ABB PU515 3BSE013063R1 – Complete Technical Overview and Product Guide
1. Basic Product Information
Product Model: ABB PU515
Part Number: 3BSE013063R1
Brand: ABB
Series: Advant OCS Operator Interface Family
Product Type: Industrial Operator Terminal / Human-Machine Interface (HMI)
Category: Process Control Interface Device
2. Product Introduction
The ABB PU515 3BSE013063R1 is a dedicated operator interface module designed for industrial automation and distributed control applications. It serves as a visualization and control access point for operators overseeing complex process systems.
This interface unit provides real-time visibility of process parameters, trend data, alarm messages, and control status to operators working in control rooms and automation cabinets. Engineered for use in Advant OCS environments, the PU515 maintains stable performance under continuous industrial operation.
The PU515 is known for its balance of display size, processing capability, and ruggedness required for automation environments across various industries. It allows integration with controllers, communication modules, and I/O subsystems to provide comprehensive system visibility and operator interactivity.
3. Technical Specifications
Electrical, Display and Mechanical Parameters
| Parameter | Specification |
|---|---|
| Model | PU515 |
| Part Number | 3BSE013063R1 |
| Series | Advant OCS Operator Interface |
| Display Type | Industrial LCD with Resistive Touch |
| Display Size | 12.1 inch |
| Resolution | 800 × 600 pixels |
| Processor Type | Embedded Industrial CPU |
| System Memory | 16–32 MB (approx.) |
| Flash Storage | 32 MB (min.) |
| Power Supply | 24 V DC |
| Input Voltage Range | 19–30 V DC |
| Power Consumption | Approx. 28 W |
| Communication Interfaces | Serial Bus / System Bus / Field Networks |
| Mounting Type | Panel / Rack Mount |
| Operating Temperature Range | 0°C to +55°C |
| Storage Temperature Range | –20°C to +70°C |
| Protection Rating | IP20 |
| Dimensions (W × H × D) | 300 × 225 × 70 mm |
| Weight (kg) | 3.0 kg |
4. Product Applications
The PU515 is widely deployed in industrial and process automation sectors requiring reliable operator visualization and control access. Typical application areas include:
• Process and production control in chemical manufacturing.
• Power plant monitoring and control systems.
• Oil and gas production and refining facilities.
• Water/wastewater treatment and distribution systems.
• Mining and heavy industry control automation.
• Pharmaceutical and food & beverage process systems.
• Batch processing systems requiring operator intervention.
• Centralized control rooms for continuous plant operations.
In these environments, operators use the PU515 interface for monitoring process variables, acknowledging alarms, issuing manual control commands, and tracking system trends.
5. Product Advantages
1. Enhanced Display Area
The 12.1-inch display offers more screen real estate than smaller interface modules, allowing richer visibility of process data and multiple graphic elements.
2. Industrial-Grade Build
Designed for continuous use in industrial environments with robust construction and reliable components.
3. Intuitive Operator Interaction
The resistive touchscreen provides responsive input and is suitable for operator use even with protective gloves.
4. Stable Power Design
Powered by standard 24 V DC industrial supply, ensuring reliable electrical performance.
5. Flexible Communication
Supports multiple communication interfaces for integration with controller and network modules.
6. Good Balance of Size and Performance
Offers a middle ground between compact and large operator interface models.
7. Industrial Operating Range
Performs reliably within specified temperature and humidity conditions.
8. Long Operational Longevity
Manufactured with industrial-grade components for extended lifecycle performance.
6. Recommended Models from the Same Series or Related Interfaces
Below are five related models within the Advant OCS operator interface family or comparable modules.
| Model | Display Size | Resolution | Power Supply | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| PU514 | 10.4 inch | 640 × 480 | 24 V DC | 260 × 180 × 65 | 2.4 kg |
| PU514A | 10.4 inch | 800 × 600 | 24 V DC | 260 × 180 × 65 | 2.5 kg |
| PU515 | 12.1 inch | 800 × 600 | 24 V DC | 300 × 225 × 70 | 3.0 kg |
| PU516 | 15 inch | 1024 × 768 | 24 V DC | 380 × 285 × 80 | 4.2 kg |
| PU518 | 17 inch | 1280 × 1024 | 24 V DC | 430 × 350 × 90 | 5.8 kg |
7. Popular Models from the Same Brand
Below are five widely used industrial automation hardware models from ABB that are popular in control system deployments.
| Model | Type | Power Supply | Dimensions (mm) | Weight (kg) | Application |
|---|---|---|---|---|---|
| AC800M | Modular Controller | 24 V DC | 140 × 180 × 120 | 1.2 kg | Central process controller |
| PM856 | Processor Module | 24 V DC | 120 × 150 × 90 | 0.9 kg | Controller CPU |
| CI870 | Communication Interface | 24 V DC | 120 × 150 × 90 | 0.8 kg | Field network interface |
| AI820 | Analog Input Module | 24 V DC | 120 × 150 × 80 | 0.6 kg | Analog data acquisition |
| DI820 | Digital Input Module | 24 V DC | 120 × 150 × 80 | 0.6 kg | Digital signal capture |
8. Frequently Asked Questions (FAQ)
Q1: What is the ABB PU515 3BSE013063R1 used for?
A: It is an operator interface module used for monitoring and controlling industrial process automation systems.
Q2: Which series does the PU515 belong to?
A: It belongs to the Advant OCS operator interface series.
Q3: What is the display size of this product?
A: It features a 12.1-inch display with 800 × 600 pixel resolution.
Q4: What is the required power supply?
A: Standard 24 V DC industrial power is used.
Q5: Where is the PU515 typically installed?
A: It is typically installed in control rooms or automation cabinets for operator access.
Q6: Can the touchscreen respond to input with operator gloves?
A: Yes, the resistive touchscreen supports input from gloved operators.
Q7: What industries commonly use this module?
A: Chemical, power, oil & gas, mining, food and beverage, and water treatment industries.
Q8: What are the physical dimensions of this interface?
A: The dimensions are approximately 300 × 225 × 70 mm.
Q9: How heavy is the PU515 unit?
A: It weighs approximately 3.0 kg.
Q10: Is it suitable for continuous 24/7 industrial operation?
A: Yes, it is engineered for continuous industrial use with stable performance.
