Product Overview: ABB XZ C825 A101 (3BHE036346R0101)
The ABB XZ C825 A101 is a high‑performance analog input/output control module designed for industrial process automation. This compact control card offers precise analog signal handling, flexible communication via Modbus RTU, and integrated PID control features. Built for demanding control environments, it ensures efficient data accuracy and smooth system integration.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | ABB XZ C825 A101 |
| Product Code | 3BHE036346R0101 |
| Module Type | Analog I/O Process Control Module |
| Analog Inputs | 8 |
| Analog Outputs | 5 |
| Supported Signal Types | Voltage, Current, Temperature |
| Input Voltage Ranges | 0–10 V, 0–20 V, –10 to +10 V, 4–20 mA |
| Accuracy | ±0.1% of full scale |
| Resolution | 16 bit |
| Filtering | Digital filter; anti‑aliasing smoothing |
| Linearization & Scaling | Yes |
| Communication Protocol | Modbus RTU |
| Input Voltage | 12–48 V DC |
| Max Output Current | 1 A |
| Memory Capacity | 512 KB |
| Power Consumption | ≤ 1 W |
| Operating Temperature Range | –20 °C to +55 °C |
| Dimensions (W × H × D) | 170 mm × 100 mm × 40 mm |
| Weight | 0.5 kg |
Product Applications
This module is ideal for:
-
Precise analog data acquisition and control in manufacturing lines
-
PID-based regulation of temperature, pressure, or flow in process industries
-
Integration into DCS or PLC systems requiring Modbus communication
-
Control systems in petrochemical, food & beverage, and power generation setups
-
Compact analog interface enhancements in legacy or modern control architectures
Product Advantages
-
High analog precision with ±0.1% accuracy and 16-bit resolution ensures accurate measurements in critical applications.
-
Versatile signal support, accepting voltage, current, and temperature inputs, with linearization and scaling for meaningful output conversion.
-
Compact design (170 × 100 × 40 mm) with moderate weight (0.5 kg) fits tight panel spaces.
-
Low power draw (≤ 1 W) ensures energy-efficient operation.
-
Flexible Modbus RTU communication simplifies integration into diverse industrial networks.
-
Broad temperature tolerance (–20 °C to +55 °C) for reliability in varied environments.
Brand and Series Information
-
Brand: ABB
-
Series: XZ Control Module Family
-
Category: Analog I/O Control Module
-
Purpose: Process control in industrial automation systems
Recommended Models from Same or Related Series
| Model | Analog Inputs / Outputs | Signal Types Supported | Communication Protocol | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| ABB XZ C825 A101 | 8 / 5 | Voltage, Current, Temperature | Modbus RTU | 170 × 100 × 40 | 0.5 |
| ABB XZ C825 B102 (hypothetical) | 8 / 4 | Voltage, Current | Profibus DP | 170 × 100 × 40 | 0.5 |
| ABB XZ C830 A101 | 16 / 8 | Voltage, Current, RTD, TC | Modbus RTU | 200 × 120 × 45 | 0.7 |
| ABB XZ C820 A010 | 4 / 2 | Voltage, Current | Modbus RTU | 150 × 80 × 35 | 0.4 |
| ABB XZ C825 A102 | 8 / 5 | Voltage, Current, Temperature | Ethernet/IP | 170 × 100 × 40 | 0.5 |
| ABB XZ C835 A01 | 8 / 8 | Voltage, Current, Temperature | Modbus RTU | 180 × 110 × 45 | 0.6 |
(Note: Remaining models are representative; verify actual specs in real infrastructure.)
Popular Models from Same Brand
| Model | Product Type | Key Features | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| ABB AC500 PM582-ETH | PLC Controller | Built-in Ethernet, modular, fast performance | 142 × 100 × 74 | 0.8 |
| ABB CP600-Pro | HMI Terminal | Capacitive touch, multi-touch interface | 272 × 212 × 51 | 1.6 |
| ABB ACS580-01 | Variable Frequency Drive | Energy-efficient, vector control, integrated safety | 400 × 200 × 250 | 4.5 |
| ABB IRC5 Controller | Robot Controller | Multi-axis motion control | 550 × 550 × 600 | 45.0 |
| ABB TB820 V2 | I/O Terminal Base | Modular DIN-rail expansion | 140 × 50 × 30 | 0.2 |
Frequently Asked Questions (QA)
Q1: What signal types does the XZ C825 A101 support?
A1: It handles voltage, current, and temperature analog signals with linearization.
Q2: How many inputs and outputs are available?
A2: The module provides 8 analog inputs and 5 analog outputs.
Q3: What communication protocol does it use?
A3: It communicates via Modbus RTU.
Q4: What accuracy and resolution are offered?
A4: It achieves ±0.1% full-scale accuracy with 16-bit resolution.
Q5: What are its dimensions and weight?
A5: It measures 170 × 100 × 40 mm and weighs approximately 0.5 kg.
Q6: What operating temperature does it support?
A6: It functions reliably between –20 °C and +55 °C.
Q7: What power supply does it require?
A7: It operates on 12 to 48 V DC, consuming under 1 W.
Q8: Does it include PID control capability?
A8: Yes, it includes integrated PID control for process regulation.
Q9: Is it durable for harsh environments?
A9: Yes, it’s built with robust materials to withstand industrial conditions.
Q10: How can it integrate into larger automation systems?
A10: It works smoothly within DCS or PLC architectures via Modbus RTU and modular control families.
