Allen Bradley 1606-XLE120E Power Supply Installation Guide

2026-08-28

Table of Contents

Allen Bradley 1606-XLE120E Power Supply Installation Overview

Allen Bradley 1606-XLE120E Power Supply installation is most successful when electrical planning is completed before any wiring begins. Incorrect grounding, overloaded DC circuits, undersized cables, and poor cabinet ventilation cause considerably more commissioning failures than defective hardware.

The 1606-XLE120E Power Supply is designed to provide regulated DC power for industrial automation equipment including PLC Controller systems, I/O Modules, Sensors, HMIs, industrial Ethernet switches, communication modules and related control devices. A successful Installation Guide focuses on the complete power distribution path instead of only connecting input and output terminals.

Allen Bradley 1606-XLE120E Installation Planning

Before installation, engineers should compare the electrical drawings with the actual control cabinet to verify the intended System Configuration.

  • Confirm incoming AC power.
  • Calculate total DC load.
  • Review future expansion capacity.
  • Verify branch protection.
  • Separate control power from high-current equipment.
  • Identify critical PLC Controller loads.
  • Prepare commissioning measurements.

Many field problems originate because additional communication modules or remote I/O stations were added after the original design without updating the power calculations.

Allen Bradley 1606-XLE120E Mounting Environment

Install the power supply inside a clean industrial control cabinet with sufficient airflow. Leave adequate clearance around the unit to support heat dissipation and simplify maintenance.

Avoid mounting directly beside variable frequency drives, braking resistors or transformers whenever cabinet layout allows. Reducing thermal stress generally improves long-term reliability.

Allen Bradley 1606-XLE120E Wiring and Power Connections

Correct wiring is essential for reliable Setup and Commissioning.

  • Verify incoming AC voltage before energizing.
  • Connect protective earth correctly.
  • Check DC polarity twice.
  • Use appropriately sized conductors.
  • Tighten every terminal according to project specifications.
  • Clearly label every outgoing DC branch.
Installation Logic

Incoming AC
      │
      ▼
1606-XLE120E
      │
      ▼
24VDC Distribution
      │
      ├── PLC Controller
      ├── Remote I/O Module
      ├── Sensors
      └── Ethernet Devices

Allen Bradley 1606-XLE120E Setup and Commissioning

During Commissioning, energize the Power Supply before connecting all downstream equipment simultaneously. Progressive loading makes abnormal behavior much easier to identify.

  1. Measure AC input.
  2. Measure DC output.
  3. Connect PLC Controller.
  4. Connect communication modules.
  5. Add field I/O.
  6. Monitor voltage stability.
  7. Run the machine under production conditions.

Record every measurement. These values become the reference for future Troubleshooting and Fault Diagnosis.

Allen Bradley 1606-XLE120E System Configuration Verification

Commissioning should verify the entire System Configuration instead of only the power supply.

  • Stable PLC operation.
  • No unexpected I/O faults.
  • Reliable communication.
  • Stable Sensor readings.
  • No excessive voltage drop.
  • No abnormal cabinet temperature rise.

Measure the DC voltage at both the power supply output and the furthest PLC or remote I/O device. Small voltage differences are normal, but excessive drop often indicates wiring problems.

Allen Bradley 1606-XLE120E Real Commissioning Case

During the commissioning of a packaging production line, engineers observed that several Ethernet I/O modules disconnected whenever pneumatic valves operated simultaneously.

Initial suspicion focused on the 1606-XLE120E Power Supply. Instead of replacing the unit immediately, measurements were taken at both the power supply output and the remote distribution block.

The output at the power supply remained close to 24 VDC while the remote terminal dropped to approximately 21.8 VDC during heavy load switching.

Further investigation identified an undersized distribution cable feeding the remote cabinet. After replacing the cable with a larger conductor and tightening all terminals, the voltage remained above 23.8 VDC under identical operating conditions. The communication faults disappeared completely without replacing the power supply.

This case demonstrates that voltage measurements should always be performed at the load rather than only at the power supply terminals.

Allen Bradley 1606-XLE120E Installation FAQ

Should the PLC Controller be connected before verifying the output?

It is good engineering practice to verify the regulated DC output before connecting critical automation equipment.

Why should voltage be measured at remote equipment?

Voltage loss can occur across long cables or loose terminals. Measuring only at the power supply may hide distribution problems.

How important is grounding?

Proper grounding improves electrical stability, EMC performance and overall reliability during long-term industrial operation.

Should commissioning values be documented?

Yes. Baseline measurements significantly reduce diagnostic time during future maintenance.

Allen Bradley 1606-XLE120E Technical Summary

The Allen Bradley 1606-XLE120E Power Supply Installation Guide should emphasize electrical planning, correct wiring, progressive Commissioning, load verification and complete System Configuration validation. Field experience consistently shows that careful installation and documented baseline measurements prevent many future power-related failures affecting PLC Controllers, Modules and Sensors throughout the automation system.
