PFEA112-20 (3BSE050091R20 / 3BSE030369R0020 / 3BSE030369R20) – Industrial Force Measurement Module
Product Overview
The PFEA112-20, with part numbers 3BSE050091R20, 3BSE030369R0020, 3BSE030369R20, is a precision industrial force measurement module capable of measuring forces up to 20 kN. It is part of ABB’s PFEA series, engineered for high-accuracy load sensing in industrial and laboratory environments.
This module transforms applied mechanical forces into stable analog electrical signals suitable for automated process monitoring, control systems, and data acquisition. Designed for durability, the PFEA112-20 can operate reliably in challenging industrial conditions, including vibration, dust, moderate moisture, and temperature variations.
The device is ideal for industrial automation, material testing, weighing applications, structural monitoring, and laboratory force measurement. Its modular design ensures easy installation, maintenance, and seamless integration into existing systems.
Brand Information
| Item | Description |
|---|---|
| Brand | ABB |
| Product Model | PFEA112-20 |
| Part Numbers | 3BSE050091R20 / 3BSE030369R0020 / 3BSE030369R20 |
| Product Category | Industrial Force Measurement Module |
| Product Type | Precision Load Cell / Force Sensor |
| Application Industry | Industrial automation, manufacturing, material testing, quality control |
| Installation | Flange mount / direct mechanical integration |
Product Series
The PFEA Series focuses on industrial force measurement modules with the following features:
-
High-accuracy measurement across multiple force ranges
-
Rugged, durable design for harsh industrial environments
-
Modular and compact construction for easy integration and maintenance
-
Output signals compatible with PLCs, SCADA systems, and data acquisition units
The series is widely applied in industrial automation, R&D laboratories, process monitoring, and manufacturing quality control.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PFEA112-20 |
| Part Numbers | 3BSE050091R20 / 3BSE030369R0020 / 3BSE030369R20 |
| Product Type | Industrial Force Measurement Module |
| Force Measurement Range | 0 – 20 kN |
| Accuracy | ±0.05% full scale |
| Output Signal | Analog mV/V, compatible with digital acquisition systems |
| Excitation Voltage | 5 – 15 VDC |
| Temperature Compensation | -10°C to +50°C operating |
| Maximum Overload | 150% of rated capacity |
| Protection Class | IP65 (dust and water resistant) |
| Mounting Method | Flange mount / direct mechanical integration |
| Dimensions | 180 × 90 × 75 mm |
| Weight | 2.4 kg ( ) |
Product Features
-
High Accuracy: Provides precise measurement in both tension and compression applications.
-
Durable Design: Resists vibration, dust, moderate moisture, and temperature variations.
-
Compact and Modular: Simplifies installation, maintenance, and integration.
-
Reliable Signal Output: Analog output compatible with automation and data acquisition systems.
-
Overload Protection: Protects the sensor from mechanical damage and ensures longevity.
-
Wide Applications: Suitable for industrial automation, material testing, weighing, and structural monitoring.
Product Applications
-
Industrial Automation: Force monitoring in production lines and automated systems.
-
Material Testing: Accurate force measurement in tensile, compressive, and fatigue tests.
-
Manufacturing Quality Control: Ensures consistent production quality and process reliability.
-
Weighing Systems: Integration into industrial and process weighing applications.
-
Research & Development: Supports laboratories and engineering centers in load testing and analysis.
Product Advantages
-
High Precision: ±0.05% full-scale accuracy ensures reliable readings.
-
Rugged Construction: Suitable for demanding industrial environments.
-
Easy Integration: Modular design allows fast installation and maintenance.
-
Protective Features: IP65 protection and overload capacity enhance durability.
-
Versatile Applications: Applicable across industrial automation, material testing, weighing, and R&D.
Recommended Models from the Same Series or Related Modules
| Model | Product Type | Key Function | Dimensions | Weight kg ( ) |
|---|---|---|---|---|
| PFEA111-10 | Load Cell | Force measurement up to 10 kN | 160 × 80 × 70 mm | 1.8 kg ( ) |
| PFEA111-20 | Load Cell | Force measurement up to 20 kN | 180 × 90 × 75 mm | 2.2 kg ( ) |
| PFEA111-30 | Load Cell | Force measurement up to 30 kN | 190 × 90 × 80 mm | 2.5 kg ( ) |
| PFEA111-50 | Load Cell | Force measurement up to 50 kN | 210 × 100 × 90 mm | 3.5 kg ( ) |
| PFEA112-50 | Heavy-Duty Load Cell | High-capacity measurement | 220 × 105 × 95 mm | 4.0 kg ( ) |
Popular Models from the Same Brand
| Model | Product Type | Key Function | Dimensions | Weight kg ( ) |
|---|---|---|---|---|
| ACS880‑01‑04A0‑3 | Variable Frequency Drive | Motor speed control | 520 × 220 × 280 mm | 8.5 kg ( ) |
| ACS580‑01‑046A‑4 | General Purpose Drive | Energy-efficient automation | 510 × 220 × 300 mm | 9.1 kg ( ) |
| ACS550‑01‑05A4‑4 | Industrial Drive | Pump and fan control | 480 × 200 × 260 mm | 7.2 kg ( ) |
| PFCA 401 | Power Factor Controller | Reactive power management | 150 × 130 × 70 mm | 0.6 kg ( ) |
| PP D113 B01‑10‑150000 | Industrial Controller | Automation system processing | 210 × 150 × 100 mm | 1.8 kg ( ) |
FAQ (Frequently Asked Questions)
Q1: What is the main function of PFEA112-20?
A1: It measures mechanical forces up to 20 kN with high precision for industrial and laboratory applications.
Q2: Can it measure both compression and tension forces?
A2: Yes, it provides accurate readings for both tensile and compressive forces.
Q3: What operating environments are suitable for this module?
A3: Industrial environments with vibration, dust, moderate moisture, and temperature variations.
Q4: How accurate is PFEA112-20?
A4: It offers ±0.05% full-scale accuracy.
Q5: Can it be used in automated systems?
A5: Yes, the analog output is compatible with PLCs, SCADA systems, and data acquisition units.
Q6: What is the maximum overload capacity?
A6: It can safely handle up to 150% of the 20 kN rated force.
Q7: How is it installed?
A7: It can be flange-mounted or integrated directly into mechanical systems.
Q8: What protection does it have?
A8: IP65 protection against dust and water, plus mechanical overload protection.
Q9: Is maintenance difficult?
A9: No, its modular design allows easy installation, replacement, and integration.
Q10: Which industries benefit most from PFEA112-20?
A10: Industrial automation, material testing, manufacturing quality control, process monitoring, and R&D laboratories.
