Product Overview
The ABB PM5650-MC-KIT (Part Number: 1SAP141000R0379) is a high-performance Controller Kit from the ABB AC500 PLC series. It is designed for advanced industrial automation and machine control applications, combining a powerful CPU module with motion and communication components in a single integrated solution.
The kit is intended for complex automation systems, offering high processing capability, multi-network communication, and flexible expansion for motion and distributed control architectures.
Kit Composition
The PM5650-MC-KIT typically includes:
- PM5650-2ETH CPU Processor Module
- CM579-ETHCAT communication module (EtherCAT)
- TB5610-ETH terminal/base module
- PS5611-MC power supply module
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | PM5650-MC-KIT |
| Part Number | 1SAP141000R0379 |
| Product Type | Controller Kit |
| PLC Series | AC500 |
| CPU Included | PM5650-2ETH |
| Program Memory | 80 MB |
| User Memory | 369256 kB RAM |
| Industrial Ethernet | 2 ports |
| Motion Communication | EtherCAT support (via CM579-ETHCAT) |
| Serial Communication | RS232 / RS485 (via CPU) |
| Fieldbus | CAN support |
| Supply Voltage | 20.4–28.8 V DC |
| Rated Voltage | 24 V DC |
| Protection Rating | IP20 |
| Mounting Method | DIN Rail |
| Dimensions | 250 × 110 × 180 mm |
| Weight | 0.363 kg |
Function and Working Principle
The PM5650-MC-KIT functions as a complete automation controller system. It combines PLC logic execution, high-speed motion control, and industrial communication into a unified platform.
The CPU processes automation logic, while the EtherCAT module enables deterministic real-time communication for synchronized motion control systems. The controller also supports Ethernet-based communication for SCADA, HMI, and engineering tools.
Operating Sequence
- Input signals from sensors and field devices are collected
- PLC program executes in the PM5650-2ETH CPU
- Motion and control data is processed in real time
- EtherCAT transmits synchronized commands to drives
- System status is continuously monitored via Ethernet
Key Features
- Complete AC500 machine control kit solution
- High-performance 80 MB CPU memory
- Dual Industrial Ethernet interfaces
- Integrated EtherCAT communication capability
- Multi-module architecture (CPU + comms + power)
- Real-time motion control readiness
- High scalability for industrial systems
- DIN rail installation design
- Robust ABB industrial reliability
System Role
The PM5650-MC-KIT serves as a central machine control platform, integrating:
- PLC logic control
- Motion control coordination
- Industrial networking
- Distributed I/O management
Typical System Architecture
Sensors → PM5650-MC-KIT Controller Kit → EtherCAT / Ethernet Network → Drives / Actuators → Machine System
Industrial Applications
The PM5650-MC-KIT is widely used in:
- Robotics systems
- Packaging machinery
- High-speed production lines
- CNC-related automation
- Material handling systems
- Printing and textile machines
- Semiconductor automation
- Complex OEM machine design
Installation Guidelines
- Install components on DIN rail inside control cabinet
- Ensure stable 24 V DC power supply
- Connect CPU, EtherCAT, and I/O modules properly
- Configure industrial networks (EtherCAT + Ethernet)
- Load PLC and motion program via ABB engineering software
- Perform full system commissioning and safety checks
Compatible Components
The kit is compatible with:
- ABB AC500 I/O modules
- ABB servo drives and motion systems
- EtherCAT field devices
- Industrial Ethernet switches
- ABB HMI panels
- SCADA systems
- ABB Automation Builder software
Alternative Models
| Model | Description |
|---|---|
| PM5650-2ETH | Standalone CPU module |
| PM5650-MC-EIP-KIT | EtherNet/IP motion kit variant |
| PM5640-2ETH | Mid-range CPU module |
| PM5072-MC-KIT | Motion controller kit |
| PM5082-MC-KIT-EC-EIP | Advanced motion control kit |
Advantages
- Fully integrated machine control solution
- High-performance 80 MB processing capacity
- Supports real-time EtherCAT motion control
- Dual Ethernet communication flexibility
- Modular and scalable architecture
- Suitable for complex industrial automation
- Strong ABB reliability and durability
Frequently Asked Questions
What is the PM5650-MC-KIT used for?
It is used for advanced machine automation and motion control systems, combining PLC, communication, and motion functions.
What components are included in the kit?
It includes the PM5650-2ETH CPU, CM579-ETHCAT module, TB5610-ETH terminal module, and PS5611-MC power module.
Does it support motion control?
Yes. It supports motion control via EtherCAT communication (CM579-ETHCAT module).
Is it suitable for large industrial systems?
Yes. It is designed for complex, multi-axis and high-performance automation systems.
Conclusion
The ABB PM5650-MC-KIT (1SAP141000R0379) is a powerful all-in-one AC500 machine control solution. With its 80 MB CPU, EtherCAT motion capability, dual Ethernet communication, and modular architecture, it provides a scalable and high-performance platform for advanced industrial automation, robotics, and complex machine control applications.
