Industrial Servo Drive Module Report – 2198-H025-ERS2
1. Product Overview
The 2198-H025-ERS2 is a high-performance servo drive module designed for advanced industrial motion control systems. It is built for applications requiring high torque output, precise multi-axis coordination, and stable long-term operation under heavy load conditions.
This model is part of a modular servo drive platform designed to support scalable machine architectures, high-speed communication, and flexible system integration.
2. Brand and Product Series
- Brand: Industrial automation motion control manufacturer (not specified)
- Product Series: Kinetix 5700 Servo Drive Platform
- Product Category: High-power servo drive module
This series is widely used in industrial automation due to its modular structure, compact footprint, and strong real-time synchronization capabilities.
3. Product Introduction
The 2198-H025-ERS2 servo drive is engineered for high-demand motion control environments where precision and power must coexist. It provides accurate regulation of torque, speed, and position, ensuring stable performance under fluctuating industrial loads.
It is commonly used in systems requiring:
- High-power servo motion control
- Multi-axis synchronization
- Continuous heavy-duty operation
- High-speed industrial automation
The module is designed for cabinet installation and integrated into distributed motion control systems.
4. Technical Parameters
Core Specification Table
| Parameter | Specification |
|---|---|
| Model | 2198-H025-ERS2 |
| Product Type | Servo Drive Module |
| Series | Kinetix 5700 |
| Input Voltage | 3-phase AC 200–480V |
| Rated Output Power | ~7–12 kW class |
| Continuous Output Current | ~25 A |
| Peak Output Current | ~50 A |
| Control Method | Vector servo control |
| Communication | Industrial Ethernet motion network |
| Feedback Support | High-resolution encoder feedback |
| Safety Function | Integrated Safe Torque Off (STO) |
| Cooling Method | Forced air cooling |
| Mounting Type | Cabinet-mounted |
| Protection Level | Industrial enclosure standard |
| Dimensions (H × W × D) | ~320 × 100 × 230 mm |
| Weight | ~6.2 – 7.9 kg |
5. Product Application Areas
The 2198-H025-ERS2 is widely used in heavy-duty and high-precision automation environments where motion stability and torque consistency are critical.
Typical Applications
- Heavy CNC machining systems
- Industrial robotics with high payload requirements
- Automated packaging and palletizing lines
- Large conveyor and logistics systems
- Printing and converting machinery
- Semiconductor manufacturing equipment
- Multi-axis assembly systems
- Metal processing automation equipment
It performs especially well in systems requiring synchronized motion under continuous load conditions.
6. Product Advantages
High Torque Stability
Maintains consistent performance under high load and rapid load changes.
Precise Motion Control
Ensures accurate positioning and smooth speed transitions in complex motion profiles.
Compact High-Power Design
Optimized structure reduces cabinet space while maintaining high output capability.
Advanced Thermal Management
Efficient cooling system supports long-term high-current operation.
Strong System Scalability
Easily integrated into multi-axis distributed control architectures.
High Industrial Reliability
Designed for continuous duty cycles in demanding production environments.
7. Recommended Models – Same Series / Related Models
Kinetix 5700 Series Related Models
| Model | Performance Level | Rated Current | Power Range | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 2198-H015-ERS2 | Medium-high | ~15 A | 4–7.5 kW | 260×80×220 | ~4.8 |
| 2198-H020-ERS2 | High power | ~20 A | 7–10 kW | 300×80×220 | ~5.6 |
| 2198-H025-ERS2 | High power | ~25 A | 7–12 kW | 320×100×230 | ~7.0 |
| 2198-H030-ERS2 | Very high power | ~30 A | 10–15 kW | 340×120×240 | ~7.8 |
| 2198-H040-ERS2 | Heavy duty | ~40 A | 15–20 kW | 360×140×250 | ~9.5 |
8. Recommended Popular Models (Same Brand Portfolio)
Widely Used Servo Drive Models
| Model | Application Focus | Power Range | Control Type | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| 2198-H025-ERS2 | High-load automation systems | ~7–12 kW | Servo vector control | 320×100×230 | ~7.0 |
| 2198-E2007-ERS | Standard automation lines | ~3–5 kW | Advanced servo control | 280×60×200 | ~3.0 |
| 2198-E2055-ERS | Medium industrial systems | ~5–10 kW | Multi-axis servo control | 320×80×220 | ~4.3 |
| 2198-E2090-ERS | Heavy industrial systems | ~10–15 kW | High-power servo control | 350×120×250 | ~6.9 |
| 2198-E2120-ERS | Ultra heavy-duty systems | ~15–25 kW | Industrial servo control | 380×150×260 | ~8.5 |
9. Engineering Summary
The 2198-H025-ERS2 represents a high-end configuration within the H-series servo drive platform. It is designed to handle demanding industrial motion tasks requiring both high torque output and precise multi-axis synchronization.
Key engineering highlights include:
- High continuous current capacity
- Strong dynamic load adaptability
- Advanced thermal efficiency design
- Compact but high-density architecture
- Stable long-term industrial operation capability
This model is best suited for large-scale automation systems where performance stability and durability are critical under continuous heavy-duty conditions.
