ABB FS450R12KE3 / FS450R17KE3 / AGDR-61C / AGDR61C Product Overview
Product Overview:
The ABB FS450R12KE3, FS450R17KE3, AGDR-61C, and AGDR61C (product codes: 64635867, 64606221, 64606221D, 64783831) are high-performance industrial components used in power electronics, motor control, and automation systems. These components are designed to offer high reliability, efficiency, and versatility in demanding industrial environments. The FS450R12KE3 and FS450R17KE3 are IGBT power modules, while the AGDR-61C and AGDR61C are part of the ABB’s advanced gate drive and protection module family.
These products are designed for use in industrial motor drives, solar inverters, HVDC systems, and rail traction systems, among others. Their superior characteristics such as fast switching speeds, high voltage handling capabilities, and thermal efficiency make them ideal for applications that require high power density and reliability.
Key Specifications and Parameters:
| Parameter | FS450R12KE3 (64635867) | FS450R17KE3 (64606221) | AGDR-61C (64606221D) | AGDR61C (64783831) |
|---|---|---|---|---|
| Product Name | FS450R12KE3 | FS450R17KE3 | AGDR-61C | AGDR61C |
| Series | IGBT Power Module | IGBT Power Module | Gate Drive Module | Gate Drive Module |
| Weight | 0.75 kg | 0.85 kg | 0.55 kg | 0.55 kg |
| Dimensions (LxWxH) | 120 mm x 95 mm x 32 mm | 130 mm x 100 mm x 35 mm | 100 mm x 80 mm x 40 mm | 100 mm x 80 mm x 40 mm |
| Power Rating | 450 A | 450 A | 15 A | 15 A |
| Voltage Rating | 1200 V | 1700 V | 60 V | 60 V |
| Current Rating | 450 A | 450 A | 15 A | 15 A |
| Switching Frequency | High Switching Speed | High Switching Speed | High Switching Speed | High Switching Speed |
| Thermal Resistance | Low Thermal Resistance | Low Thermal Resistance | Low Thermal Resistance | Low Thermal Resistance |
| Mounting | Bolt Mounting | Bolt Mounting | Surface Mounting | Surface Mounting |
| Application | Inverters, Drives, HVDC | Inverters, Drives, HVDC | Motor Control, Protection | Motor Control, Protection |
Product Introduction:
-
FS450R12KE3 and FS450R17KE3: These are IGBT power modules designed to handle high current and voltage, offering high efficiency and reliability in industrial motor drives, solar inverters, and HVDC systems. The FS450R12KE3 supports a voltage of 1200 V, while the FS450R17KE3 can handle a higher voltage of 1700 V. These modules are designed to offer fast switching speeds and low thermal resistance, ensuring efficient energy conversion and minimizing losses.
-
AGDR-61C and AGDR61C: These are gate drive modules designed for driving IGBTs and MOSFETs in power electronic applications. They provide fast switching and are equipped with protection features to enhance the reliability of the system. The AGDR-61C series is particularly used in motor control, inverters, and renewable energy systems, where precise control and protection of the IGBT modules are critical.
Applications:
-
FS450R12KE3 & FS450R17KE3:
-
Industrial Motor Drives: Used in the power electronics of industrial motor control systems, offering efficient and fast switching.
-
Solar Inverters: Provides high efficiency for converting DC to AC in renewable energy applications.
-
HVDC Systems: Essential for the conversion of high-voltage DC electricity in long-distance power transmission.
-
-
AGDR-61C & AGDR61C:
-
Motor Control Systems: Used in precise motor control applications to drive IGBT and MOSFET switches.
-
Inverters: Protects and drives power components in both industrial and renewable energy inverters.
-
Renewable Energy Systems: Used in solar, wind, and energy storage systems for controlling the power electronic devices.
-
Rail Traction Systems: Provides the necessary gate driving and protection for IGBT devices used in traction control.
-
Advantages:
-
High Switching Speed: These modules are designed with fast switching speeds, ensuring efficient energy conversion and minimizing switching losses.
-
Low Thermal Resistance: These products have low thermal resistance, which reduces heat generation, contributing to longer operational lifetimes and better efficiency.
-
High Power Density: Offers high current handling capabilities in a compact size, making them ideal for space-constrained industrial applications.
-
Robust Protection Features: The AGDR-61C and AGDR61C modules include robust protection features, ensuring the safe operation of IGBT and MOSFET devices, which improves overall system reliability.
-
Versatile Applications: These modules are suitable for a wide range of applications, from motor control and inverters to renewable energy and rail traction systems.
Brand and Series:
-
Brand: ABB
-
Series: FS Series (FS450R12KE3 / FS450R17KE3) & AGDR Series (AGDR-61C / AGDR61C)
Similar Models in the ABB FS Series and AGDR Series
| Model | Key Specifications |
|---|---|
| FS600R12KE3 | 600 A, 1200 V IGBT, fast switching, 0.80 kg, 130 mm x 100 mm x 35 mm |
| FS600R17KE3 | 600 A, 1700 V IGBT, high power density, 0.90 kg, 135 mm x 105 mm x 38 mm |
| AGDR-62C | 18 A, 60 V gate drive module, 0.60 kg, 110 mm x 90 mm x 45 mm |
| AGDR-63C | 20 A, 60 V gate drive module, 0.65 kg, 115 mm x 95 mm x 50 mm |
| AGDR-64C | 25 A, 60 V gate drive module, 0.70 kg, 120 mm x 100 mm x 52 mm |
Top 5 Popular ABB Models (Same Brand)
| Model | Key Specifications |
|---|---|
| IRB 6700 | 6-axis industrial robot, 50 kg payload, 3.2 m reach, 3200 mm/s speed |
| PM810 | Power meter, 24 V DC, 60 mm x 80 mm x 100 mm, 0.5 kg |
| AC500 | Modular PLC, 24 V DC, supports Ethernet/IP, PROFIBUS, CANopen |
| A60 | Low-voltage switchgear, 690 V, 50 A, 4000 A, 6 kA short circuit |
| AF50 | Circuit breaker, 50 A, 1-3 pole, 400 V AC, 80 mm x 50 mm x 40 mm |
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the FS450R12KE3 and FS450R17KE3?
A1: The FS450R12KE3 and FS450R17KE3 are IGBT power modules used for high-current, high-voltage applications such as industrial motor drives, solar inverters, and HVDC systems.
Q2: What voltage ratings do the FS450R12KE3 and FS450R17KE3 support?
A2: The FS450R12KE3 supports 1200 V, and the FS450R17KE3 supports 1700 V, making them suitable for different industrial power requirements.
Q3: What applications are the AGDR-61C and AGDR61C used for?
A3: The AGDR-61C and AGDR61C are gate drive modules used to control IGBT and MOSFET switches in motor control systems, inverters, and renewable energy applications.
Q4: What is the switching frequency capability of these products?
A4: All of these modules feature high switching frequencies, which enable efficient power conversion and reduce switching losses in power electronics applications.
Q5: How is the cooling managed in these modules?
A5: The FS450R12KE3 and FS450R17KE3 modules have low thermal resistance designs to improve heat dissipation, ensuring efficient performance in demanding environments.
Q6: What are the mounting options for these modules?
A6: The FS450R12KE3 and FS450R17KE3 use bolt mounting, while the AGDR-61C and AGDR61C are designed for surface mounting.
Q7: What protection features are included in the AGDR-61C and AGDR61C?
A7: These gate drive modules include robust protection features to safeguard IGBT and MOSFET devices from overcurrent, overvoltage, and short circuits.
Q8: What is the weight of these modules?
A8: The FS450R12KE3 weighs 0.75 kg, the FS450R17KE3 weighs 0.85 kg, and the AGDR-61C and AGDR61C each weigh 0.55 kg.
Q9: Are these modules suitable for use in renewable energy systems?
A9: Yes, both the FS450R12KE3, FS450R17KE3, and the AGDR-61C/AGDR61C are commonly used in solar inverters, wind power systems, and other renewable energy applications.
Q10: What is the thermal resistance of these modules?
A10: These modules are designed with low thermal resistance, ensuring efficient cooling and long operational lifetimes in high-performance applications.
