ABB PU514 3BSE013062R1 – Comprehensive Product Technical Guide
1. Basic Product Information
Product Model: ABB PU514
Part Number: 3BSE013062R1
Brand: ABB
Series: Advant OCS
Product Type: Operator Interface / Control Display Unit
Category: Industrial Process Control Interface Module
2. Product Introduction
The ABB PU514 3BSE013062R1 is an operator interface module designed for industrial control environments within the Advant OCS automation architecture. It serves as a process monitoring and control interface, enabling operators to interact directly with distributed control systems in real time.
This module is typically used in process industries where reliability, system stability, and continuous operation are essential. The PU514 provides operational visibility of system variables, alarms, and control commands. It is engineered for integration with controller units and I/O modules in complex automation systems.
The design focuses on industrial durability, stable communication, and long operational lifespan. It is commonly deployed in centralized control rooms or industrial cabinets as part of distributed automation solutions.
3. Technical Specifications
Electrical and Hardware Parameters
| Parameter | Specification |
|---|---|
| Model | PU514 |
| Part Number | 3BSE013062R1 |
| Series | Advant OCS |
| Product Type | Operator Interface Unit |
| Processor Type | Embedded Industrial CPU |
| Memory | 8–16 MB (Industrial grade) |
| Display Type | Industrial LCD |
| Display Size | 10.4 inch |
| Resolution | 640 × 480 pixels |
| Power Supply | 24 V DC |
| Input Voltage Range | 19–30 V DC |
| Power Consumption | Approx. 20 W |
| Communication Ports | Serial / System Bus Interface |
| Mounting Type | Rack / Panel Installation |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5–95% (non-condensing) |
| Dimensions (W × H × D) | 260 × 180 × 65 mm |
| Weight (kg) | 2.4 kg |
4. Product Applications
The PU514 is primarily applied in industrial distributed control environments.
Typical industries include:
• Power generation facilities
• Oil and gas processing systems
• Petrochemical plants
• Pulp and paper manufacturing
• Mining operations
• Marine automation control rooms
• Heavy industrial production lines
It is particularly suited for integration into control cabinets where operators need stable and continuous system visualization.
5. Product Advantages
1. Designed for Distributed Control Systems
The module integrates seamlessly within Advant OCS automation platforms.
2. Reliable Industrial Operation
Engineered for 24/7 industrial use with stable electrical design.
3. Compact Structure
Optimized dimensions allow efficient cabinet space utilization.
4. Low Power Consumption
Designed for energy-efficient operation in industrial systems.
5. Strong Communication Stability
Supports system bus communication for secure data exchange.
6. Industrial Temperature Tolerance
Operates reliably under moderate industrial environmental conditions.
7. Long Lifecycle Availability
Designed for extended service in process automation facilities.
6. Recommended Models from the Same Series or Related (Advant OCS)
Below are five related models from the Advant OCS or compatible automation family.
| Model | Product Type | Power Supply | Dimensions (mm) | Weight (kg) | Main Function |
|---|---|---|---|---|---|
| PU515A | Operator Interface | 24V DC | 260×180×65 | 2.5 kg | Enhanced display interface |
| PU516 | Control Interface Unit | 24V DC | 280×190×70 | 2.8 kg | Advanced system monitoring |
| PM511V16 | Processor Module | 5V DC (via rack) | 240×160×50 | 1.2 kg | CPU control module |
| DSAI130 | Analog Input Module | 24V DC | 240×160×45 | 0.8 kg | 16-channel AI |
| DSDI110A | Digital Input Module | 24V DC | 240×160×45 | 0.7 kg | 32-channel DI |
7. Five Popular Models from the Same Brand
Below are widely used industrial automation models from ABB.
| Model | Product Type | Power Supply | Dimensions (mm) | Weight (kg) | Application |
|---|---|---|---|---|---|
| AC800M | Controller | 24V DC | 140×180×120 | 1.2 kg | Process automation |
| PM866K01 | CPU Module | 24V DC | 120×150×90 | 0.9 kg | Central controller |
| CI854A | Communication Interface | 24V DC | 120×150×90 | 0.7 kg | PROFIBUS communication |
| AI810 | Analog Input Module | 24V DC | 120×150×80 | 0.6 kg | Analog data acquisition |
| DI810 | Digital Input Module | 24V DC | 120×150×80 | 0.6 kg | Digital signal processing |
8. FAQ – ABB PU514 3BSE013062R1
Q1: What is the primary function of the PU514?
A: It serves as an operator interface unit within distributed control systems.
Q2: Which series does this product belong to?
A: It belongs to the Advant OCS automation series.
Q3: What is the required power supply?
A: The module operates on 24V DC power.
Q4: Is this module suitable for cabinet installation?
A: Yes, it is designed for rack or panel mounting in control cabinets.
Q5: What is the display size?
A: It features a 10.4-inch industrial LCD display.
Q6: What is the operating temperature range?
A: It operates between 0°C and +55°C.
Q7: How much does the unit weigh?
A: Approximately 2.4 kg.
Q8: Can it be integrated with other control modules?
A: Yes, it is designed to work with processor and I/O modules within the same automation platform.
Q9: What industries typically use this product?
A: Power, oil & gas, chemical, mining, and heavy manufacturing industries.
Q10: Is it designed for continuous industrial operation?
A: Yes, it is engineered for stable long-term industrial use.
