Product Overview
The ABB PP D113 B03-10-150000 (Part Number: 3BHE023584R1023) is a high-performance AC 800PEC Controller Module designed for advanced industrial automation and power electronics control systems.
It belongs to the ABB AC 800PEC platform, which is specifically engineered for very fast control cycles, power conversion systems, and high-dynamic industrial applications such as drives, traction, and power generation systems.
This controller is optimized for real-time, high-speed control tasks, where cycle times can reach the microsecond range, making it suitable for demanding electrical and power system applications.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | PP D113 B03-10-150000 |
| Order Code | 3BHE023584R1023 |
| Product Type | AC 800PEC Controller |
| Control Platform | ABB AC 800PEC |
| Application Type | Power electronics / industrial automation |
| Processor Architecture | High-speed real-time control CPU (RISC-based system architecture) |
| Control Capability | Very fast control loops (microsecond-level cycles) |
| Communication Interfaces | Ethernet, fieldbus, optical I/O expansion (system dependent) |
| I/O Expansion | Modular optical and fieldbus I/O support |
| Operating Voltage | 24 V DC (system dependent) |
| Protection Rating | IP20 |
| Operating Environment | Industrial control cabinet |
| Dimensions | 450 × 100 × 145 mm |
| Weight | 2.59 kg |
Function and Working Principle
The PP D113 AC 800PEC controller is designed for high-speed deterministic control applications. It processes real-time signals from power electronics systems and executes control algorithms for fast dynamic systems such as converters, drives, and energy systems.
Unlike standard PLCs, the AC 800PEC platform is optimized for extremely fast control loops (down to ~100 microseconds) and tight integration with power electronics hardware.
Operating Sequence
- Power system and sensors feed real-time electrical signals to the controller
- AC 800PEC CPU executes high-speed control algorithms
- Optical and fieldbus I/O modules exchange data with peripheral devices
- Control outputs are sent to power converters, drives, or actuators
- Continuous closed-loop regulation ensures system stability
Key Features
- High-performance ABB AC 800PEC controller
- Designed for power electronics and fast control applications
- Supports microsecond-level control cycles
- Modular architecture with optical I/O expansion
- High-speed deterministic processing capability
- Integrated communication with industrial systems
- Suitable for demanding electrical control environments
- Robust industrial-grade design for continuous operation
System Role
The PP D113 B03-10-150000 acts as a central high-speed control processor in ABB AC 800PEC systems, responsible for:
- Real-time control of power electronics systems
- Execution of fast dynamic control algorithms
- Coordination of optical I/O modules
- Communication with upper-level automation systems
- Closed-loop regulation of electrical parameters
Typical System Architecture
Sensors / Power Electronics → Optical I/O Modules → PP D113 AC 800PEC Controller → Power Converter / Drive System → Process Feedback Loop
Industrial Applications
The PP D113 AC 800PEC controller is used in:
- Power generation systems
- Electrical drive systems
- Traction and rail transportation systems
- Industrial power converters
- Renewable energy systems (wind / power electronics interfaces)
- High-speed motor control applications
- Utility grid control systems
- Heavy industrial automation requiring fast control loops
Installation Guidelines
- Install inside ABB AC 800PEC control cabinets
- Ensure proper thermal management and grounding
- Use optical fiber connections for I/O modules where applicable
- Follow ABB system integration and commissioning procedures
- Configure using ABB ControlIT / AC 800PEC engineering tools
- Verify communication and loop timing during startup
Compatible Components
The PP D113 B03-10-150000 works with:
- ABB AC 800PEC CPU and backplane systems
- Optical I/O modules (PowerLink interfaces)
- Fieldbus communication modules
- ABB power electronics converters
- Industrial Ethernet systems
- ControlIT engineering environment
Alternative Models
| Model | Description |
|---|---|
| PP D113 B01-10-150000 | Earlier AC 800PEC controller variant |
| PP D113 B03-19-150000 | Alternative configuration model |
| AC 800M PM864 | General-purpose control CPU |
| ABB AC 800PEC CPU modules | High-speed power electronics controllers |
| ABB excitation control systems | Related power control platforms |
Advantages
- Extremely fast control performance (microsecond-level loops)
- Optimized for power electronics systems
- Modular and scalable architecture
- High reliability in demanding industrial environments
- Strong integration with ABB AC 800PEC ecosystem
- Suitable for mission-critical electrical applications
- Deterministic real-time behavior
Frequently Asked Questions
What is the PP D113 B03-10-150000 used for?
It is used as a high-speed controller in ABB AC 800PEC systems, mainly for power electronics and industrial drive applications.
Is it a PLC?
No, it is not a standard PLC. It is a specialized high-speed power electronics control system.
Where is it used?
It is used in power generation, traction systems, industrial drives, and energy conversion systems.
What makes AC 800PEC different?
It supports very fast control cycles (microseconds range) and is optimized for power electronics rather than general automation.
Is it still used today?
Yes, it is still widely used in industrial power systems and installed ABB control infrastructures.
Conclusion
The ABB PP D113 B03-10-150000 (3BHE023584R1023) AC 800PEC Controller is a high-performance industrial control module designed for ultra-fast power electronics applications. With its microsecond-level control capability, modular architecture, and strong integration into ABB AC 800PEC systems, it is widely used in power generation, traction, and advanced industrial drive systems where real-time precision is critical.
