamic, and alarm data in the 3500 rack; the 146031‑01 enables plant network integration via Ethernet. Together, these modules replace older communication interfaces, improving data throughput and reliability. Configurable via a web browser, they support real-time condition monitoring and efficient diagnostics in critical machinery environments.
Applications
This module pair is widely used in industries that demand accurate and reliable machinery condition monitoring:
-
Power generation turbine and generator systems
-
Refining and petrochemical operations
-
Oil & gas upstream, midstream, and downstream platforms
-
Heavy manufacturing and process industries
-
Marine engine and propulsion condition monitoring
-
Pulp & paper and industrial automation plants
Product Advantages
-
Modular Communication Interface – Combines buffered data capture and Ethernet output.
-
User-Friendly Configuration – Web-based setup makes deployment simple and accessible.
-
Compact and Efficient – Takes minimal space while providing full data interface functionality.
-
Rugged Reliability – Withstands extreme temperatures and humid conditions.
-
Fast Integration – Easily fits into standard racks and connects to modern control systems.
-
Improved System Resilience – Reduces risk of data loss with buffered output and reliable Ethernet.
Related or Similar Models (Same Series)
| Model | Function | Key Features | Weight (kg) | Dimensions (cm) |
|---|---|---|---|---|
| 3500/22M 138607‑01 | System Interface Module | Buffered data output | 0.42 | 24.1 × 3.8 × 23.1 |
| 3500/22M 146031‑01 | Ethernet I/O Module | I/O interface for Ethernet | 0.20 | 24.1 × 3.8 × 23.1 |
| 3500/22M 146031‑02 | Improved Ethernet I/O Module | Updated interface for newer racks | 0.20 | Same |
| 3500/20 | Rack Interface Module | Basic static data communication | 0.47 | 24.1 × 3.8 × 23.1 |
| 3500/25 | Keyphasor Module | Phase reference capture for rotating machines | 0.50 | 24.1 × 3.8 × 23.1 |
Popular Models of the Same Brand (Other Functions)
| Model | Function | Key Features | Weight (kg) | Dimensions (cm) |
|---|---|---|---|---|
| 3500/42M | Vibration Monitoring Module | Radial and thrust vibration tracking | 0.48 | 24.1 × 3.8 × 23.1 |
| 3500/15 | Power Supply Module | Supplies system power seamlessly | 0.55 | 24.1 × 3.8 × 23.1 |
| 3500/05 (Rack) | Module Chassis | Houses multiple modules for systematic deployment | 3.5 | 33 × 48 × 30 |
| 3500/53 | Overspeed Detection Module | Detects dangerous overspeed conditions | 0.50 | 24.1 × 3.8 × 23.1 |
| 3500/94M | Touchscreen Display Module | User-friendly interface for real-time data | 0.62 | 24.1 × 3.8 × 23.1 |
FAQ – Frequently Asked Questions (Q&A)
Q1: What do these modules do together?
A1: One buffers rack data; the other provides Ethernet I/O to integrate with control systems.
Q2: What data is handled?
A2: The pair handles static values, alarms, and dynamic system conditions.
Q3: How is it configured?
A3: Via a web browser connected to the Ethernet interface—no specialized tools needed.
Q4: What is the weight of both modules?
A4: Combined, they weigh approximately 0.62 kg.
Q5: Can they survive rough environments?
A5: Yes—they operate from –30 °C to +65 °C and resist high humidity.
Q6: Are they compatible with all 3500 racks?
A6: Yes—they integrate seamlessly into standard 3500 rack systems.
Q7: Does this setup improve reliability?
A7: Absolutely—redundant buffering and Ethernet reduce data loss risk.
Q8: Is it easy to install?
A8: Yes—modules are plug-and-play and use straightforward web configuration.
Q9: Which industries use this combo most often?
A9: Power plants, oil & gas, manufacturing, marine systems, and pulp & paper facilities.
Q10: What power do they draw?
A10: Together, they use approximately 5 watts.
