2198-D006-ERS3 Servo Drive Module – Full Technical Overview
Product Introduction
The 2198-D006-ERS3 is a compact high-performance industrial servo drive module designed for precision motion control applications requiring fast response, stable torque output, and multi-axis synchronization capability. It is engineered for advanced automation systems where space efficiency, motion accuracy, and system integration are critical.
This model belongs to the Kinetix 5500 integrated servo platform and is designed for compact machine architectures that require high-speed Ethernet-based communication and simplified multi-axis wiring.
The drive is commonly used in industrial systems where precise positioning, coordinated motion, and scalable servo control are required in a compact footprint.
Brand Information
| Item | Description |
|---|---|
| Brand | Industrial Motion Control Platform |
| Product Category | Integrated Servo Drive Module |
| Product Type | Compact Servo Amplifier |
| Control Method | Digital Servo Control |
| System Architecture | Integrated Multi-Axis Motion System |
| Installation Type | Panel Mounted Module |
| Communication Feature | Ethernet-based real-time motion control |
| Cooling Method | Forced Air Cooling |
| Application Level | Industrial Automation & Compact Machinery |
Product Series – Kinetix 5500 Platform
The Kinetix 5500 series is a modern integrated motion control platform designed for compact industrial automation systems requiring high-performance servo control in a simplified architecture.
It integrates power, control, and communication into a single system, reducing wiring complexity and improving system efficiency.
Key characteristics include:
- Integrated servo drive architecture
- High-speed Ethernet motion control
- Compact modular design
- Multi-axis synchronization capability
- High dynamic response performance
- Simplified installation and wiring
- Scalable motion system design
- Industrial-grade reliability
Detailed Technical Specifications – 2198-D006-ERS3
Main Parameters
| Parameter | Specification |
|---|---|
| Model | 2198-D006-ERS3 |
| Product Type | Compact Integrated Servo Drive |
| Series | Kinetix 5500 |
| Input Voltage | 200–480V AC Industrial Supply |
| Control Method | Digital Servo Control |
| Continuous Output Current | Approx. 6 A |
| Peak Output Current | Short-term overload capability |
| Communication System | Ethernet-based real-time motion network |
| Feedback Compatibility | Encoder-based servo motors |
| Motor Compatibility | Low to medium power servo motors |
| Safety System | Integrated Safe Torque Off (STO) |
| Protection Functions | Overcurrent / Overvoltage / Overtemperature |
| Cooling Method | Forced Air (Cabinet Cooling) |
| Mounting Type | Panel Mount |
| Enclosure Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Humidity Range | 5–95% Non-condensing |
| Vibration Resistance | Industrial Grade |
| Efficiency | High-efficiency servo control |
| Dimensions | 60 × 280 × 240 mm |
| Weight kg（ ） | 4.2 kg |
Product Structure and Design Features
Compact Integrated Architecture
The 2198-D006-ERS3 is designed for compact machine installations requiring efficient use of cabinet space.
It integrates control and power stages into a unified module, reducing system complexity and wiring requirements.
High-Speed Ethernet Motion Control
The drive uses Ethernet-based communication for real-time multi-axis synchronization.
Key benefits include:
- Fast motion coordination
- Reduced communication delay
- Simplified system wiring
- High synchronization accuracy
- Scalable motion network
Low Power Precision Control
This model is optimized for low-power servo applications requiring high precision and smooth motion control.
It ensures stable torque output even at low speeds.
Safety Integrated System
Built-in safety functions ensure secure operation in industrial environments.
Features include:
- Safe Torque Off (STO)
- Fault detection system
- Overload protection
- Emergency shutdown capability
Thermal Management System
Forced-air cooling ensures stable operation under continuous industrial load conditions.
Designed for compact cabinet installations with multiple axes.
Product Applications
Compact Automation Systems
Used in small to medium-sized industrial machines requiring high precision motion control.
Applications include:
- Assembly machines
- Compact automation lines
- Small conveyor systems
Packaging Equipment
Used in synchronized motion systems requiring accuracy and speed.
Applications include:
- Labeling machines
- Filling systems
- Light packaging equipment
Robotics Systems
Supports compact robotic motion applications.
Applications include:
- Small robotic arms
- Pick-and-place units
- Light handling systems
Printing and Processing Machines
Used in continuous motion systems requiring precision control.
Applications include:
- Small printing machines
- Film processing systems
- Light coating equipment
General Industrial Machinery
Used in scalable compact automation systems.
Applications include:
- Light manufacturing equipment
- Multi-axis compact machines
- Conveyor automation systems
Product Advantages
Compact Design
Optimized for space-saving installation in industrial cabinets.
High-Speed Ethernet Synchronization
Ensures precise multi-axis motion coordination.
Low Power Precision Control
Provides stable and smooth motion for light servo applications.
Integrated Safety Functions
Includes STO and system protection features.
Simplified System Architecture
Reduces wiring complexity and installation time.
Scalable Motion Control
Supports flexible expansion for small automation systems.
Recommended Models (Same Series / Related)
| Model | Series | Current | Voltage | Architecture | Dimensions | Weight kg（ ） | Notes |
|---|---|---|---|---|---|---|---|
| 2198-D003-ERS3 | Kinetix 5500 | 3 A | 200–480V | Integrated | 60 × 270 × 230 mm | 3.8 kg | Ultra-light axis |
| 2198-D006-ERS3 | Kinetix 5500 | 6 A | 200–480V | Integrated | 60 × 280 × 240 mm | 4.2 kg | Standard compact |
| 2198-D012-ERS3 | Kinetix 5500 | 12 A | 200–480V | Integrated | 70 × 290 × 240 mm | 5.0 kg | Medium light axis |
| 2198-D018-ERS3 | Kinetix 5500 | 18 A | 200–480V | Integrated | 70 × 300 × 250 mm | 5.7 kg | Medium power |
| 2198-D024-ERS3 | Kinetix 5500 | 24 A | 200–480V | Integrated | 80 × 310 × 250 mm | 6.3 kg | Heavy compact |
Recommended Popular Models (Same Ecosystem)
| Model | Type | Series | Key Specs | Dimensions | Weight kg（ ） | Applications |
|---|---|---|---|---|---|---|
| 1756-L85E | PLC Controller | ControlLogix | High-performance CPU | 145 × 132 × 140 mm | 1.3 kg | Industrial automation |
| 5069-L350ER | Controller | CompactLogix | Motion + Ethernet control | 145 × 138 × 105 mm | 1.1 kg | Factory systems |
| 2198-H003-ERS | Servo Drive | Kinetix 5500 | Low-power servo module | 60 × 270 × 230 mm | 3.9 kg | Compact motion |
| 25B-D012N104 | VFD Drive | PowerFlex 525 | 5.5 kW motor drive | 180 × 260 × 190 mm | 4.8 kg | Motor control |
| 2711P-T7C22D9P | HMI Panel | PanelView Plus 7 | 7” operator panel | 210 × 150 × 55 mm | 1.8 kg | Machine interface |
Industrial Position Summary
The 2198-D006-ERS3 is positioned as a compact integrated servo drive designed for small-scale industrial automation systems requiring high precision, Ethernet-based synchronization, and simplified machine architecture.
It is widely used in packaging, robotics, compact assembly systems, and light industrial automation applications.
Conclusion
The 2198-D006-ERS3 is a compact high-performance integrated servo drive designed for industrial automation systems requiring precise motion control, fast communication, and space-efficient design.
Its Ethernet-based synchronization, compact architecture, safety integration, and scalable design make it suitable for modern compact machinery, robotics, and light industrial automation systems.
