Product Overview – ABB XV C768 AE101 (3BHB007211R0101)
The XV C768 AE101 is a powerful, high-reliability industrial control module designed for advanced automation and process control environments. With the part number 3BHB007211R0101, this module is part of the high-performance ABB Advant Controller / AC 800M series. Its robust architecture, advanced signal processing, and efficient communication capabilities make it an ideal component for mission-critical industrial applications.
Built for modularity and scalability, the XV C768 AE101 provides seamless integration into distributed control systems (DCS), offering flexibility and high-speed performance demanded by modern industrial infrastructures such as power plants, chemical processing facilities, and large-scale manufacturing environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | XV C768 AE101 |
| Part Number | 3BHB007211R0101 |
| Series | Advant Controller / AC 800M |
| Brand | ABB |
| Type | Control / Communication Module |
| Function | Industrial data processing and control |
| Input/Output Support | Supports analog and digital I/O |
| Power Supply Voltage | 24 VDC ±10% |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Mounting Type | DIN rail or panel mount |
| Dimensions | 225 mm x 105 mm x 70 mm |
| Weight | 1.10 kg |
| Communication Interface | Serial, Fieldbus, and Ethernet |
| CPU/Processing Unit | Embedded high-speed microprocessor |
| Firmware Compatibility | Fully supports AC 800M firmware versions |
| Cooling Type | Passive air cooling |
| Protection Class | IP20 (for cabinet installation) |
| Certifications | CE, RoHS, UL, Industrial EMC compliant |
Product Applications
-
Power Generation Facilities
Enables stable and safe control of turbines, transformers, and distribution systems through high-speed processing and reliable communication. -
Oil & Gas Industry
Controls remote sensors, pumps, and valves while supporting hazardous-area rated environments. -
Water Treatment & Distribution
Monitors and manages flow, filtration, and quality parameters in municipal and industrial water systems. -
Pharmaceutical Manufacturing
Offers precision in batch production, temperature control, and real-time diagnostics in GMP-compliant setups. -
Chemical & Petrochemical Plants
Supports complex control algorithms for dosing, mixing, and process safety management.
Product Advantages
-
Robust Industrial Design
Engineered to operate reliably in harsh environments with extended temperature tolerances and strong EMI shielding. -
Real-Time Control
Equipped with a high-performance CPU, it ensures rapid processing and deterministic responses in automation systems. -
Modular Scalability
Allows seamless expansion within DCS systems, supporting both centralized and decentralized architectures. -
Low Maintenance
Long operational lifecycle and stable firmware minimize service needs, reducing total cost of ownership. -
Multiple Protocol Support
Built-in flexibility to communicate across different industrial protocols, including PROFIBUS, Modbus, and Ethernet. -
Secure Architecture
Advanced firmware integrity checks and secure communication help protect against unauthorized access and cyber threats.
Series Information: Advant Controller / AC 800M
The Advant Controller / AC 800M series is designed for distributed control and automation systems in industries requiring high availability, advanced communication, and modular scalability. The XV C768 AE101 fits seamlessly within this architecture, designed to perform control, signal processing, and interface management tasks reliably over long operational cycles.
Related Models (Same Series or Closely Related)
| Model | Description | Dimensions (mm) | Weight (kg) | Key Feature |
|---|---|---|---|---|
| XV C768 AE102 | Enhanced variant with extended memory | 225 x 105 x 70 | 1.15 | Expanded data buffering |
| XV C724 BE102 | Real-time control module | 220 x 100 x 65 | 0.95 | Fast data processing for DCS systems |
| PM864AK01 | Main controller for AC 800M | 185 x 127 x 65 | 0.88 | Dual Ethernet and redundancy capability |
| CI854AK01 | PROFIBUS interface module | 120 x 95 x 70 | 0.45 | Integrates PROFIBUS communication |
| PM861AK02 | Mid-tier CPU module with broad compatibility | 185 x 127 x 65 | 0.90 | Supports advanced firmware functions |
Top 5 Popular ABB Modules (Other Series)
| Model | Description | Dimensions (mm) | Weight (kg) | Key Feature |
|---|---|---|---|---|
| AC500-CPU PM591 | High-performance modular PLC | 160 x 110 x 75 | 0.72 | Suitable for high-speed control systems |
| AC500-PS571 | Reliable power supply module | 150 x 100 x 70 | 0.65 | Compact and robust for industrial PLCs |
| CI860A | PROFINET communication interface | 120 x 95 x 70 | 0.42 | Enables advanced fieldbus integration |
| PM902F | High-reliability CPU module for critical systems | 185 x 127 x 65 | 0.96 | Enhanced safety and diagnostics |
| PM802F | Compact CPU for entry-level applications | 170 x 115 x 60 | 0.78 | Optimized for compact automation tasks |
FAQ (Frequently Asked Questions)
Q1: What is the primary use of the XV C768 AE101 module?
A1: It is designed to serve as a control and communication interface in industrial automation systems, supporting real-time data processing and connectivity within DCS environments.
Q2: Can the module be used in hazardous or extreme temperature environments?
A2: Yes, the module is rated for operation from -25°C to +70°C and complies with industrial EMC standards, making it suitable for rugged conditions.
Q3: What kind of mounting options are available?
A3: It can be mounted on DIN rails or directly on control panels, depending on the system design.
Q4: Does the XV C768 AE101 support Ethernet communication?
A4: Yes, it is equipped with Ethernet and serial interfaces, enabling fast and flexible communication within modern industrial networks.
Q5: How is the module powered?
A5: It operates on a 24 VDC power supply, with a tolerance of ±10% to accommodate voltage fluctuations in industrial settings.
Q6: Is firmware upgradable for this model?
A6: Yes, the firmware can be updated through the control system software to ensure compatibility and performance improvements.
Q7: Can it be used with redundant controllers?
A7: Yes, it is compatible with redundant system architectures when configured with appropriate controller modules such as the PM865AK01.
Q8: How does it handle communication with I/O devices?
A8: The module supports multiple industrial protocols and provides real-time communication with both analog and digital I/O devices.
Q9: What maintenance does the module require?
A9: Very minimal. Routine inspection for dust accumulation and secure connections is sufficient. Firmware updates and diagnostics should be part of periodic system checks.
Q10: Is this module certified for international use?
A10: Yes, it holds CE, UL, and RoHS certifications and meets industrial electromagnetic compatibility requirements.
