ABB Bailey IMSET01 Event Sequencer Timer Module
Product Introduction
The IMSET01 is an Event Sequencer Timer module from ABB’s Bailey controls product line. It sequences up to 32 timed events based on programmable setpoints, supporting cascade and interlock logic. Integrated into the ABB Bailey™ modular I/O rack, the IMSET01 delivers deterministic timing for batch processes, startup/shutdown sequences, and interlock management in continuous and discrete applications.
Key Applications
-
Batch Control: Orchestrating multi-step batch recipes with precise timing in chemical and food processing.
-
Startup/Shutdown Sequences: Safe, repeatable ramp-up or ramp-down of turbines, compressors, and reactor systems.
-
Interlock Timing: Enforcing timed delays for safety interlocks and permissive logic in oil & gas and power plants.
-
Pump/Valve Cycling: Automating sequential pump staging and valve actuation in water and wastewater facilities.
-
Preventive Maintenance: Triggering alarms and test routines at programmed intervals for critical equipment.
Product Advantages
-
High Event Capacity: Supports up to 32 independent timer channels in a single module.
-
Flexible Logic: Cascade, repeat, and inhibit functions allow complex sequence designs without external logic.
-
Deterministic Performance: Hardware-based timing guarantees millisecond accuracy unaffected by network load.
-
Seamless Integration: Plug-and-play into the ABB Bailey rack with auto-recognition and hot-swap support.
-
Robust Diagnostics: Built-in health monitoring reports module failures, timing overruns, and bus communication errors.
Brand: ABB Bailey™ Controls
Detailed Technical Parameters
| Specification | Details |
|---|---|
| Model Number | IMSET01 |
| Series | ABB Bailey™ IM Series |
| Function | 32-channel event sequencer & timer |
| Timer Range | 1 ms to 99,999 s |
| Timing Resolution | 1 ms |
| Control Inputs | 4 status inputs for cascade & inhibit |
| Outputs | 32 discrete relay outputs (Form A) |
| Power Supply | 24 V DC ±10 % |
| Network Interface | ABB proprietary bus, 1.5 Mbps |
| Diagnostics | Module health, channel overrun, bus error LEDs |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5 % to 95 % RH (non-condensing) |
| Dimensions (W×H×D) | 330.2 × 177.8 × 50.8 mm |
| Weight | 0.37 kg |
| Mounting | DIN-rail or rack slot, hot-swap capable |
Related Series / Function Models
| Model | Description |
|---|---|
| IMTIM01 | 16-channel general-purpose timer |
| IMCNT01 | 16-channel event counter |
| IMFLP01 | 8-channel flip-flop / latch module |
| IMDLY02 | 8-channel programmable on-delay timer |
| IMRPT01 | Repeat timer with 8 channels |
Popular ABB Bailey™ Models
| Model | Description | Function Type | Channels | Dimensions (mm) | Weight (kg) | Key Features |
|---|---|---|---|---|---|---|
| IMRAE11 | Analog input module | Analog Input | 8 channels | 330.2 × 177.8 × 50.8 | 0.35 | 4-20 mA input, high accuracy |
| IMQRS02 | Quadrature encoder input module | Encoder Input | 2 channels | 330.2 × 177.8 × 50.8 | 0.38 | For high-speed rotary encoders |
| IMSER02 | Serial communication module | Communication Interface | N/A | 330.2 × 177.8 × 50.8 | 0.40 | Supports Modbus, DNP3 protocols |
| IMSET01 | Event sequencer / timer module | Timer / Sequencer | 32 channels | 330.2 × 177.8 × 50.8 | 0.37 | Multi-channel event timing |
| IMCNT01 | Event counter module | Event Counter | 16 channels | 330.2 × 177.8 × 50.8 | 0.36 | High-speed counting capability |
Frequently Asked Questions (FAQ)
Q: How many timer channels does IMSET01 support?
A: It provides 32 independent event/timer channels, each programmable from 1 ms to 99,999 s.
Q: What accuracy can I expect?
A: Timing resolution is 1 ms with hardware-based counters for ±1 ms accuracy.
Q: Can timers be cascaded?
A: Yes—any channel can trigger others via 4 control inputs supporting cascade and inhibit logic.
Q: How are timing overruns handled?
A: Built-in diagnostics flag overruns per channel and report via module health LEDs.
Q: Is hot-swap supported?
A: Yes—IMSET01 can be inserted or removed without powering down, if used in a redundant rack.
Q: What output type is used?
A: Each channel drives a Form A relay contact, rated for 2 A at 30 V DC or 250 V AC.
Q: How does the module integrate into the control network?
A: It uses ABB’s proprietary bus at 1.5 Mbps, auto-detected by the system controller.
Q: What environmental conditions can it operate under?
A: Rated for 0 °C to +60 °C and 5 %–95 % RH non-condensing.
Q: Does it require special software?
A: No—configuration is via the standard ABB Bailey I/O configuration tool included with the controller.
Q: What form of mounting is used?
A: It clips into ABB’s modular rack or on a TS35 DIN rail, with spring latches for secure hold.
