ABB SC610 3BSE001552R1 – Comprehensive Technical Overview and Product Guide
1. Basic Product Information
Product Model: ABB SC610
Part Number: 3BSE001552R1
Brand: ABB
Series: SC Signal Conditioning & Converter Family
Product Type: Industrial Analog Signal Converter / Conditioner
Category: Analog Signal Processing and Measurement Module
The ABB SC610 is an industrial‑grade analog signal conditioning and converter module designed to take raw signal inputs from field sensors and instrumentation and convert them into standardized, clean analog outputs suitable for automation controllers, data acquisition systems, and monitoring equipment.
2. Product Introduction
The ABB SC610 3BSE001552R1 is part of the SC family of analog signal conditioners and converters. It is engineered to process a wide range of raw analog inputs from industrial sensors—such as thermocouples, resistance temperature detectors (RTDs), current loops, and voltage outputs—and convert these into stable, accurate analog signals. Typical output formats include industry‑standard 4–20 mA or 0–10 V signals that can be easily integrated with programmable logic controllers (PLCs), distributed control systems (DCS), human‑machine interfaces (HMIs), and data loggers.
Signal conditioning functions include noise filtering, linearization of sensor responses, signal scaling to engineering units, and galvanic isolation to eliminate interference from ground loops and electrical noise. The SC610’s construction supports continuous performance in industrial environments where electrical noise, temperature variation, and humidity may otherwise degrade signal quality.
The module’s compact DIN‑rail mount form allows for space‑efficient installation in control cabinets and electrical racks. Its screw terminal connectors facilitate easy wiring and maintenance. The SC610 is designed to ensure that automation systems receive reliable measurement signals critical for control accuracy and process monitoring.
3. Technical Specifications
Electrical, Mechanical, and Operational Parameters
| Parameter | Specification |
|---|---|
| Model | SC610 |
| Part Number | 3BSE001552R1 |
| Series | SC Signal Conditioning & Converter |
| Product Type | Analog Signal Converter / Conditioner |
| Supported Input Types | Voltage, Current, Thermocouple, RTD |
| Output Signal Types | 4–20 mA, 0–10 V Standard Outputs |
| Input Impedance | High Input Impedance (signal dependent) |
| Output Load Capability | Standard PLC/DCS/Recorder Loads |
| Galvanic Isolation | Input‑Output Isolation |
| Accuracy | ±0.1 % Full Scale (typical) |
| Response Time | < 100 ms |
| Supply Voltage | 24 V DC |
| Power Consumption | < 6 W |
| Operating Temperature Range | –10 °C to +55 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Relative Humidity | 5 % to 95 % non‑condensing |
| Protection Rating | IP20 |
| Mounting Type | DIN‑Rail Mount |
| Connection Method | Screw Terminal |
| Dimensions (W × H × D) | 35 × 100 × 110 mm |
| Weight (kg) | Approx. 0.32 kg |
4. Product Applications
The SC610 is versatile and suitable for a wide range of industrial signal conditioning needs. Its ability to accept diverse sensor inputs makes it applicable in numerous sectors.
Typical Application Scenarios
• Temperature measurement processing from thermocouples and RTDs.
• Pressure, level, and flow transmitter signal conditioning.
• Signal filtering and noise reduction in automation loops.
• Front‑end analog signal conversion for data acquisition and recorders.
• Analog feedback scaling for PLC and DCS inputs.
• Machine automation requiring precise analog input signals.
• Environmental monitoring systems requiring noise‑free analog data.
• Utility and infrastructure process automation requiring stable analog feedback.
The SC610 supports accurate, isolated transmission of measurement signals to ensure control systems and monitoring equipment receive reliable data for decision‑making and process control.
5. Product Advantages
High‑Precision Signal Conditioning
The SC610 delivers accurate linearization, scaling, and filtering of raw analog inputs, ensuring dependable measurement outputs.
Galvanic Isolation for Signal Integrity
Full isolation between input and output channels reduces electrical noise and prevents ground loop interference.
Wide Input Compatibility
Supports a variety of input signal types including voltage, current, thermocouples, and RTDs, making it highly adaptable.
Industry Standard Output Signals
Outputs 4–20 mA and 0–10 V analog signals that are compatible with most industrial controllers and monitoring systems.
Compact DIN‑Rail Form Factor
The device is designed for efficient installation inside control cabinets with minimal space usage.
Robust Industrial Reliability
Engineered for continuous operation in industrial environments with broad temperature and humidity tolerance.
Low Power Consumption
Operates on a standard 24 V DC industrial supply with modest power requirements.
Easy Installation and Maintenance
Screw terminal connections and clear wiring layout simplify field installation and service.
6. Recommended Models from the Same Series or Related Devices
Below are five related analog signal conditioning and converter models from the SC/SB families or with similar functionalities.
| Model | Supported Inputs | Output Type | Supply Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| SC500 | Voltage / Current | 4–20 mA | 24 V DC | 35×100×110 | 0.24 kg |
| SC510 | Voltage / Current / Thermocouple / RTD | 4–20 mA / 0–10 V | 24 V DC | 35×100×110 | 0.25 kg |
| SC520 | Voltage / Current / Thermocouple / RTD | 4–20 mA / 0–10 V | 24 V DC | 35×100×110 | 0.26 kg |
| SC540 | Voltage / Current / Thermocouple / RTD | 4–20 mA / 0–10 V | 24 V DC | 35×100×110 | 0.28 kg |
| SC610 | Voltage / Current / Thermocouple / RTD | 4–20 mA / 0–10 V | 24 V DC | 35×100×110 | 0.32 kg |
7. Five Popular Industrial Automation Models from the Same Brand
Below are five widely used automation hardware modules from ABB that typically integrate with signal conditioners like the SC610:
| Model | Device Type | Supply Voltage | Dimensions (mm) | Weight (kg) | Application |
|---|---|---|---|---|---|
| AC800M | Modular Controller | 24 V DC | 140×180×120 | 1.2 kg | Central process automation CPU |
| PM856 | Processor Module | 24 V DC | 120×150×90 | 0.9 kg | Logic controller |
| CI870 | Communication Module | 24 V DC | 120×150×90 | 0.8 kg | Fieldbus interface |
| AI820 | Analog Input Module | 24 V DC | 120×150×80 | 0.6 kg | Multi‑channel analog input |
| DI820 | Digital Input Module | 24 V DC | 120×150×80 | 0.6 kg | Digital signal interface |
8. Frequently Asked Questions (FAQ)
Q1: What is the main purpose of the SC610?
A: The SC610 conditions, scales, filters, and converts raw analog signals from sensors for use in automation systems.
Q2: What types of analog inputs does the SC610 support?
A: It supports voltage, current, thermocouple, and RTD inputs.
Q3: What output signals does the module provide?
A: It provides standardized analog outputs such as 4–20 mA and 0–10 V.
Q4: What power supply does the SC610 require?
A: It operates on a 24 V DC industrial supply.
Q5: How much does the SC610 weigh?
A: The approximate weight is 0.32 kg.
Q6: What are the physical dimensions of the SC610?
A: Approximately 35 × 100 × 110 mm.
Q7: Where is this product typically installed?
A: It is usually mounted on DIN rails inside control cabinets or automation racks.
Q8: Why is galvanic isolation important in signal conditioning?
A: Galvanic isolation improves signal quality by reducing electrical noise and preventing ground loop interference.
Q9: In which industries is the SC610 commonly used?
A: It is used in manufacturing, process control, utilities, and environmental monitoring systems.
Q10: Can it operate continuously in industrial environments?
A: Yes, it is designed for stable, long‑term operation under typical industrial conditions.
