ABB TC810 (3BSE076220R1) Product Overview
Product Introduction
The ABB TC810 (3BSE076220R1) is an advanced process controller designed for high-performance applications in industrial environments. This product is part of ABB’s TC series, which is renowned for providing precise control and monitoring capabilities. The TC810 is engineered to handle complex process control systems with high reliability and efficiency. This model is tailored for industries that require scalable solutions, including power generation, chemical processing, and automation systems.
The TC810 offers a modular design with excellent scalability, which allows it to be adapted to meet the needs of both small-scale and large-scale industrial operations. With a robust set of communication options, versatile input/output capabilities, and high-speed processing, the TC810 is a reliable choice for industrial control applications.
Product Parameters
The following table provides a comprehensive list of key parameters for the TC810:
| Parameter |
Details |
| Model |
ABB TC810 (3BSE076220R1) |
| Type |
Process Controller |
| Power Supply |
24V DC |
| Input Channels |
12 Analog, 8 Digital |
| Output Channels |
8 Analog, 8 Digital |
| Dimensions (WxHxD) |
160mm x 180mm x 120mm |
| Weight |
1.6 kg |
| Communication Ports |
Ethernet, RS-485, Modbus, CAN |
| Temperature Range |
-10°C to 70°C |
| Mounting |
DIN Rail Mountable |
| Compliance |
CE, UL, RoHS, Ex (for hazardous areas) |
| Software Compatibility |
ABB Controller Suite, DCS/PLC |
Applications
The TC810 controller is highly versatile, making it suitable for a wide range of industrial applications:
-
Power Generation: Used to regulate and optimize the performance of power plants and electrical grids.
-
Chemical Processing: Helps monitor and control chemical reactions, ensuring efficient and safe production processes.
-
Water Treatment: Facilitates precise regulation of water quality and distribution systems.
-
Manufacturing Automation: Controls industrial machinery and factory processes for consistent quality and efficiency.
-
Oil & Gas: Monitors and controls critical infrastructure in oil and gas production, ensuring safety and performance.
Product Advantages
The TC810 offers several advantages that make it a preferred choice for industrial control systems:
-
High Flexibility: With a modular design, the TC810 can be customized to fit different industrial control needs.
-
Scalability: The system supports a variety of configurations, making it suitable for small to large-scale applications.
-
Comprehensive I/O Capabilities: The TC810 offers both analog and digital inputs/outputs, providing comprehensive control.
-
Reliability: Built to operate in harsh environments, the TC810 ensures continuous, reliable performance even in extreme conditions.
-
Advanced Communication Options: The TC810 supports multiple communication protocols, including Ethernet, RS-485, Modbus, and CAN, making integration easy with existing systems.
Brand and Series Information
-
Brand: ABB
-
Series: TC Series (Process Controllers)
-
Product Line: The TC series is widely recognized for its robust and high-performance controllers, which are used in various industries requiring precise process control and automation.
Related Models in the Same Series
Here are 5 other models from the ABB TC Series that offer similar functionalities or complementary features to the TC810:
| Model |
Description |
Key Specifications |
| TC700 |
Advanced process controller with additional features |
24V DC, 16 Analog Inputs, 12 Digital Outputs |
| TC820 |
High-performance process controller with extensive I/O |
24V DC, 32 Analog Inputs, 24 Digital Outputs |
| TC600 |
Compact, cost-effective process controller |
24V DC, 8 Analog Inputs, 4 Digital Outputs |
| TC850 |
Top-of-the-line model with integrated control functions |
24V DC, 20 Analog Inputs, 16 Digital Outputs |
| TC750 |
Reliable process controller with robust I/O options |
24V DC, 12 Analog Inputs, 8 Digital Outputs |
Popular ABB Models in Other Product Lines
Here are 5 popular models from ABB’s other product lines, each designed for specific industrial applications:
| Model |
Description |
Key Specifications |
| AC800M |
Modular and scalable PLC for process automation |
24V DC, 32 I/O, supports advanced protocols |
| PM825 |
Multifunction Power Meter for energy management |
230V AC, 8 I/O, supports Modbus and CAN |
| DCS500 |
Digital DC drive for motors |
380V AC, 150A, integrated control system |
| S900 I/O |
Distributed I/O for advanced process control |
24V DC, modular up to 16 I/O channels |
| AFC800 |
Advanced field controller for precise process control |
24V DC, 12 I/O, supports high-speed control |
