Product Introduction
The SDCS‑FEX‑2A (3ADT311500R0001) is a power‑supply / field‑excitation module designed for integration into ABB’s modular drive system architecture. Its role is to provide reliable auxiliary power and field excitation regulation within DC and synchronous‑machine drive racks, especially under demanding industrial conditions.
With design emphasis on compactness, robust operation, high efficiency and modular integration, the board suits industrial automation applications where space is at a premium, reliability is critical, and serviceability is required. The “2A” variant of the FEX family typically supports higher field‑current limits compared to earlier FEX‑1 versions, allowing more demanding motor/drive configurations.
Its installation typically occurs within the control rack of a drive system, supplying field‑excitation circuits or auxiliary power rails, monitoring health of the excitation system, and interfacing with control logic boards. With this board in place, drive systems gain enhanced reliability, improved maintainability, and simplified service swaps when needed.
Technical Parameters
| Parameter | Description |
|---|---|
| Model | SDCS‑FEX‑2A (3ADT311500R0001) |
| Brand | ABB |
| Series | DCS Field‑Excitation / Auxiliary Power Modules |
| Function | Power supply & field‑excitation board: supplies regulated voltage/current to field circuits or auxiliary drives |
| Input Voltage | 220 V AC nominal (typical industrial supply) |
| Output Frequency | Approx. 30 kHz (switching frequency) |
| Dimensions (L×W×H) | ~ 95 mm × 63 mm × 241 mm (or alternate dimension sets: ~356 × 100 × 12 mm) |
| Weight (kg) | ~ 0.30 kg – 0.40 kg (approximate) |
| Operating Temperature | ‑20 °C to +70 °C (industrial grade) |
| Humidity Range | Up to 95% non‑condensing |
| Mounting Type | Plug‑in circuit board/module for drive rack |
| Protection Class | IP20 (for internal installation) |
| Typical Use | Field‑excitation or auxiliary power supply for DC drives, synchronous motors, drive control racks |
Application
The SDCS‑FEX‑2A board is widely used in industrial automation and heavy‑duty drive contexts where reliable auxiliary and field‑excitation power is required. Typical applications include:
-
DC drive systems in steel, mining and material‑handling industries, where motors require regulated field current for torque/speed control.
-
Synchronous machine excitation systems in power‑generation plants, where stable rotor magnetisation and auxiliary supply from a compact board is essential.
-
Modular drive racks in manufacturing plants that utilise field‑excitation or auxiliary supplies for motor drives, where compact, serviceable boards improve uptime.
-
Marine and offshore propulsion or auxiliary drive systems, where space is limited, environmental conditions are harsher and modular replacement is critical.
-
System retrofit/upgrade projects of older drive architectures: installing a modern FEX‑2A board enables enhanced auxiliary power supply and improved serviceability.
In each of these scenarios, the board enhances system stability, simplifies maintenance and supports high availability operations.
Product Advantages
-
High reliability and industrial performance – Built for continuous operation in demanding environments, the board offers stable supplies and robust construction.
-
Compact form factor with lightweight design – Fits into tight control rack spaces, reducing footprint and simplifying upgrades or expansions.
-
Modular serviceability – Plug‑in installation enables quick replacement, reduced downtime and simplified spare‑parts management.
-
Versatile auxiliary/field supply support – Supports field‑excitation needs or auxiliary board supply for larger motor drive systems, improving system flexibility.
-
Wider operating range – With ‑20 °C to +70 °C temperature support and up to 95% humidity tolerance, it handles harsh site conditions.
-
System‑series compatibility – Designed for ABB’s DCS modular architecture, ensuring fit, interconnect compatibility and ease of integration.
-
Improved maintenance & lifecycle cost – By providing a modern, reliable module, it decreases failure risk, simplifies service tasks and lowers total ownership cost.
-
Future‑proofing your drive rack – With higher capability than earlier FEX versions, the FEX‑2A ensures readiness for higher‑current field circuits or advanced auxiliary systems.
Brand Overview
Brand: ABB
ABB is a global leader in industrial automation, drives and control systems. Its hardware solutions cover a wide range of sectors including heavy industry, utilities, marine, manufacturing and infrastructure. The SDCS‑FEX‑2A board is part of ABB’s modular drive‑control ecosystem, reflecting the brand’s focus on reliability, modularity and long‑term support.
Product Series
Series Name: DCS Field‑Excitation / Auxiliary Supply Modules
This series is a subset of the broader DCS modular control architecture and covers boards dedicated to providing field‑excitation power, auxiliary supplies and related regulation for motor drives and synchronous machines. It includes FEX series (FEX‑1, FEX‑2, FEX‑2A), FEP series (protection modules) and auxiliary power boards (POW series). The FEX‑2A is a higher‑capability member of this family, designed for more demanding field‑excitation or auxiliary tasks.
